- Page 1 NETWORK INTERFACE BOARD HKSR-5804 INSTALLATION MANUAL 1st Edition...
- Page 2 Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement. HKSR-5804...
-
Page 3: Section 1 Installation
Section 1 Installation Purpose of this manual This manual is an installation manual of Network I/F Board HKSR-5804. This manual is intended for system and service engineers, so describes information regarding installation. Related manual Besides this installation manual, the following manual is available for HKSR-5804. - Page 4 Matching Connectors/Cables/Signal Inputs and Outputs When external cables are connected to the connector of this unit, the hardware listed below (or equiva- lents) must be used. Panel indication Matching connector (cable) Sony part No. Signal AUX INPUT A BNC 75 Z, MALE 1-569-370-12...
- Page 5 S3000 S1403 S1401 S5000 Ref. No Name Description Factory setting S900 Factory use S1000 Reset System reset S1001 — Factory use S1400 — Factory use S1401 — Factory use S1402 — Factory use S1403 — Factory use 1-3 (E) HKSR-5804...
- Page 6 ON : Start by program of boot S1401-2 to 8 Factory use S3000 SW A Factory use S3001 SW B Factory use S4500 SW C Factory use S4501 SW D Factory use S5000 PLD SW A Factory use 1-4 (E) HKSR-5804...
-
Page 7: Installation Procedure
Move the knobs to the outside to fix the upper lid Protrusion (front) assembly. 3. Remove the upper lid (front) assembly in the arrow direction. Square hole Knob Upper lid (front) assembly Knob Fixing screw Removal Installation 1-5 (E) HKSR-5804... - Page 8 3 x 6 Blank panel Connector panel assembly 7. Attach the network panel assembly of HKSR-5804 to the connector panel assembly with the screws that were used for the blank panel. 8. Pass the four coaxial cables of the network panel assembly one by one through the chassis.
- Page 9 Pass the connection cord (with modular plugs) through the two harness clamps and draw the other end up. Connection cord (with modular plugs) BVTT3 x 6 Portion A Portion A Harness clamps Connector panel assembly IF-1071 board BVTT3 x 6 1-7 (E) HKSR-5804...
- Page 10 CN700 on the MY-115 board. 3) Connect four coaxial cables to the MY-115 board. 4) Insert the HIF-46 board, and connect 13 coaxial MY-115 Board (HKSR-5804) cables. 5) Insert the DVP-43 board (HKSR-5802). 6) Insert the FC-91 board (HKSR-5001) and connect...
- Page 11 Slide the two knobs each to the outside. 3. Check that “INSTALLED” is displayed for the HKSR- 16. Confirm that the HKSR-5804 has been identified by 5804 board. the MAINTENANCE INFORMATION menu. (Refer to Section 1-4.) For more information on the maintenance mode, refer to Section 3 of the VTR Maintenance Manual Volume 1.
- Page 13 The material contained in this manual consists of information that is the property of Sony Corporation. Sony Corporation expressly prohibits the duplication of any portion of this manual or the use thereof for any purpose other than the operation or maintenance of the equipment described in this manual without the express written permission of Sony Corporation.
- Page 14 Printed in Japan Sony Corporation HKSR-5804 (SY) J, E 2008. 7 08 4-114-654-01 ©2008...
