Summary of Contents for Intuicom RTK Bridge -X
- Page 1 Installation Guide ® RTK Bridge Integration with: ® ® Hemisphere Outback A220/A320 Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
- Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.
-
Page 3: Requirements For Installation
1 Requirements for Installation Required Information In order to operate an Intuicom RTK Bridge–X, you are required to have the necessary information to access and log in to the Real-Time Network. This information is entered into the RTK Bridge–X and stored in a profile. More details on setting up an RTK Bridge–X is available in the RTK Bridge-X manual. -
Page 4: Installation Instructions
Section 2: Installation Instructions 2 Installation Instructions Below is the installation Diagram for the recommended installation of the Intuicom RTK Bridge–X utilizing the equipment noted above. Diagram 1 Configuration • Configure the Intuicom RTK Bridge–X to connect to GPS/GNSS Reference network and obtain CMR/CMR+ or RTCM correction data stream from an appropriate single reference station, such as a VRS. - Page 5 Section 2: Installation Instructions • Using the Intuicom RTK Bridge-X to A220/A320 data/power cable and the null modem adapter, connect the RTK Bridge-X serial port to the Serial 2 (B Port) on the A220/A320. • Connect the SAE power connector to the supplied DC power adapter which is connected to Battery power.
- Page 6 Section 2: Installation Instructions • Scroll to Configure and press Enter • Select Data Port B by pressing Enter. Version 1.0 Intuicom, Inc.
- Page 7 Section 2: Installation Instructions • Set GGA to 1Hz, then press Enter • Scroll up to “Top Menu.” Select by pressing Enter Version 1.0 Intuicom, Inc.
- Page 8 Section 2: Installation Instructions • Scroll to System Setup and press Enter • Select Baud Rate and press Enter Version 1.0 Intuicom, Inc.
- Page 9 Section 2: Installation Instructions • Set Baud Rate to 38400 for Port B The A220/A320 should now be configured to send the GGA string to the RTK Bridge–X and receive an RTK correction stream. Version 1.0 Intuicom, Inc.
- Page 10 “RTK” should appear in NavMode. For Technical Support of the RTK Bridge-X, Intuicom recommends “Intuicom Remote Support”, please contact Intuicom for details on this real- time support program. For general technical support, please contact us at support@intuicom.com...
