Installation Instructions for
Nikko

GENERAL PRODUCT INFORMATION:

This product is suitable for wet locations.
This product can be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and DISCONNECT POWER TO
THE ELECTRICAL BOX.

Install the Fixture

1A
NIPPLE
1
1
Feed the power line wires through the crossbar nipple.
Outdoor
POWER LINE
WIRE
1B
#8-32 SCREW
2
Attach the crossbar to the electrical box using two #8-32
screws provided.
1
980NIKKO
147_, 159_
NIPPLE
2
3
2
CROSSBAR
1.0
