  • Page 1 SONOSAX SX-ST / SX-VT USER MANUAL PROFESSIONAL MIXING CONSOLE Audio equipment manufacturer SONOSAX SAS S.A. Ch. de la Naz 38 CH-1052 Le Mont s/Lausanne SWITZERLAND Tel: +41 21 651 0101 Fax: +41 21 651 0109 Web: www.sonosax.ch www.sonosax.com Email: sonosax@sonosax.ch Version: DOC-1.2...

  • Page 2: Table Of Contents

    AC Power Mode 2.4.1 Operating voltage switch... 10 OPERATING INSTRUCTIONS ...10 Switching ON your SONOSAX SX-ST / SX-VT mixer ... 10 Using an External DC Power Supply... 10 Battery Test ... 10 Low Battery Alarm ... 10 Automatic changeover of power source MIC / LINE INPUT MODULE...11...
  • Page 3 Monitor Source Selector ... 26 7.6.2 Monitor Mode selector ... 26 7.6.3 Phones Level 1 to 3 ... 26 Communication and Private Lines ... 26 SX-ST / SX-SV User Manual ... 16 ... 16 ... 17 ... 21 page 3...
  • Page 4 Master Auxiliary sends 1 to 4 ... 27 7.8.3 Peak Level Meters ... 27 7.8.4 P/A push buttons... 27 7.8.5 P/A Led's... 27 Talkback / Off / Return → switches... 27 7.8.6 SPECIFICATIONS...28 SX-ST / SX-SV User Manual page 4...

  • Page 5: Introduction

    25 years of experience have helped us to develop and build this mixer which is designed to last a minimum of 12 to 15 years. The reliability of the SONOSAX SX-ST or SX-VT is due to a high-tech design, the choice of the best components available, a meticulous hand assembly and a severe quality control.

  • Page 6: General Description

    SX-ST10, for up to 10 input modules, or up to 9 inputs and one Digital or Recorder module The SX-ST series being fully modular you can purchase with a few number of modules and add more modules or options at a later date.

  • Page 7: Installation

    Do not use the SX-ST / SX-VT console and its power supply near water, avoid moisture. • Keep the SX-ST / SX-VT console and its power supply away from heat sources such as radiators or other devices that produce heat.

  • Page 8: Battery Power Mode (Sx-St Series Only)

    SX-ST without using any other tool. WARNING: Never leave discharged batteries in your SX-ST. Make sure that your SX-ST only contains rechargeable NiCd or NiMH batteries before charging. When using dry cells, use only professional alkaline batteries to ensure optimal autonomy.

  • Page 9: Closing The Battery Compartment

    2.5A. The average power consumption is approximately 2A. The SX-ST series is supplied with an auto-ranging power supply 100 to 240 VAC 50 or 60 Hertz, that can be used worldwide without modification or setting changes.

  • Page 10: Ac Power Mode (Sx-Vt Series Only)

    The internal DC/DC converter circuitry is designed to automatically changeover between the internal batteries and the external DC power supply. You do not need to power OFF the SX-ST to change the power source. While powering up the mixer, when both the external DC power supply is connected and the internal batteries are installed, the internal DC/DC converter will first connect to the external DC power supply even if the external DC voltage is lower than the battery pack voltage.

  • Page 11: Mic / Line Input Module

    For ages this type of circuit has been used for analogue recording and nowadays The new SONOSAX SX-ST & SX-VT input stages do not reduce the microphone level before amplification. Instead we control the amount of amplification and therefore no additional noise is introduced by this method.

  • Page 12: Input Select Switch

    Caution must be taken when equipments other than a condenser microphone is connected to the 25pin Sub-D. : The SX-ST / SX-VT mixers do not provide with T12 and P12 voltage supply. Some 48V phantom to NOTE T12 or P12 adapters are available on the market 4.3 ∅...

  • Page 13: Lf Cut And Equalizer

    4.5 LF Cut and Equalizer The SONOSAX SX-ST / SX-VT series input module is equipped with a powerful filtering and equalization section. Its design is derived from our previous model SONOSAX SX-S on which the efficiency and sonic integrity have been well proven in practice for decades.

  • Page 14: Mix Busses 1 To 8 Assignment

    4.7 AUX Sends 1 to 4 The SX-ST / SX-VT mixers provide with 4 Auxiliary Sends mix busses. AUX 1 to 4 are used to create mixes for headphone cueing, effect sends, stage monitor mixes and all kinds of different sub-mixes.

  • Page 15: Limiter ( Non Vca Version Only )

    The input stage in the SX-ST / SX-VT is having such a significant headroom that it is normally not necessary to reduce the input gain. However, when the ambiance sounds become more silent, it may be necessary to increase the level so much that the traditional +12dB fader gain is not enough.

  • Page 16: Channel Power Switch (Sx-St Series Only)

    This Led will light ON only when the compressor becomes active and turns OFF when the compressor is inactive, depending if the signal level is equal to or higher than the threshold point. SX-ST / SX-SV User Manual (SX-ST series only)

  • Page 17: On Air Signaling ( Sx-Vt Serie Only )

    The Mute function can also be activated by toggeling the On/Off button, providing that the fader is moved up. This function is used by DJ's and operators that need to talk into the program material to avoid feedback trough the control room loudspeakers SX-ST / SX-SV User Manual page 17...

  • Page 18: Stereo Line Input Module

    "Pre Fader" is always Pre VCA. Please keep in mind that the Balance L / R potentiometer is part of the VCA circuitries and therefore all Post Fader signal are affected by the Balance. SX-ST / SX-SV User Manual page 18...

  • Page 19: Left & Right Gain Control

    When an overload occur while the meters are set to Dot mode, all led's turn on NOTES:- soldering jumpers S13 & S14 selects whether the Peak Meters are assigned Pre or Post Fader SX-ST / SX-SV User Manual page 19...

  • Page 20: Channel Fader

    NOTE: By implementing jumper S11, this Led will turn ON to indicate the OFF (or MUTE) status. This status can be displayed on a remote control panel for a better global view. ( optional on SX-VT only) SX-ST / SX-SV User Manual assign the channel to Odd busses Post Balance...

  • Page 21: Remote

    5.12 VCA's Group Selector The VCA group selector works the same way as on the Mic/Line input with VCA. Please refer to this section for detailled informations SX-ST / SX-SV User Manual ( optional on SX-VT Series only) page 21...

  • Page 22: Channels A/D Converter

    6. 8 CHANNELS A/D CONVERTER With the optional 8 channels 24 bits A/D converter, the SX-ST / SX-VT series provide with 8 digital outputs, combined in 4 AES/EBU pairs available on a 25pin Sub-D connector. The 3 position switches "IN 1 MIX" to "IN 8 MIX" select which sources are routed to the...

  • Page 23: Master & Monitoring Module

    7. MASTER & MONITORING MODULE SX-ST / SX-SV User Manual page 23...

  • Page 24: Meters

    When a channel is turned ON, the On Air and/or the Mute functions will be activated as soon as the Channel Fader is opened. The On Air and Mute signaling Led's will light On accordingly. For detailled information, please refer to the corresponding section in the Input modules chapters SX-ST / SX-SV User Manual page 24...

  • Page 25: Talkback/Slate And Oscillator

    7.5 Returns 1 to 8 A 25 pin Sub-D "Return" receptacle is available to connect up to 8 "Return" to the SX-ST / SX-VT mixer. It can be used to monitor and/or assign and re-mix the return of a multi-track recorder or any external lines to any of the Groups or Auxiliary sends.

  • Page 26: Monitoring

    Set the level of the corresponding monitor output (1 to 3) from - infinite (Mute) to +15 dBu 7.7 Communication and Private Lines The SX-ST / SX-VT offers three independent communication systems: a main COM for general purposes and 2 full duplex Private Lines used for communication within the 2 COM : talk to all communications lines, incl.

  • Page 27: Groups And Aux Master Sections

    Main or Aux mix bus Middle OFF position: No assignment to mix bus. Right → RET position: assign the Return bus to the Main or Aux mix bus SX-ST / SX-SV User Manual page 27...

  • Page 28: Specifications

    Overall THD+N : Main Level meters: LED's Level indicators : Nominal output level : SX-ST / SX-SV User Manual 10Hz to 200kHz ± 0.5dB 20Hz to 200kHz ± 0.1dB -128dBu ( 20Hz to 200kHz - 150 Ω source @ 60dB gain )
  • Page 29 Direct Output Level: Insert Output Level (optional) : Insert Return Level (optional) : Limiter : Compressor (VCA version) : SX-ST / SX-SV User Manual electronically balanced 6.8kΩ , linear from 10 Hz to 200 kHz standard +48V (phantom power) 60dB...
  • Page 30 Level : Distortion THD+N : Slate/Comm Mic Input Input type: Input Gain: Mic powering: SX-ST / SX-SV User Manual electronically balanced <50•. +6dBu or +4dBu depending on global nominal level setting +25dBu ( +22.5dBm Z-load 600 ) unweighted 20Hz to 22kHz -1xx dBu -100.0dBu...
  • Page 31 © 2003 SONOSAX SAS SA, Ch. de la Naz 38, 1052 Le Mont s/Lausanne, Switzerland. Phone: +41 21 651 0101, Fax: +41 21 651 0109, Email: sonosax@sonosax.ch Web: www.sonosax.ch SX-ST / SX-SV User Manual or 14,4V nominal with 12x LR20 (D) 1.2V NiCd or NiMH accumulators 409mm x 437mm x 74mm (16.10’’...
