FEATURES
•
Single chip 10/100BASE, half or full duplex
Ethernet Media Access Controller
•
IEEE 802.3u compliant MII
•
IEEE 802.3x full duplex flow control
•
PCI Bus master scatter/gather DMA on any
byte boundary
•
On-chip transmit and receive FIFO buffers
•
On-chip LED drivers
•
Power management capabilities for ACPI
1.0 compliant systems
•
WakeOnLAN support
•
Management statistics gathering
•
IP multicast receive and filter support using
64 bit hash table
•
Receive early interrupt
•
Transmit polling
•
Auto pad insertion for short packets
•
Programmable minimum Inter Packet Gap
•
Programmable transmit and receive FIFO
watermarks
•
On-chip crystal oscillator
•
3.3V CMOS with 5V tolerant I/O
•
0.35 m technology
•
128-pin PQFP
See Sundance Technology' s website at www.sundanceti.com for the latest information.
Fast Ethernet MAC

GENERAL DESCRIPTION

The ST201 is a single-chip, full duplex, 10/
100Mbps Ethernet MAC incorporating a 32-bit PCI
including bus master support. The ST201 is
designed for use in a variety of applications rang-
ing from workstation NICs, networking equipment
such as switches or routers, and other systems uti-
lizing a PCI bus which require network connectivity
to an Ethernet or Fast Ethernet LAN.
The ST201 includes a PCI bus interface unit, IEEE
802.3 compliant MAC, transmit and receive FIFO
buffers, IEEE 802.3u compliant MII, serial Electri-
cally EEPROM interface, expansion ROM inter-
face, and LED drivers.
The ST201 implements a rich set of control and
status registers. Accessible via the PCI interface,
these registers provide a host system visibility into
the features and operating state of the ST201. Net-
work management statistics are also recorded, and
host access to registers of the PHY device are
facilitated through the ST201' s PCI interface.
The ST201 supports several features for use in
" Green PCs" or systems where control over system
power consumption is desired. The ST201 sup-
ports several power down states, and the ability to
issue a system " wake event" via reception of
unique, user defined Ethernet frames. In addition,
the ST201 can assert a wake event in response to
changes in the Ethernet link status.
PRELIMINARY draft 2
ST201
Publication:
2
Rev: A
Date:
November 1998
