Energenie MIHO014 Fitting And Wiring Instructions

MIHO014 In-line Relay
Fitting and Wiring Instructions
1). Before commencing work, isolate the mains power supply and
remove the fuse in the fuse box or switch off the circuit breaker
in the consumer unit.
2). Connect the wires as shown in the wiring diagram below.
Ensure the cables are stripped to an appropriate length of
between 6mm and 10mm. Ensure the cables are fully inserted
into the terminals and that the terminals are properly tightened
and no bare wire is visible.
3). Screw the unit to a suitable flat vertical surface at least 400mm
above the adjacent floor.
4). This product must be installed in accordance with the latest
Building and IET wiring regulations. If in any doubt, please
contact a qualified electrician.
Note: For indoor use only
Mi Home
™
