COMMERCIAL INDUCTION COOKER
Installation and Operating Instruction Manual
EIDS-18
EIDS-18C
EIDS-34
Model
Voltage
Frequency
EIDS-18
120V
EIDS-18C
EIDS-34
240V
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this SPECTRUM commercial equipment. When used as intended, and with
proper care and maintenance, you are sure to experience years of reliable operation from this equipment. To ensure
best results, it is important that you read and follow the instructions in this manual carefully. It is important to
keep these instructions in a safe place for future reference.
Power
Amperage
1800W
15 A
60 Hz
3400W
14 A
ELECTRIC DROP IN
EIDS-TR
Overall Dimensions
Plug Type
Length
Depth
NEMA 5-15P
12.6"
13.4"
NEMA 5-20P
(320mm)
(340mm)
NEMA 6-20P
Optional Accessory
Stainless Steel Trim Ring
Weight
Height
3.9"
11 lbs
(100mm)
5 kgs
Advertisement
Table of Contents
Related Manuals for Winco EIDS-18C
Summary of Contents for Winco EIDS-18C
-
Page 1: Specifications
ELECTRIC DROP IN COMMERCIAL INDUCTION COOKER Installation and Operating Instruction Manual Optional Accessory EIDS-18 EIDS-18C EIDS-34 EIDS-TR Stainless Steel Trim Ring Overall Dimensions Model Voltage Frequency Power Amperage Plug Type Weight Length Depth Height EIDS-18 NEMA 5-15P 120V 1800W 15 A 12.6"... -
Page 2: Warnings
L'USINE DEVRA EFFECTUER TOUT L'ENTRETIEN ET LES AND REPAIR. BEFORE DOING ANY MAINTENANCE RÉPARATIONS. AVANT DE FAIRE TOUT ENTRETIEN OU OR REPAIR, FOLLOW SERVICE SET UP ARRANGEMENT RÉPARATION, VEUILLEZ CONTACTER WINCO. ON PAGE 11. Introduction Immediately Inspect for Shipping Damage All containers should be examined for damage before and during Congratulations on the purchase of the SPECTRUM™... -
Page 3: Table Of Contents
Electric Countertop Induction Cooker Table of Contents Specifications ..................1 Warnings ....................2 Introduction ..................2 Packaging .................... 3 Installation ..................4 Operation .................... 6 Cleaning, Care & Maintenance ............7 Safety ....................7 Troubleshooting ................. 8 Service & Repair .................. 8 Exploded View .................. -
Page 4: Important Safeguards
The cord should be located so that it will not drape over the adjustment. countertop or tabletop where it can be damaged or moved unintentionally. 6. The use of accessory attachments not recommended by WINCO may cause fire, electric shock or injury. Proper Grounding · Mise à la terre correcte WARNING... -
Page 5: Installation
Installation 1. Drop in unit may be installed as follows: Above the counter surface / Flush to the counter surface / With a stainless steel trim ring (EIDS-TR sold separately) 2. Layout and cut holes in the cabinet per the template provided for the cooker and control panel, based on the installation type (see #1) 3. -
Page 6: Operation
C. Timer Mode Button D. Adjustment Button "+" E. Power Regulator Rotary Knob Note The WINCO ® Commercial Drop-In Induction Cooker has two different cooking modes: (C) Timer Mode and (E) Power Mode. Note Induction Cooker requires induction ready cookware. -
Page 7: Cleaning, Care & Maintenance
Le liquide pourrait contacter the electrical components avec les composants électriques et causer • If the power cord is damaged, it must be replaced by a WINCO® and cause a short circuit or an un court-circuit ou un choc électrique. -
Page 8: Troubleshooting
Parts protected by the manufacturer or its agent are not to be adjusted by the installer unless the installer is an authorized service agent. If you have any questions or problems DO NOT send unit to WINCO® without first contacting our customer service department. -
Page 9: Exploded View
Exploded View & Parts List MODELS: EIDS-18 / EIDS-18C / EIDS-34 Description EIDS-18 EIDS-18C EIDS-34 Flat Glass Plate EIDS-P1 EIDS-P1 EIDS-P1 Flat Coil EIDS-P2 EIDS-P2 EIDS-P3 Fans in Main Board EIDS-P4 EIDS-P4 EIDS-P4 Main PCB Board EIDS-P5 EIDS-P5 EIDS-P6 Silicone Foot... -
Page 10: Electrical Circuit Diagram
Electrical Circuit Diagram MODELS: EIDS-18 / EIDS-18C / EIDS-34 POWER SUPPLY 120V / 240V 60Hz COIL FUSE THERMAL LINK MAIN BOARD SENSOR Control board This circuit diagram has been provided to assist qualified electricians; only SPECTRUM™ service agents or qualified electricians should carry out repairs if required. -
Page 11: Limited Warranty
Limited Warranty WARRANTY SERVICE WINCO® warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within To initiate warranty service contact: EquipService@wincous.com North America and subjected to normal use, is free from defects in or call: 973-295-3899 material or workmanship for a period of 1 year. - Page 12 Models: EIDS-18 / EIDS-18C / EIDS-34 www.wincous.com...
