- Page 1 DS-1H05 Ethernet-over-Coax Extender User Manual...
- Page 2 Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to DS-1H05-T, DS-1H05-T/E and DS-1H05-R Ethernet-over-Coax Extender. This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice.
- Page 3 User Manual of Ethernet-over-Coax Extender Safety Warnings and Cautions Please pay attention to the following warnings and cautions: Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user.
- Page 4 User Manual of Ethernet-over-Coax Extender Power Cord Requirements: The connector that plugs into the wall outlet must be a grounding-type male plug designed for use in your region. It must have certification marks showing certification by an agency in your region. The connector that plugs into the AC receptacle on the power supply must be an IEC 320, sheet C13, female connector.
- Page 5 • Please use the power adapter, which is provided by normal company. The standard of the power adapter is DC12V/1A for DS-1H05-T and DS-1H05-R models, and DC12V/2A for DS-1H05-T/E model. • Please disconnect the power supply before installation or operation.
-
Page 6: Table Of Contents
User Manual of Ethernet-over-Coax Extender Table of Contents Chapter 1 Introduction ........................6 1.1 Overview ..........................6 1.2 Features ..........................6 1.3 System Connections ......................7 Chapter 2 Operation.......................... 8 2.1 Panel of the Transmitter ....................... 8 2.2 Panel of the Receiver ......................9 2.3 Configuring Coax Transmission Bandwidth ................ -
Page 7: Chapter 1 Introduction
Chapter 1 Introduction 1.1 Overview Adopting the newest Security Link Over Coax technology, the DS-1H05 Series Ethernet-over-Coax Extender can be used to transmit the network data and CVBS signal via coaxial cable to the remote device with low signal loss. -
Page 8: System Connections
User Manual of Ethernet-over-Coax Extender 1.3 System Connections Refer to the following figure for the typical system connections of the DS-1H05 Series Ethernet-over-Coax Extender: Transmitter Receiver Switch Analog Camera Management Center Network Camera Keyboard Monitor... -
Page 9: Chapter 2 Operation
Connect to 12 VDC power supply. Power LED Indicate red when the device is powered on. Coax Connect to DS-1H05-R for Coax transmission. Note: The DS-1H05-T/E supports PSE capability and can provide max. 12W power supply for the connected camera. -
Page 10: Panel Of The Receiver
CVBS analog video signal. 2.3 Configuring Coax Transmission Bandwidth You can use the DIP switch settings to configure the downstream bandwidth of the DS-1H05-T or DS-1H05-T/E module and the upstream bandwidth of the DS-1H05-R. Refer to the following table:... -
Page 11: Installation
User Manual of Ethernet-over-Coax Extender DIP Switch Transmitter 21 Mbps 25 Mbps 28 Mbps 36 Mbps Receiver 3 Mbps 4 Mbps 9 Mbps 11 Mbps Notes: 1. Please reboot the device after you have configured the bandwidth via DIP switch settings. 2. -
Page 12: Appendix: Specifications
User Manual of Ethernet-over-Coax Extender Appendix: Specifications Model DS-1H05-T DS-1H05-T/E DS-1H05-R Video Input RJ-45/BNC RJ-45/BNC Coaxial BNC Interface Video Output Coaxial BNC Coaxial BNC RJ-45/BNC Interface — Support — ≤ 20 W (when PSE power Power ≤ 5 W ≤ 5 W...
