ENGLISH
VIDEO DOOR PHONE SYSTEM

USER MANUAL

CALL
UNLOCK
TALK/MON
IN-USE
XT-ENG-692SDTD7-V2 10S1025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT692-SD and is the answer not in the manual?

Questions and answers

Summary of Contents for Xicom XT692-SD

  • Page 1: User Manual

    ENGLISH VIDEO DOOR PHONE SYSTEM USER MANUAL CALL UNLOCK TALK/MON IN-USE XT-ENG-692SDTD7-V2 10S1025...
  • Page 2: Parts And Functions

    1. Parts and Functions Home Screen Microphone CALL CALL button UNLOCK UNLOCK button Manual Monitor Intercom Multimedia TALK/MON TALK/MON button Monitor IN-USE LED indicator User Setup Close Memory Album Playback ? 09/30/2010 Thu.16:41 About Speaker Ventilation Vent Mounting Hook Connection Port DIPS 1 2 3 4 5 6 Mounting Hook...
  • Page 3: Answering A Door Call

    3. Operation Instructions 3.1 Answering a Door Call ● ● Press●the●CALL●button●on●door●station. ● ● The●monitor●rings,and●the●visitor's●image●will●be●seen●on●screen. Note:the●screen●turns●off●after●30●seconds●if●nobody●answers. ● ● Press●TALK/MON●Button●or●touch●● ● icon,●you● can● talk● with● the● visitor● for● 90● seconds.● During● CALL talking●state,●press●the●TALK/MON●Button●again● Standard UNLOCK Screen or●press●● ●●icon●to●end●the●conversation.●●If●the● TALK/MON Unlock IN-USE system●connects●two●or●more●Monitors,●pick●up●any● Talk Capture Monitor●,●the●others●will●be●automatically●shut●off.
  • Page 4: Basic Setup Instructions

    ● * Note:1.●Press●"CALL"●button●or●touch● ●again●to●redial.●●●2.●Touch●● ●icon●to●cancel● the●call. CALL CALL -Name List- UNLOCK UNLOCK [0001] Jim,Zhang TALK/MON TALK/MON Last Next [0002] Calo,Liu [0003] Jacko,Zhang IN-USE IN-USE [0004] Jana,Qiao Intercom Inner Call Direct Call by Namelist Guard Unit [0005] Hebe,Zhang Dial Close [0006] Tony,Li Number Home 09/30/2010 Thu.16:41...
  • Page 5: Ring Volume Setting

    ● ● Touch●the●screen●again●to●enter●the●main●menu.● then●touch● ● ●icon●to●enter●call● User Setup CALL tone●setting●screen,touch●Door●station●call●tone/ UNLOCK Carman Going Home Door Station TALK/MON Call Tone Ding Dong Congratulate intercom●call●tone/door●bell●call●tone,12●pieces● Rhythm of the rain Do Re Me IN-USE Happy Birthday For Elise ring●tones●will●be●displayed●,you●can●choose●a● Exit&Save Sonatine Jingle Bell Edelweiss Telephone Ring ring●tone●which●you●want,and●then●touch●...
  • Page 6: Monitor Time Setting

    CALL CALL UNLOCK UNLOCK Night Ring Night Ring TALK/MON TALK/MON Ring Night Ring Volume Volume Volume Volume IN-USE IN-USE Exit&Save Exit&Save Adjust + Adjust - Adjust + Adjust - Exit&Unsave Exit&Unsave 4.3 Monitor Time Setting ● ● Enter●home●screen●page(refer●to●4.1),thenTouch●● ●● ●icon●to●enter● Manual Monitor next●page.and●then●press●●...
  • Page 7 4.6 Monitor Parameter Setting How to enter the installation setting page Installation settings: [0010]#:Remove all remote control [0011]#:Add remote control H/W : DT14-CT a1.3 [8000]#:Set as master unit 0 [8001]#:Set as slaver unit 1 S/W: V17.11.418.00 [8002]#:Set as slaver unit 2 Manual Intercom Code Number:[----]...
  • Page 8: Unlock Mode

    How to set the monitor panel on In default mode,when receive a calling,the master and slave monitors will ring at the same time,and just the master monitor can display the image while the slave monitors can not.But the settings can be changed,you can set the master monitor and all the slave monitors to panel on at the same time when receiving a call, just input the code number of 8006 on each slave monitor.
  • Page 9: Built-In Memory And Sd Card

    5. Built-in Memory and SD Card This●Monitor●has●been●equipped●with●a●built-in●memory●(about●120●MB)●together●with●a●SD●card● reader.●Maximum●16●GB●SD●card●can●be●supported.● CALL UNLOCK TALK/MON IN-USE SD card ● ● The●monitor●can●play●photos●and●pictures. ● ● Photo●frame●function,●each●photo●playing●will●last●5●seconds,●More●pictures●in●the●SD●card,● longer●time●for●triggering●the●function,●●800●pictures●is●supported●in●inner●memory.●With●2G●SD● card,more●than●30000●pictures●can●be●supported. ● ● Must●use●T-views●album●software●tool●to●transform●the●JPG●format●photos●●took●by●digital● camera●to●TVS●format●photos●that●can●be●viewed●on●Monitor. ● ● The●captured●pictures●will●be●saved●in●a●folder●named●by●date,note●that●the●pictures●recording● every●day●will●be●saved●in●different●folders●which●automatically●generated●every●day. ● ● The●captured●pictures●in●the●built-in●memory●can●be●copied●to●the●SD●card,●and●●you●should● use●T-views●●memo●software●tool●to●convert●the●pictures●to●JPG●format●that●can●be●seen●on● the●computer.●(select●the●pictures(press●Ctrl+A●to●select●all)->>click●the●right●key●of●the●mouse● ->>choose●transfer●selected●to●JPG●item->>save●the●pictures●on●computer) ● ● When●the●built-in●memory●is●full,the●oldest●picture●will●be●deleted●to●make●room●for●new●record●. ● ● The●built-in●memory●can●be●formatted●by●the●Monitor,but●SD●card●cannot,you●should●format●the● SD●card●on●computer.●...
  • Page 10: Picture Recording

    5.1 Picture Recording CALL 00:03 Talking Both●Auto-Recording●and●Manual-Recording●are● Standard UNLOCK Screen available.and●Auto-Recording●is●default.●If●receive●a● TALK/MON Unlock IN-USE Call●,●after●3s,●the●monitor●will●record●automatically.● Talk Capture or●you●can●touch●● ● ●icon●to●record●the● Capture Recording... Home visitor's●image●manually. 5.2 Record times Setting You● can● setup● Memo● Options● to● choose● 1/4/8● pictures●memo.●If●4/8●was●chosen,●you●will●have● 4/8●shots●for●each●recording●operation,●every●1.5● seconds●catch●a●picture.● CALL Record times: [ 1 ] UNLOCK Touch●...
  • Page 11: Photo Frame

    5.4 Photo Frame 5.4.1 Playing Touch● ● icon●on●home●screen●to●play●the●photos.it●can●be●played●both●manually● Album and●automatically,use●your●fingers●to●slide●●right●or●left●on●screen●to●play●last/next●photo. 5.4.2 Playing time setting Touch●● ● icon●on●home●screen●to● Multi Media enter●next●page,●touch●● ● ●icon,a● Album Options digital●keypad●will●be●showed●on●the●screen,then● CALL Album time set UNLOCK min:[01] sec:[30] you●can●set●the●palying●time●by●touching●the●digital● TALK/MON IN-USE keypad● to● input● digitals● and● press● ●...
  • Page 12 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
