Enlogic Door Switch Sensor Installation Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

The Critical Component
LT0003400A20000000
Door Switch Sensor
Installation Guide
Enlogic Door Switch Sensor
SKU: EA9109
Enlogic's Door Switch Sensor is designed to send an alarm or notification signal
when the door on which is installed had been opened more than 10mm. This
provides added security. You can extend the length of the sensor cable up to 30.5
m (100 ft) using the RJ-45 coupling and standard CAT-5 cabling.
Note: The Enlogic Door Switch Sensor is only designed to connect to an Enlogic PDU or Inline
Energy Meter. Connecting it to another device may result in damage.
www.enlogic.com
LT-00034-A4
