MaxLite 73683 Installation Instructions

4”, 6”, 8” and 9” led architectural downlight

Operating Instructions

MaxLite

4", 6", 8" and 9" LED ARCHITECTURAL DOWNLIGHT

INSTALLATION INSTRUCTIONS

General Safety Information

• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions,

and other hazards read all warnings and instructions included with and on the fixture box and all fixture labels.

• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general precautions.

• Commercial installation, service and maintenance of luminaires should be performed by a qualified licensed electrician.

• For Residential installation: If you are unsure about the installation or maintenance of the luminaires, consult a qualified

licensed electrician and check your local electrical code.

• DO NOT INSTALL DAMAGED PRODUCT!

• This fixture is intended to be connected to a properly installed and grounded UL listed junction box.

WARNING:

• Risk of Fire - Supply conductors (power wires) connecting the fixture must be rated minimum 90℃. If uncertain consult an

electrician.

• Risk of fire or electric shock. LED Retrofit Kit installation requires knowledge of luminaires electrical systems.

• Risk of Fire/Electric Shock - If not qualified, do not attempt installation. Contact a qualified electrician.

CAUTION:

• For your safety read and understand instructions completely before starting installation.

• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.

• Before attempting installation, check your local electrical code, as it sets the wiring standards for your locality.

NOTES:

• If luminaire (fixture) is to be switched from a wall switch, make sure black power supply wire is connected to the

switch. DO NOT connect the white supply wire to the switch.

• Make certain no bare wires are exposed outside the wire nut connectors.

• Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.

Illustrations on the manual are for installation purposes only. It may not be identical to the fixture purchased.

Architectural Downlight Fixtures

Page : 1

REV: 6/22/2015

Table of Contents

Do you have a question about the 73683 and is the answer not in the manual?

Page 1 Operating Instructions Architectural Downlight Fixtures ® MaxLite 4”, 6”, 8” and 9” LED ARCHITECTURAL DOWNLIGHT INSTALLATION INSTRUCTIONS General Safety Information • To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions, and other hazards read all warnings and instructions included with and on the fixture box and all fixture labels.
Page 2 Operating Instructions Architectural Downlight Fixtures ® MaxLite 4”, 6”, 8” and 9” LED ARCHITECTURAL DOWNLIGHT INSTALLATION INSTRUCTIONS Figure 2. INSTALLATION IN NEW CONSTRUCTION 1. Locate center of fixture opening in the ceiling sheetrock and cut a 6-1/2" diameter hole. Note: Cut a 5-1/8" (for 4" fixtures), 8-1/8" (for 8"...
Page 3 Operating Instructions Architectural Downlight Fixtures ® MaxLite 4”, 6”, 8” and 9” LED ARCHITECTURAL DOWNLIGHT INSTALLATION INSTRUCTIONS 4. Connect supply wires to fixture wires and insulate with proper size wire INSTALLATION IN SUSPENDED CEILINGS nuts (not provided). 1. Locate fixture proposed fixture center in the ceiling tile and cut a a.) Connect incoming ground wire (green or bare) to fixture ground...
