- Page 3 2. Unpack the boxes & parts bags. Inspect & count the parts. The Parts Identifier page can be used to record your results. 3. Some parts on the Parts Identifier page are pre-assembled. 4. If any parts are missing please contact Mightymast Leisure immediately. 5. Note that some parts are stored inside the table top.
- Page 4 ASSEMBLY Step 1 1. Lift the air hockey top off the pool table & lay aside somewhere safe for now. Either carefully lay it on the floor or up against a wall. Be careful not to damage the air hockey fan motor. 2.
- Page 5 Step 3 7. Attach the two latches #24 to the outside of each pedestal using screws #3. 8. Important – to ensure the latches are attached in identical positions around the leg platform please make sure each latch is seated firmly on the bottom of the latch-receiving slot. See diagram below: Step 4 9.
- Page 6 Step 5 13. Place the complete table top onto the leg assembly. Ideally this requires four adults each lifting one corner of the table top, then carefully lowering it onto the leg assembly ensuring both rotational bolts #32 slot into the groove in the top of the two pedestals #12.
- Page 7 Step 7 18. Lay the table tennis pitch #9 onto the table top & attach the net by sliding parts #28 onto the side of the pitch – see diagram below. If still attached, peel off the protective paper film from the reverse side of the table tennis pitch to reveal the black exterior finish.
-
Page 8: Using The Table
USING THE TABLE To rotate the table Caution – this should only be performed by an adult as the rotating table may pinch body parts if not careful. • Pull out the two table latches on both ends. • Slowly rotate the table. If the edge of the table top catches on any part of the leg assembly when rotating then a small adjustment will need to be made to the leg assembly to make it square to the table top. -
Page 9: Environmental Protection
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. For sales & service please contact: Mightymast Leisure Ltd, 58 Bentwaters Park, Rendlesham, Woodbridge, Suffolk. IP12 2TW. UK Tel: +44 (0)1394-460896 Fax: +44 (0)1394-461326 www.mightymast.com...
