Universal Table Top Stand/Base
15kg
33lbs
STOP
Read through ALL instructions before commencing installation.
Retain all packaging in case the product needs to be returned.
Contents may vary from photography / illustrations.
You will not need all these parts, so expect there to be some left over depending upon
the specification of your TV.
This product is intended for indoor use only. Use of this product outdoors could lead
to failure and personal injury.
Model PS-UTTS32B
Advertisement
Summary of Contents for Farnell PS-UTTS32B
- Page 1 You will not need all these parts, so expect there to be some left over depending upon the specification of your TV. This product is intended for indoor use only. Use of this product outdoors could lead to failure and personal injury. Model PS-UTTS32B...
- Page 2 Tools Recommended Boxed Parts...
- Page 3 Measure the TV fixing holes Width and Height X 50 - 200mm Bottom 50 - 200mm If width X is greater than mm or height Y greater than mm, OR if the distance from the bottom fixing holes to the bottom of your TV is more than STOP installation now and contact the customer helpline.
- Page 4 Preparing the TV Mounting Plate Use the option that fits your TV OPTION 1 X 50mm x Y 50mm X 75mm x Y 75mm X 100mm x Y 100mm OPTION 2 OPTION 3 OPTION 4 X 100mm x Y 200mm X 200mm x Y 100mm X 200mm x...
- Page 5 OPTION 2 Assemble as shown at the end of this section. 100mm OPTION 3 200mm Assemble as shown at the end of this section.
- Page 6 OPTION 4 Assemble as shown at the end of this section. 200mm Adaptor assembly method. (Example shown is 200 x 200 fixings)
- Page 7 Fitting the TV Mounting Plate No Spacers Spacers For TVs with flat / unobstructed back For TVs with irregular / obstructed back WARNING After completing step you will have fittings left over, please keep for future reference...
- Page 8 OPTION 1 OPTION 2, 3 & 4 Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations...
- Page 9 Assemble the Base Attach the feet to the bottom of the glass base Dull side Assemble the column...
- Page 10 Push your fingers through the cable management hole and use them to guide G into position.
- Page 11 Attach the nut covers Push and turn to tighten Attach the horizontal plate...
- Page 12 Connecting the TV Click! To remove TV Manage cables through the column...
