LED's work 700320 Operating Manual

Technical specifications

Art no.
Total output (W):
(working light/flashlight)
Luminous flux
Charging time (h):
(working light/flashlight)
Burning time
Protection class:
Input voltage (V DC):
Warm up time (s):
Switch cycles:
LED lifetime (h):
Colour temperature (K):
Colour Rendering Index:
(working light/flashlight)
Beam angle
Battery

Packaging contents:

1x Rechargable Multi-Function Light
1x 230 V USB power supply
1x 12 ...24V USB car adapater
1x USB Charging cable
1x Operating manual
Important: please read these instructions carefully. Note the
safe operational requirments, warnings and cautions, use this
product correctly and with care for the purpose for which it is
intended.Failure to do so may cause damage and/or personal
injury and will invalidate the warranty. Please keep instruc-
tions safe for future use.
1. SAFETY INSTRUCTIONS
1.1. GENERAL
• Ensure the worklight is correctly charged before initial use.
• DO NOT cover or block the lens during use.
• DO NOT shine directly into your, other person's or animal's
eyes.
• DO NOT allow children to use the worklight
• DO NOT handle or move the worklight whilst it is being
charged.
• DO NOT use the worklight if you suspect that the battery
or the worklight casing is damaged.
• Ensure replacement batteries are genuine batteries of the
same rating.
• Ensure the worklight is unplugged and allowed to cool
before attempting any cleaning or replacement.
• When not in use, store the worklight in a safe, dry, child-
proof location.
700320-MAN-ML-2017100201-SHA.indd 3
LED's work
700320
2
(lm): 200
~ 3-4
(h): ~ 3
IP20
5V 1A (Micro USB)
<1
30.000
30.000
6.500
Ra>70
: 70°
Li-Ion 3,7V 1.800mAh 6,66Wh

1.2 BATTERY SAFETY

WARNING! To reduce the risk of burns or fire:
• DO NOT attempt to open, disassemble, modify or service
the battery.
• Ensure the charger is switched off and disconnected from
the worklight before attempting to open the lamp unit.
• DO NOT expose to temperatures above 40 °C
• DO NOT crush, puncture, short external contacts or dispose
of in fire or water.
• Replace only with the batteries designated for this product.
• Dispose of the old batteries in accordance with local
authority battery regulations. DO NOT dispose of with
regular refuse.
• If the electrolyte in the cells contacts the skin, wash thoro-
ughly with soap and water.
• If the electrolyte in the cells gets into the eyes, rinse
thoroughly with cool water and seek immediate medical
attention.
1.3 Electrical safety
Use only the supplied mains charger plug for connecting work-
light to the mains power supply.Only use the supplied adaptor
for connecting to a vehicle 12V -24V accessory socket.
Warning! It is the user's responsibility to read, understand and
comply with the following electrical instructions: You must
ensure the risk of electric shock is minimized by the installa-
tion of appropriate safety devices. An RCCB (Residual Current
Circuit Breaker) should be incorporated in the main distributi-
on board. We also recommend that an RCD (Residual Current
Device) is used with all electrical products, particularly porta-
ble equipment which is plugged into an electrical supply not
protected by an RCCB.
You must also read and understand the following instructions
concerning electrical safety.
You must ensure that you:
• Inspect the charger plug,cable and connector for wear and
damage to ensure items are safe before connecting to the
mains power supply. If worn or damaged DO NOT use.
• Check cables are always protected against short circuit and
overload.
• Important:Check that the voltage marked on the charger
plug is the same as the power supply to be used.
• Uncoil the cable between charger and the worklight.
• DO NOT pull the charger plug from the mains socket by
the lead.
• DO NOT use any other type of charger with this product.
• DO NOT place the connector into any area of the worklight
except the correct jack inlet socket.
• DO NOT try to take the charger plug apart.
• DO NOT use the charger plug to charge or power any other
electrical item.
• DO NOT get the charger wet,or use in wet, damp condi-
tions (for indoor use only).

2. INTRODUCTION

2W (4x 0,5 watt SMD) rechargeable worklight, to be used as an
inspection lamp or as a power bank to recharge a (mobile) de-
vice. One 360 degree swivel hook, strong magnet in base. Base
pivots 180 degrees, supplied with 230 V mains USB charger and
12-24V USB car charger.

3. OPERATION

3.1 CHARGING

Warning! Ensure that you read, and fully understand the safety
instructions before use.
GB Operating Manual
3.1.1 Charge the batteries before use.
Important: Ensure the worklight is turned „Off" while char-
ging. Failure to do so will damage the charger plug/vehicle
plug.
3.1.2 Connect the charging plug into the charging socket, which
is located on the rear of inspection lamp. Connect the 230V
charger or 12V-24V DC charger to a power supply.
Charging indicators on back of lamp
1: Red indicator LED on: lamp is charging
2: Red indicator LED off: lamp fully charged
3: Green indicator LED on: fully charged
4: Green indicator LED flashing: Power Bank function
3.1.4 Disconnect the charger from the worklight when it is fully
charged.
USB output (Power Bank)
A built-in chip automatically controls the USB Charging-port in
the bottom USB hole of the lamp. When a device is plugged in,
The charging starts and once the plug is pulled out, charging
(e.g. mobile phone/tablet) stops.
3.2 OPERATTION
Caution! Never shine the LED light directly into your or any one
else's eyes.
3.2.1 Press the on/off switch to turn the lamp on and off)

4. MAINTENANCE

Keep the worklight clean from dirt and grease, using a damp
cloth. Do not submerge in water.
