Condensing high efficiency direct vent gas - fired hot water boiler (80 pages)
Summary of Contents for Boiler Company V8H Series
Page 1
™ 9700609 For service or repairs to boiler, call your heating contractor or oil supplier. When seeking information on boiler, provide Boiler Model Number and Serial Number as shown on Rating Label. Boiler Part Number Boiler Serial Number Installation Date Heating Contractor Phone Number Address...
All V8H™ Series Boiler Repair Parts may be obtained through your local U.S. Boiler Company Wholesale distributor. Should you require assistance in locating a U.S. Boiler Company Distributor in your area, or have questions regarding the availability of U.S. Boiler Company products or repair parts, please contact U.S. Boiler Company Customer Service at (717) 481-8400 or Fax...
Page 4
SECTION XVI: REPAIR PARTS (continued) Item Description Part No. V8H3 V8H4 V8H5 V8H6 V8H7 V8H8 V8H9 1. BARE BOILER ASSEMBLy Cast Iron Block Assemby: Includes Block Assembly,Burner Swing Door Assembly, Flue Cover Plate, Taget Wall Insulation, Combustion Chamber Blanket (Where Applicable), and Heater Cover Plate/Gasket (Where applicable) 101362-03 101362-04 101362-05...
Page 6
SECTION XVI: REPAIR PARTS (continued) Item Description Part No. V8H3 V8H4 V8H5 V8H6 V8H7 V8H8 V8H9 1. BARE BOILER ASSEMBLy (Continued) 610280351 610280451 610280551 Steam Rear Heater 610280651 UR with Heater Coil 610280751 610280851 610280951 Heater Cover Plate Gasket - Front Heater 8036068 Heater Cover Plate Gasket - Rear Heater 8036058...
Page 11
SECTION XVI: REPAIR PARTS (continued) V8H3 Thru V8H9 Water Boilers - Trim and Controls...
Page 12
SECTION XVI: REPAIR PARTS (continued) Item Description Part No. V8H3 V8H4 V8H5 V8H6 V8H7 V8H8 V8H9 4. V8H3 Thru V8H9 WATER BOILERS - TRIM AND CONTROLS Temperature & Pressure Gauge, ¼" NPT x 2½" Dia., 1½" 100282-01 Lg. Shank Honeywell #123870A Immersion Well, ¾" NPT 80160426 x 1½"...
Page 14
SECTION XVI: REPAIR PARTS (continued) BECKETT AFG OIL BURNER PART NOS. FOR V8H SERIES BOILERS NOTE: When ordering parts always give the serial and model numbers shown on the boiler and burner. Also provide the name of the part(s) and part number as listed below.
Page 15
SECTION XVI: REPAIR PARTS (continued) BECKETT AFG OIL BURNER PART NOS. FOR V8H SERIES BOILERS (continued) NOTE: When ordering parts always give the serial and model numbers shown on the boiler and burner. Also provide the name of the part(s) and part number as listed below.
Page 16
SECTION XVI: REPAIR PARTS (continued) CARLIN EZ and 102CRD OIL BURNER PART NUMBERS FOR V8H SERIES BOILERS NOTE: When ordering parts always give the serial and model numbers shown on the boiler and burner. Refer to Installation and Operating Instructions for Packaged Heating/Burner Units, Carlin Elite EZ-1HP and EZ-2HP Oil Burners (Form CCT-569A) for an exploded view of the burner and a list of spare parts.
