Mambo AMP 10 User Manual

Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
This information is for guidance and applies to the standard 500 watt guitar combo.

Specification

500 Watt rms continuous power rating, 250 Watt rms with the internal speaker, plus an
•
additional 250 watt rms when used with an external 8 Ohm loudspeaker, an r.m.s. limiter
prevents power amplifier overdrive while allowing loud transients to be faithfully reproduced.
24 bit digital reverb, with depth and delay-time controls
•
hand-made birch ply cabinet
•
two guitar input jacks ,
•
line level input (3.5mm stereo jack) for MP3 / CD etc.
•
headphone output (3.5mm stereo jack)
•
European (230 V) or US (115V) mains voltage (specify when ordering)
•
Size and weight (approx.)
12" - 12.1 kg, 36 by 36 by 30 cm
•
10" - 8.1 kg, 31 by 31 by 25 cm
•
8" - 7.3 kg, 27 by 27 by 23 cm
•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mambo AMP 10

  • Page 1 European (230 V) or US (115V) mains voltage (specify when ordering) • Size and weight (approx.) 12" - 12.1 kg, 36 by 36 by 30 cm • 10" - 8.1 kg, 31 by 31 by 25 cm • 8" - 7.3 kg, 27 by 27 by 23 cm •...
  • Page 2 / normal / deep ; 3 way switch • the normal setting is the classic mambo amp sound deep setting has slightly more bass and less treble, more like a Polytone bright setting swaps the standard mambo tone control to a Fender AB763 circuit...
  • Page 3 clean / harmonic ; 2 way switch • the clean setting is pure and clean, very high headroom the harmonic setting is similar to a valve preamp, turning the guitar up and playing harder will produce more dynamic overtones. Use the gain control and guitar volume to get the best of this to suit your taste.
  • Page 4 There is a fuse fitted to the electrical inlet of the amplifier. Make sure the correct fuse is fitted. Never replace with a fuse with a higher Amp rating. Correct fuse ratings for the 500W rms mambo amp are; 4 Amp time-delay (T) fuse ( it's the same fuse type for US 115V and Europe 230V) Mains power cable colour coding The cable supplied uses European colour coding;...
