1 Safety information
This manual should be read before the product
is being operated. The manufacturer can not be
held responsible for personal injuries or other
damages caused by misuse of the product.For
future use, the manual should always be kept
with the product.
1.1 Safety for childen and disabled
This product can be used by children at the age
of 8 and older, and by people with reduced
physical, sensory or mental capability. This
product can also be used by people with lack of
experience and knowledge, if they are
supervised and instructed in how the product
should be used in a safe way and also
understand the risks associated with their use.
Children should not play with this product.
All packaging material should be kept away
from children in order to avoid suffocation.
1.2 General safety
The product is intended to be used for unloading
heavy mobile food transport carts.It is not
allowed to use the product for other purposes.
This product should be connected to the power
grid with wall socket that provides a safe
connection to iodine. When the power plug is
Advertisement
Table of Contents
Summary of Contents for ScanBox Ergo Drive+
- Page 1 1 Safety information This manual should be read before the product is being operated. The manufacturer can not be held responsible for personal injuries or other damages caused by misuse of the product.For future use, the manual should always be kept with the product.
- Page 2 loosened from the socket, it is important to use your hand to physically unplug the socket. Do not pull the power plug. The product must be disconnected from the power socket before performing troubleshooting or maintenance. To avoid danger, only the manufacturer, service agent or personnel with equivalent knowledge should replace the spiral cable and plug.
-
Page 3: Table Of Contents
1 Table of contents Table of contents ..........................2 Product description ..........................3 Use ................................ 3 Understanding the user interface ....................3 Preparations ..........................4 Driving ............................5 Emergencies ..........................6 After use ............................6 Charging ............................6 Use of the key-lock ........................7 Maintenance ............................ -
Page 4: Product Description
2 Product description This manual describes usage of the Ergo Drive+. Ergo Drive+ is an add-on solution for heavy mobile food carts products. Typical applications for Ergo Drive+ are beds and stretchers for patient transport, heavy medical equipment, patient lifts and facility trolleys. The system provides power assisted drive functionality for forwards, backwards and (optionally) sideways movement of these products. -
Page 5: Preparations
1. Emergency switch 2. On/ off switch 3. Indication LED 4. Key lock switch The indication LED is used for communication of the system status. The information includes battery level and charge indication, activation status of the emergency switch and indication of system errors. Indication LED Explanation Remarks... -
Page 6: Driving
Caution! Before switching the system on, make sure that the sensor handles are completely free of external forces. Prevent objects, such as cutlery or blankets, to push against the sensor handles. Do not hang clothes, bags, etc. to the handles. Take care that no objects are clamped between the sensor handles and the tabletop. -
Page 7: Emergencies
The Ergo Drive+ system also provides powered drive when moving a trolley up and down on slopes. In case a trolley is released on a ramp it will brake and, depending on the slope angle, will gradually drive down slowly. Warning! Do not use trolleys with Ergo Drive+ system on slopes exceeding a 6 degree angle. -
Page 8: Use Of The Key-Lock
In case the LED indication starts blinking red the battery is almost empty and immediate charging is required. In case the trolley comes with a separate power supply, please connect this power supply on one side to a mains socket and on the other side to the power connector on controller box. In case the trolley comes with an integrated power supply, please connect the power cord of the trolley to a mains socket. - Page 9 personnel only. Notice! Avoid the use of aggressive detergents/ solvents and excess of water. The Ergo Drive+ components are not designed for exposure to large amounts (jets) of water. The system is not suitable for machine washing. Notice! Even when the system is not used, the battery slowly drains. A fully drained battery can get damaged.
-
Page 10: Quick Debugging Guide
5 Quick debugging guide In case the Ergo Drive+ system fails operation, perform following steps: 1. Check if the system is switched on. The system switches off automatically in case it is not used for 15 minutes. 2. Make sure the sensor handles are not touched or moved for a few seconds directly after start of the system. -
Page 11: Product Specification
6 Product specification Use environment The drive unit is suited for indoor use only on hard (solid), dry and clean industrial surfaces. Ambient use temperature 10° to 40° C Charging -20° to 50° C Discharging (Power assisted driving) Storage temperature ... -
Page 12: Warranty
7 Warranty ScanBox grants two years warranty on the Ergo Drive+ system. The manufacturer does not warranty parts that are prone to wear and tear, as for instance the tire of the drive wheel. Warranty on the battery pack is 500 full charge cycles or two years, whichever comes first. A counter in the battery battery management system and date of integration of the Ergo Drive+ system define this cycle number or time.
