Q UI CK STA RT
GU I D E

Advertisement

loading
Need help?

Need help?

Do you have a question about the Lumi and is the answer not in the manual?

Questions and answers

Summary of Contents for Mei-cha Lumi

  • Page 1 Q UI CK STA RT GU I D E...
  • Page 3 TOUCH PANEL KIT CONTENTS 7-12 ASSEMBLY 13-16 OPERATION CARE INSTRUCTION WARRANTY...

  • Page 4: Touch Panel

    TOUCH PANEL: FRONT PROGRAM: PROGRAM: BROW LINER PROGRAM: PROGRAM: ON/OFF PEN A BUTTON PEN B SPEED (PULSE PER SECOND)

  • Page 5: Touch Panel

    TOUCH PANEL: BACK POWER BUTTON PEN A PORT PEN B PORT POWER FOOT PEDAL OUTPUT OUTPUT...

  • Page 6: Kit Contents

    KIT CONTENTS LUMI PAD POWER SUPPLY DEVICE POWER CORD...
  • Page 7 LUMI PEN LUMI PEN POWER CORD FOOT PEDAL STAND...

  • Page 8: Assembly

    ASSEMBLY CONNECT LUMI PEN POWER CORD TO END OF LUMI PEN. LUMI SYSTEM CAN ACCOMONDATE UP TO TWO PENS FOR DIFFERENT PROCEDURE USAGES. FEED LUMI PEN POWER CORD, POWER CORD AND FOOT PEDAL (OPTIONAL) THROUGH THE STAND.
  • Page 9 ATTACH CORDS TO THE BACK OF DEVICE. PEN A PORT PEN B PORT POWER OUTPUT FOOT PEDAL OUTPUT...
  • Page 10 TWIST AND LOCK STAND INTO THE BACK OF LUMI PAD. MATCH INDICATION MARK WITH THE LOCK SYMBOL AND TURN STAND COUNTER CLOCKWISE.
  • Page 11 CONNECT POWER SUPPLY UNIT TO THE DEVICE POWER CORD. PLUG INTO WALL ADAPTOR.
  • Page 12 PUSH 1:POWER BUTTON ON THE BACK OF DEVICE TO POWER ON. LUMI PANEL IN 2:STANDBY MODE.
  • Page 13 ATTACH ULTRA PRECISION NEEDLE TO LUMI PEN. LUMI DIGITAL DEVICE IS NOW READY TO USE!
  • Page 14 OPPERATION: TOUCH PANEL SELECT FROM EITHER A OR B LUMI PEN. SELECT PROGRAM FROM DISPLAY PANEL. TOUCH + TO INCREASE SPEED AND — TO DECREASE SPEED.
  • Page 15 TOUCH THE ON/OFF BUTTON TO START. SELECT BETWEEN A AND B TO SWITCH PEN. REPEAT STEP 3 TO 5 TO OPERATE.
  • Page 16 OPPERATION: PROGRAM PERSONALIZED SETTINGS SELECT EITHER LUMI PEN A OR B. SELECT PROGRAM FROM MENU. ADJUST SPEED.
  • Page 17 PRESS AND HOLD THE PROGRAM BUTTON FOR 3 SECTIONS UNTIL BEEP TO LOCK SETTING. CONFIRM SPEED AND PRESS ON/OFF BUTTON TO START.
  • Page 18 Lumi Digital Device is designed for micropigmentation purpose and for trained professional use only. Neither MEI-CHA or its a liates assume responsibility or liability for any injuries or damages, resulting, directly or indirectly, from the use of this product.

  • Page 19: Warranty

    WARRANTY MEI-CHA warrants the LUMI DEVICE for a period of ONE (1) YEAR and after the original date of purchase, against defects due to faulty manufacturing or material. If you discover a defect and notify MEI-CHA during the warranty period, MEI-CHA will repair or replace the machine free of charge.
  • Page 20 H ELLO @MEI- CHA .COM / + 1 949 788 088 2 / LA KE F O REST, CA @M EICHA _O FFICIAL # MA D EW I T HM EICHA MEI-CHA.COM...
