Ⅰ. INTRODUCTION .............................................................................................................................................. 1
Ⅱ. SAFETY NOTES ............................................................................................................................................... 1
Ⅲ. PRECAUTIONS ................................................................................................................................................ 2
Ⅳ. MAINTENANCE............................................................................................................................................... 3
Ⅴ. HOW DOES YOUR ATMOSPHERIC WATER GENERATOR WORK? ......................................................... 3
Ⅵ. FEATURES OF ATMOSPHERIC WATER GENERATOR. .............................................................................. 4
Ⅶ. OPERATING YOUR ATMOSPHERIC WATER GENERATOR ...................................................................... 6
1. DIGITAL TOUCH SCREEN FUNCTION .................................................................................................. 6
1.1.
1.2. Digital Touch Screen indication ...................................................................................................... 12
2. SETTING UP ............................................................................................................................................. 15
3. OPERATIONAL STAGE ........................................................................................................................... 16
4. CLEANING AND REPLACEMENT OF FILTERS .................................................................................. 18
4.1. Cleaning .......................................................................................................................................... 24
4.2. Sterilization ..................................................................................................................................... 28
4.3. Replacement .................................................................................................................................... 29
5. ATTENTION .............................................................................................................................................. 34
Ⅷ. TROUBLE SHOOTING .................................................................................................................................. 35
Ⅸ. TECHNICAL SPECIFICATIONS ................................................................................................................... 39
Note：We reserves the right to at any time without notice make any changes / amendments / deletions and / or
variations to the contents of this manual.
Contents
............................................................................................................................... 6
Advertisement
Table of Contents
Summary of Contents for Aquavida AQ200
-
Page 1: Table Of Contents
Contents Ⅰ. INTRODUCTION .............................. 1 Ⅱ. SAFETY NOTES ............................... 1 Ⅲ. PRECAUTIONS ..............................2 Ⅳ. MAINTENANCE............................... 3 Ⅴ. HOW DOES YOUR ATMOSPHERIC WATER GENERATOR WORK? ............3 Ⅵ. FEATURES OF ATMOSPHERIC WATER GENERATOR................4 Ⅶ. OPERATING YOUR ATMOSPHERIC WATER GENERATOR ..............6 1. -
Page 2: Ⅰ. Introduction
ATMOSPHERIC WATER GENERATOR Ⅰ . INTRODUCTION Thank you for purchasing the Atmospheric Water Generator. The Atmospheric Water Generator is a new, state-of-the-art water-generating machine, which uses some of the latest and most sophisticated technology available in the industry today. We have designed your Atmospheric Water Generator with one objective in mind i.e. -
Page 3: Ⅲ. Precautions
USER’S MANUAL Keep an eye on children to ensure they will not have fun with this product. Ⅲ. PRECAUTIONS Do not place the unit too close to the wall. Best performance is obtained when the unit is placed at least 50 cm from the wall. -
Page 4: Ⅳ. Maintenance
ATMOSPHERIC WATER GENERATOR Ⅳ. MAINTENANCE Always keep the unit clean. Wipe the outer casing with soft, damp fabric to clean. Use water to clean, avoid using harsh cleaning agent. Do not use cleaning agent to clean storage tanks. Clean air filters regularly to ensure proper air flow. When machine not use for a longer period of time, drain out all water completely and clean all tanks. -
Page 5: Ⅵ. Features Of Atmospheric Water Generator
USER’S MANUAL Ⅵ. FEATURES OF ATMOSPHERIC WATER GENERATOR. 1. Microcomputer The unit is fitted with a microcomputer, which ensures proper working of internal parts. The machine has preset hot/cold temperature adjustable functions. Temperature of hot or cold water can preset according to personal preference. - Page 6 ATMOSPHERIC WATER GENERATOR filter out dust particles and effectively block dust in the air from entering the machine. 6.2. LF2 zeolite + active carbon filter at the bottom tank(As per customer”s requirement): This device can remove organic compound, dust and large particles in the air. It can also reduce ammonia level in the water.
-
Page 7: Ⅶ. Operating Your Atmospheric Water Generator
USER’S MANUAL Ⅶ. OPERATING YOUR ATMOSPHERIC WATER GENERATOR By following these simple instructions and simple maintenance procedures, your Water Generator should give you years of trouble-free operation while producing the most maximum amount of pure, high-quality, drinking water that is not only healthy, but also beneficial to your health. Please read this operation manual carefully before you start the machine. - Page 8 ATMOSPHERIC WATER GENERATOR 1.1.1. Digital Touch Screen Icon Funciton 1.1.1-1. Screen Indication 1.1.1-2. From the top to bottom are as follows, Booster bump icon indicator, Heating function, Cooling function, Water generating indicator. 1.1.1-3. Water level in the top tank and bottom tank(top tank represents water level in the top tank, bottom tank represents water lever in the bottom tank) 1.1.1-4.
- Page 9 USER’S MANUAL ”flashes，continuously soft press the icon“ ”dispenser water. when the icon“ ：Enter function setting choose function and make adjustments. 1.1.2-4. Ajdustment icon ：to select function: Select function needed to be adjueded 1.1.2-5. Hold on the mode icon STDBY-ON / OFF： soft press the icon of power-saving, soft press the icon of “ ”...
- Page 10 ATMOSPHERIC WATER GENERATOR start the function； ： indicates filter system usage time periods （it can be reseted to FLT1--***, FLT2--***， FLT3--***， RO--*** zero when the number is not zero） ， soft press the icon of “ ” will clear the time set （ indicates DAYS 000）...
- Page 11 USER’S MANUAL 1.1.3-4. When the machine has enough wter, soft press the “ ” icon and, then pressand the npress “ ” to select options to adjust. When the “COOLING” is on. Its light is on. If it is shut down, the light is off. Only when it is met the pre-set condition, the icon of COOLING flashes, which means it is cooling.
-
Page 12: Setting Up
ATMOSPHERIC WATER GENERATOR 2. SETTING UP 2.1. Please confirm parts in the package are of complete set. The unit should be placed on solid and level ground, and be located in place with good air circulation. The unit should be placed no less than 50 cm from the wall. Push down the lever of braking wheel to get the machine in fixed position. - Page 13 USER’S MANUAL press “ ” to select options to adjust. When heating is on, the “HEATING” will light on, light turns off when function is off. This will happen when the water level is no less than 2 . It means the machine starts heating.
- Page 14 ATMOSPHERIC WATER GENERATOR showing and the FILTERING icon showed in the screen will stop flashing. Timer has been RO-000 re-set.(Refer to 1.2-5-7) 3.7. For cool water dispensing, keep pressing on the “ ” key; For hot water dispensing, press “ ”...
-
Page 15: Cleaning And Replacement Of Filters
USER’S MANUAL 3.10. Brand new machine under first time use need to follow “Machine cleaning and sterilizing” procedure and remove odor from machine parts. CLEANING AND REPLACEMENT OF FILTERS screen Water Water tap Drain Cold Water Drain Waste Water Drain Drip tray City Water... - Page 16 ATMOSPHERIC WATER GENERATOR The above structure and filtration system is for reference only, may change without prior notice. Recommended Timing for Filter Replacement (It might be verified according to different water consumption. The timing below is based on 10 liters water consumption per day.): 1.
-
Page 17: Cleaning
USER’S MANUAL cold tank and bottom tank as well, to ensure that your unit will always produce the cleanest and purest drinking water effectively. 4.1. Cleaning 4.1.1. Cleaning of Air Filter Please clean air filter regularly according to the air pollution situation in order to ensure proper air supply. Take off air filter and rinse in clean water or blow in the air to remove dirt and then replace back after natural drying .(as shown in diagram 4.1.1-1，4.1.1-2,4.1.1-3). - Page 18 ATMOSPHERIC WATER GENERATOR 4.1.2. Cleaning of Bottom Tank ① Unplug the power cord; Detach the panel ② pull out the PIN of water level sensor, and unplug the water outlet pipe and reflux pipe , then take out bottom tank (diagram 4.1.2-2,4.1.2-3,4.1.2-4); ③...
-
Page 19: Sterilization
USER’S MANUAL 4.2. Sterilization The brand new machine should be sterilized after one week service. 4.2.1. Sterilization solution: Prepare a 70 Liter clean container and mix 60 liters of clean water with 0.36 liter of sterilization liquid (30% hydrogen peroxide sterilization liquid) Formular: ρ... -
Page 20: Replacement
ATMOSPHERIC WATER GENERATOR 4.2.5. Fill city water into bottom tank. Turn on the unit and have it running automatically till top tank is full of water; 4.2.6. Touch the “ ” icon and then continue touching “ ” icon to unlock then touch the “... - Page 21 USER’S MANUAL ② Replace carbon filter : Pull out inlet tube of carbon filter and take out the filter from the clip ,then replace with a new filters;(diagram 4.3.1-3, 4.3.1-4). Then put it to its original place . ③ Replace RO membrane: Take out the carbon filter first (4.3.1-5), and take out the RO casing , Then pull out pure water outlet tube and unscrew the RO casing (diagram 4.3.1-6), replace with a new filter and put all parts back.
- Page 22 ATMOSPHERIC WATER GENERATOR 4.3.2 Replace the Top Tank UV After the machine operate for a period of time, the UV light may break. There will be a warning beep sound , the UV light has to be replaced. ① Unplug power cord; ②...
-
Page 23: Attention
USER’S MANUAL 5. ATTENTION 5.1. It is recommended to dispense not less than 3 liters of water every day. 5.2. If hot water is not dispensed for a long period, it is recommended to turn on heating process and keep hot ℃~ 93℃... - Page 24 ATMOSPHERIC WATER GENERATOR UV is not working, replace with new bulb by following steps in REPLACEMENT. Problem Two: The UV2 warning icon “ ” blinks and REP-R-UV showed in the screen with three short beeps. Solution: Check the ultraviolet device at cool water outlet to make sure the bulb is lit and all wirings are correct. If the UV is not working, replace with new bulb by following steps in REPLACEMENT.
- Page 25 USER’S MANUAL Problem Seven: There is burning smell from the machine and meanwhile hot temperature indication has exceeded the preset. Solutions: Unplug power cord from electrical outlet. Stop draining immediately if you are on draining operation from the back. Wait and continue draining until hot temperature is normal.
- Page 26 ATMOSPHERIC WATER GENERATOR Make sure that the power voltage is not too low or too high. Make sure that the internal booster pump is working well. Make sure that the water lines are not blocked and water flow is smooth. Make sure that the unit is placed in good ventilation condition, and the air filter net is cleaned regularly to ensure the free air flow.
-
Page 27: Ⅸ. Technical Specifications
USER’S MANUAL Ⅸ. TECHNICAL SPECIFICATIONS Model EA-200 Voltage 和 Frequency 220V/50Hz Input power 4.5KW Compressor wattage 2.6KW Heating wattage 1.6KW Cooling wattage 125W Fan wattage 250W Working temperature 15-38℃ Working humidity 45-95% Noise <65db Weight 260kg Size 80*70*170cm Water storage capacity Water production capacity （Humidity：...
