TypeS BLIZZARD BOX Series Instruction Manual

Portable fridge / freezer
Hide thumbs

Advertisement

Table of Contents

PORTABLE FRIDGE / FREEZER
WP ITM. AC57245
AC57245-1
INSTRUCTION MANUAL
PLEASE READ THIS USER MANUAL CAREFULLY BEFORE CONNECTING AND OPERATING APPLIANCE.
SAVE FOR FUTURE REFERENCE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLIZZARD BOX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for TypeS BLIZZARD BOX Series

  • Page 1 PORTABLE FRIDGE / FREEZER WP ITM. AC57245 AC57245-1 INSTRUCTION MANUAL PLEASE READ THIS USER MANUAL CAREFULLY BEFORE CONNECTING AND OPERATING APPLIANCE. SAVE FOR FUTURE REFERENCE.

  • Page 2: Package Contents

    PACKAGE CONTENTS: Blizzard Box Blizzard Box Lid Small Large Instruction Storage Basket Storage Basket Manual 12V DC Power Cord - 9 1/2’ 110V Power Adaptor - 6’...
  • Page 3 TECHNICAL SPECIFICATIONS: Capacity: 41 Quart (38.80L) Dimension: 29.6” × 16.1” × 16.1” (Including Handles) (752mm × 410mm x 410mm) USB charging port output: 5 V / 1.5A rating Climate class: 50ºF ~ 109ºF (10ºC ~ 43ºC) (SN/N/ST/T) Compressor: SECOP/Danfoss PBC-2.0 Cooling Performance: 0ºF ~ 50ºF (-18ºC ~10ºC) Refrigerant:...

  • Page 4: Operation

    OPERATION: BEFORE YOU START CAUTION! • To reduce the chances of overheating, keep your Blizzard Box in an open area, not to obstruct the heat dissipation side ventilation openings. Ensure these side vents are not blocked while in use, or shortly after use. •...

  • Page 5: Setting The Temperature

    OPERATION CONT.: 2. Operating panel Power / Status Light On / Off Button Temp. / Setting Up Orange: Stand-by Green: Running Setting Button Digital Display Temp. / Setting Down Error Light Red (Flashing): Low voltage or damage, contact Customer Care. 3.
  • Page 6 OPERATION CONT.: - Use to switch between Fahrenheit and Centigrade. The cooling temperature appears on the display for a few seconds. The display flashes several times and then the interior temperature is displayed again. NOTE If the ambient temperature is above +90°F (+32°C), the minimum setting temperature cannot be attained.
  • Page 7 OPERATION CONT.: Digital Display will be as follows: (LOW), (MED), (HIGH) The selected mode then appears on the display for a few seconds. The display flashes several times before it returns to the current temperature. (Reference Section 9 for more information) 6.
  • Page 8 OPERATION CONT.: 8. USB port for power supply 1.5A USB Port allows you to charge most mobile devices. 9. Setting Vehicle Battery Protection / Low Voltage Battery Protection When the vehicle battery’s voltage drops to the below setting, the Blizzard Box compressor will turn off. This will protect the vehicle battery from over discharge.
  • Page 9 OPERATION CONT.: 10. 3-Position Lid 11. Tips Suggested beverage & food storage Temperature temperatures Beer (Light), Sparkling Wines, Champagne 41°F / 5°C Beer (Craft), White Wine 46°F / 8°C Beer (Rich flavor), Red Wine 53°F / 12°C Soda / Pop 40°F / 4°C Fruit &...
  • Page 10 OPERATION CONT.: Cleaning and Maintenance WARNING: Always disconnect Blizzard Box from power before cleaning or servicing. WARNING: Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the Blizzard Box. • Occasionally clean the device interior and exterior with a damp cloth. •...

  • Page 11: Important Safety Instructions

    WARNING: IMPORTANT SAFETY INSTRUCTIONS 1. SAVE THESE INSTRUCTIONS– This manual contains important safety and operating instructions. 2. Before using this product, read all instructions and cautionary markings. 3. Do not expose the product to rain, moisture, or snow. 4. Use of an attachment not recommended or sold by the product manufacturer may result in a risk of fire, electric shock, or injury to persons.
  • Page 12 WARNING CONT.: Over-voltage can damage the electronics of the device. • Blizzard Box can only be maintained by authorized person, improper maintenance may lead to unexpected dangers or damages. • Corrosive materials should not be stored in Blizzard Box. • The Blizzard Box should be used, kept and stored in a dry place, avoiding water spashes, rain, or other moisture.

  • Page 13: Warranty

    WARRANTY: Limited Warranty: Type S warrants, to the original purchaser, that its products are free from defects in material and workmanship for 1 year from the date of original purchase. Conditions of Warranty: If during the 1 year warranty period your new product is found to be defective, Type S will repair such defect without charge for parts or labor, or will replace the product, subject to the following condition: 1.
  • Page 14 WARRANTY CONT.: BLIZZARD BOX MODEL#: AC57245 Responsible Party: Type S 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626, USA Tel: 1-866-294-9244 FCC Compliance Statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 16: Troubleshooting

    TROUBLESHOOTING: Issue Cause Remedy Power indicator No power input. Check whether input power is functional or light is not on not. The engine must be on in most vehicles or Blizzard Box to provide the power. does not work. Blizzard Box fuse burnt. Change fuse.
