INSTALLATION INSTRUCTIONS
RETRACTED RECESSED
EMERGENCY LIGHTING UNIT
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions
should always be followed including the following:
READ AND FOLLOW ALL SAFETY
1.
Before wiring to power supply, disconnect power at fuse or circuit breaker.
2.
Disconnect A.C. power before servicing.
3.
Refer to wiring instructions sheet for proper connections.
4.
Consult your local building code for approved wiring and installation.
5.
Do not use outdoors.
6.
Do not mount near gas or electric heaters.
7.
Equipment should be mounted in locations and at heights where it will not
readily be subject to tampering by unauthorized personnel.
8.
The use of accessory equipment not recommended by the manufacturer
may cause an unsafe condition.
9.
Do not use this equipment for other than intended use.
10.
Servicing of this equipment should be performed by qualified service
personnel.
SAVE THESE INSTRUCTIONS
2575 Metropolitan Drive • Trevose • PA 19053 U•S•A
Telephone: (215) 244-4204 • Fax: (215) 244-4208
INSTRUCTIONS
R
LED
by Evenlite
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aperion LED and is the answer not in the manual?

Questions and answers

Summary of Contents for Evenlite Aperion LED

  • Page 1 Evenlite INSTALLATION INSTRUCTIONS RETRACTED RECESSED EMERGENCY LIGHTING UNIT IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS Before wiring to power supply, disconnect power at fuse or circuit breaker.

  • Page 2: Backbox Installation

    BACKBOX INSTALLATION DO NOT INSTALL SPLICE BOX COVER INTO BACKBOX UNTIL WIRING IS COMPLETE Bar Hangers telescope when BAR HANGERS assembled adjust from (4) BAR HANGER 14-1/2" to 24" HARDWARE KIT (2) HANGER CLAMP ROUGH-IN CEILING AND WALL MOUNT SUPPORTING MEMBERS MUST BE ABLE TO SUPPORT A LOAD OF AT LEAST 25 LBS. 16"...

  • Page 3: Wiring Instructions

    CLOSE-IN CEILING AND WALL MOUNT DRY WALL: Cutout hole in ceiling material should be 5-1/4” high by 5- 1/2” wide. Align backbox so lamphead opening is flush, or slightly behind inner ceiling or wall surface. 5-1/4" high WET WALL: 5-1/2" wide Plaster flush up against lamphead opening.

  • Page 4: Battery Installation

    BATTERY INSTALLATION THIS PRODUCT IS SUPPLIED WITH A CHOICE OF 3 TYPES OF BATTERY SOURCES: SEALED LEAD CALCIUM (LC) - NICKEL CADMIUM (Ni-Cd) - NICKEL METAL HYDRIDE (Ni-MH) Attach Battery Cable to LC Battery ensuring that proper polarity is observed. To PC Board Battery Connector Backbox Opening...

  • Page 5: Lamphead Installation

    LAMPHEAD INSTALLATION Connect 2 pin Battery Cable first, then 3 pin Transformer Cable to matching sockets on Printed Circuit Board. BATTERY CABLE, WITH BATTERIES CONNECTED, MUST BE ATTACHED BEFORE AC POWER IS APPLIED. Backbox Spring NOTE: Latch Once Battery is connected, unit must be energized within 30 days.

  • Page 6: Lamp Adjustment

    LAMP ADJUSTMENT This Fully Recessed Emergency Light has an Adjustable LED Assembly adjustable LED assembly mounted on the moveable Down position for Wall Mounting Up position for Ceiling Mounting door. For wall mounting, the LED assembly should be aimed down towards the floor. For ceiling mounting, the LED assembly should be aimed straight out.
  • Page 7 SELF-TESTING / SELF-DIAGNOSTICS This unit meets the requirements of NFPA 101 for Periodic Testing of Emergency Lighting Equipment. It provides visual indication of unit malfunctions including: Battery Fault Charger Fault Transfer Fault Lamp Fault Door Fault SELF-TEST An automatic self-test and diagnostic function will be performed every 28 days. A load test will be performed for 30 seconds checking for a lamp, battery or transfer fault.

  • Page 8: Status Indications

    STATUS INDICATIONS FUNCTION ACTION STATUS DISPLAY Continuous Green Battery in None Float / Trickle Charge Continuous Red Battery High Charging Wait for Green Status Flashing Green In Test Mode Wait for Test to Complete Alternate Red and Green Insufficient Charge Wait for For User Test Adequate Charge*...
