Summary of Contents for MIRAART TRAUMSCHWINGER Babyschwinger
- Page 1 Your manual BaByschwinger & Kinderschwinger...
-
Page 2: Table Of Contents
inhalt introduction ....................4 BaByschwinger/ Kinderschwinger ..........6 2.1 BABYSCHWINGER ................6 2.2 KINDERSCHWINGER ................8 Prerequisites ....................9 individual Parts ..................10 assembling the height adjustment ............12 5.1 Prepare the threaded rods ..............12 5.2 Insertion of threaded rods (1) ............12 5.2 Inserting the threaded rods (2) ............ - Page 3 Montage Footboard (optional) ..............23 8.1 Insert vertical strut ................24 8.2 Insert side strut ................... 24 8.3 Adjusting the foot part ................ 25 8.4 Mounting of the foot ................26 Usage of your BaByschwinger/ Kinderschwinger ..... 26 9.1 Maintenance ..................27 9.2 Cleansing ...................
-
Page 4: Introduction
introduction The first step in a dreamlike life Strange in the world of adults, just missing babies in the first months many familiar from the mother‘s belly movements. In BABYSCHWINGER Experience familiar: Swinging movements in which the little ones gently slip into in new dream worlds. The gentle rhythm of circular or spiral vibrations leads to a feeling inner peace, and provides a natural way for the breakdown of Stress. - Page 5 SAFETY NOTICE Please make sure that all packaging removed and keep this away from your child. Use only tested by us and recommended accessories and spare parts. Our TRAUMSCHWINGER - hanging chairs are resting and relaxing furniture. They are not for using as trainers or play area. If you notice damage of the material (e.g.
-
Page 6: Babyschwinger/ Kinderschwinger
BaByschwinger/ Kinderschwinger With these models, you should adjust the height of the baby swing so that your child can swing freely just above the ground. In addition, it´s recommended interpreted the ground with a damping material (1.5 m wide). Note that hanging chairs are not a cradles rocking or any toys equipment. - Page 7 If the child sit up, kneel or pull itself, May no longer the baby chair be used as infant cot. Then operate it by simply into a children high chair by changing the side woods. The necessary position of the side wood in the second pix illustrates.
-
Page 8: Kinderschwinger
2.2 Kinderschwinger CHILDREN‘S CHAIR is suitable for children from 3 to about 10 years old. It is optionally available with a separate foot part. -
Page 9: Prerequisites
Prerequisites For your BABY SWING or CHILDREN SWING you need your building conditions and use wishes adequately secured. You can directly through MIRA - ART the standard fixings for our products receive - we will gladly advise you. Basically, you have the choice between a ceiling mounting, attachment to a beam or the use of a stator. -
Page 10: Individual Parts
individual Parts For an overview of the delivery of BABYSCHWINGER/ KINDERSCHWINGER you get in the two following pictures and tables. Weaving net in cotton Rope bag universal Wooden transverse strut Wooden side strut, 2 piece Only deliverable in versions: „Set“ or „Set Plus“... - Page 11 All items shown on this page are only included when you buy a TRAUM- SCHWINGER in the version „Set“ or „Set plus“. For the others versions this can be purchased as an accessory item. 1) Holzwange (x 2) 6) Edelstahl-Buchse (x 2) 2) Edelstahl-Einleger (x 2) 7) Innensechskantschlüssel 3) Karabiner...
-
Page 12: Assembling The Height Adjustment
assembly of the height adjustment The first portion for mounting your TRAUMSCHWINGER (dream swing) forms of assembling the supplied height adjustment. For this, you need the items from the box of height adjustment and the swivel. The required tool (an Allen key) is enclosed. -
Page 13: Inserting The Threaded Rods (2)
5.2 inserting the threaded rods (2) 5.3 Attach the first stainless steel inlays Now place the free hand on the Take one of the stainless steel inlays. three round nuts to prevent it from A colored sticker marks the side of slipping and rotate with your hand the stainless steel inlays, which should the wooden cheek. -
Page 14: Attach The Stainless Steel Bushings
5.4 attach the stainless steel bus- 5.5 inserting the steel pin into the hings wooden wedge On the threaded rod, into the top Now take the wooden wedge and the of the triangular, wooden panel steel pen into hand. Run the steel pin insert the stainless steel socket with through the hole in the extent of the a groove. -
Page 15: Placing The Wood Wedge Over The Stainless Steel Inlay
5.6 Placing the wood wedge over 5.7 attach the second noble steel the stainless steel inlay inlay Place now the wooden wedge, Take the second stainless steel which is inserted already with the inlay in your hand. Grasp the imported steel pin with smooth sides stainless steel inlay so, that on the already mounted stainless with the label marked side facing... -
Page 16: Attaching The Second Wooden Panel
5.8 attaching the second wooden 5.9 screw down and tighten the panel round nuts Take the second wooden panel. Now screw the three remaining With a colored sticker marked side round nuts with the three threaded of the wooden wedge must lie on rods, which are placed in the holes of the second stainless steel inlay with the second wooden panel. -
Page 17: Insertion Of The Carabineer
5.10 insertion of the carabiner 5.11 Finished height adjustment Take the supplied carabiner and Please use both supplied Allen keys place it in the stainless steel bush to make sure that all metal parts are with the groove (on the upper side of properly tightened. -
Page 18: Netting Connect With The Height Adjustment
connecting the netting with the height adjustment Next you connect the netting of your BABYSCHWINGER/ KINDERSCHWINGER with the height adjustment. Due to the fact that you have to spread the netting in front of you, we recommend you put a blanket on the floor. The height adjustment you should place next to you. -
Page 19: Insert The Rope Ends And Interconnecting
6.2 insert the rope ends and jam them On delivery, the track ropes can be twisted in themselves and each other, because of material and manufacturing conditions. Prior to inserting the rope ends in the height adjustment, you need to make sure that the support ropes are not twisted in itself and into each other. - Page 20 Now drag with your left hand the rope Now take the height adjustment so pair trough the right hand, without to in your right hand, the wood wedge twist the ropes. If you reach the end almost half inserted into the height of the rope, grab around.
-
Page 21: Netting Hang Up And Span
netting hang up and span In this section you will finished assembling your BABYSCHWINGER/ TRAUM- SCHWINGER. For this you will need the height adjustment connected with the netting, the vertical wood and the two side wood, the rope bag and a ladder. 7.1 netting to hang up with height adjustment Hang the connected height adjustment with the swivel into the prepared (resp. -
Page 22: Insert Side Strut
wrOng righT saFeTy nOTice If the suspension ropes lay on each other or are twisted, this can increase wear of the ropes through damage to the rope surface. Do not use sharp objects to the rope pair to push into the recess. This may damage the surface of the rope, and can interfere with the carrying capacity of the cables. -
Page 23: Attaching The Rope Bag
7.4 attaching the rope bag As a final step you bring the rope bag between the two rope pairs above the cross of wood. Hang on the universal case with the two adjustable straps. For the motive bags (sun and sheep) you should made a knot in order to attach the cords. -
Page 24: Insert Vertical Strut
8.1 insert vertical strut (conjunction) Spread the netting in front of you so, that the label is in the upper right corner. One of the supplied wooden struts is longer than the other two. This is the vertical conjunction wood. righT wrOng Ensure that the ropes running down... -
Page 25: Adjusting The Foot Part
8.3 adjusting the foot part Following pull the rope on the other Take the rope as in Fig. 1, and pull a side. loop of approximately 50 cm in length (depending on the mounting height of the hanging chair). te: You can adjust the length of the Pull on the rope end as shown in FIG. -
Page 26: Mounting Of The Foot
8.4 assemby of the foot part Place the loop behind the carabiner on the groove connection. If you have no height adjustment, put the loop of the foot part simply in your carabineer. note With the height adjustable footrest you can easily adjust the height with only a few gras- ps. -
Page 27: Maintenance
9.1 Maintenance The natural materials used for the BABYSCHWINGER/ KINDERSCHWINGER (wood and cotton) are untreated and ideal for indoor use. For outdoor usage it should be noted that the untreated materials are not durable and moisture are weather resistant. Avoid that the netting and the untreated wood are exposed to humidityand rain. We recommend that you remove the hammock chair and optionally place it to dry in a warm, ventilated place. -
Page 28: Washing Instructions
9.3 washing instructions Prepare: First, remove the lateral and side struts and take out the TRAUMSCHWINGER. Loose the netting of the height adjustment. Spread the netting and lay the track ropes curled up on the netting. Fold the netting so that the support ropes completely enclosed with the netting. -
Page 29: Adjusting The Seat Height
9.4 adjusting the seat height With the height adjustment, you can personally setting the optimum seat height of your TRAUMSCHWINGER. We recommend to adjusting the seat height so, that the bottom edge of the netting rests in the knees when you are under the suspension point. To adjust the height you access with each of your hand the rope pairs below the height adjustment. - Page 30 enjoy...
- Page 31 For your notes...
- Page 32 MiraarT® GmbH Bünderstraße 21 33613 Bielefeld fon: +49 521 66545 mail: info@mira-art.de web: www.mira-art.de shop: www.traumschwinger.de...
