  • Page 1 TriBrer AOR500-P PON Optical Time Domain Reflectometer USER'S GUIDE...

  • Page 3: Avoiding Condensation Problems

    TriBrer WARNING WARNING You are cautioned that changes or modifications not espressly approved in this document could void yout authority to operate this equipment. To reduce the risk of fire or electric shock,do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet.
  • Page 4 TriBrer Standard Lithium battery Power adapter Host(with TF card) Carrying bag USB cable...
  • Page 5 TriBrer Description USB interface TF(micro SD) card slot Power adapter socket Charge indicator Menu button Cursor select button File operation button OPM fast enter button VFL control button Zoom control button Full screen button 21 22 23 Power button Cancel button Real-time measurement button Average measurement button Up button...
  • Page 6 TriBrer On/off Button is used to turn on/off the device. Keep pressing it for 2 seconds Optical Time Domain Reflectometer Optical Time Domain Reflectometer to turn on device. Short press it again to turn off the device. Press button to SCAN 2012-01-01 21:25...

  • Page 7: Measurement Interface

    TriBrer Measurement interface 2012-01-01 21:25 Date and time Power 2012-01-01 21:25 40.00 There are 10x10 grids in waveform region. 174622_0001.sor 174622_0001.sor 36.00 A:0.000Km File name 32.00 Horizontal grids mean distance, vertical grids B:0.000Km 28.00 24.00 mean dB value. As shown in figure, each 20.00 Waveform region 16.00...

  • Page 8: Real-Time And Average Measurement

    TriBrer Real-time and average measurement Real-time measurement can quickly judge basic faults of optical fiber. Press Optical Time Domain Reflectometer Optical Time Domain Reflectometer button to start real-time measuring. During measuring, you can change REAL range, zoom in or zoom out . Press button again or button to REAL...

  • Page 9: Event List

    TriBrer Event list After measurement or open a waveform in memory, there is Dis. Loss Ref. dB/Km C.Loss 0.000 0.00 -28.00 --.-- 0.00 event list on the bottom of waveform interface. Press ENTER Event list on main interface button to show the whole event list. Six types of events as followed: Event List Dis.

  • Page 10: Real-Time Measurement Tips

    TriBrer Real-time measurement tips The device supports user to change measurement range during real-time Optical Time Domain Reflectometer Optical Time Domain Reflectometer measurement. Start Real-time measuring function and press Up or Down button to increase or decrease the range. And it also supports to change the cursor position and zoom in/out waveform in realtime, which means you can zoom in partial waveform while measuring to judge the network fault.

  • Page 11: Cursor Selection And Waveform Zoom In/Out

    TriBrer Cursor selection and waveform zoom in/out This device has two cursors, A and B. 2012-01-01 21:25 40.00 36.00 Default distance is 0m, activated cursor A:0.000Km Optical Time Domain Reflectometer Optical Time Domain Reflectometer 32.00 B:0.583Km 28.00 turned to bright red. Press Marker 24.00 20.00...
  • Page 12 TriBrer Menu There are four pages of menu File Measure Settings System Settings About Open... Format SD Card... System Settings File Measure Settings About which used to configure parameters. System Settings Optical Time Domain Reflectometer Optical Time Domain Reflectometer 1550 Wavelength Scan Mode Manual...

  • Page 13: Menu-File Menu

    TriBrer Menu-File menu Measure Settings System Settings File About File Measure Settings System Settings About Open... Format SD Card... 20140615 2014-06-15 20140617 2014-06-17 20140618 2014-06-18 20140619 2014-06-19 20140622 2014-06-22 Warnning Press key MENU to switch to the menu tag. Enter File menu, there are two options, Are you sure to format the SD card? Open and Formatting SD card.
  • Page 14 TriBrer Menu-File menu Measure settings System settings About File Select Open option, there are folders. The folder 20140615 2014-06-15 name is the date of the file saved, which is generated 20140617 2014-06-17 20140618 2014-06-18 automatically by system. Files measured in the same 20140619 2014-06-19 20140620...
  • Page 15 TriBrer Menu-File menu Measure settings System settings About File Select one folder to display all files inside. Press Up or Down button to select one file and press 133210_0001.sor 2014-06-18 button to display it in main interface. ENTER 133210_0002.sor 2014-06-18 133210_0003.sor 2014-06-18 The file information at the bottom is the file's main...
  • Page 16 TriBrer Menu-File menu Save When finish measuring an optic fiber, press File File Name: button to enter storage interface. Default filename is 140950 hour/minute/second of first time storage. Press Caps back Save Up/Down/Left/Right button to select alphabets, digits Rename and symbols on soft keyboard. You can input 23 File Name: 140950 alphabets at most.

  • Page 17: Menu-Measure Settings

    TriBrer Menu-Measure settings Measure settings menu is used to set relative measurement data, which File Measure Settings System Settings About the judgment of events list is based on. Wrong setting might leads to wrong or Wavelength 1550 missing events. Scan Mode Manual Wavelength---wavelength of laser .

  • Page 18: Menu-System Settings

    TriBrer Menu-System settings System settings menu is used to set the device's basic functions. File Measure Settings System Settings About Auto Power Off--- set time of automatic off or cancel this function. Auto Power Off 10min Auto Name Auto Name---name automatically when file is saving, can cancel this Optical Dectector function.
  • Page 19 TriBrer Menu- About This menu is version details about device's configuration of File Measure Settings System Settings About hardware and software. CPU number is used to generate upgrading Firmware Version: TEN1A20V35_MAIN_V1.2 TEN1A20V35_ANALOG_V0.3 code, which should inform distributor or factory before software TEN1A20V35_TFT_V1.1 upgrading.
  • Page 20 TriBrer OPM function Press button on device with OPM function to enter Optical Power Meter OPM measurement interface. Press button to start ENTER Power +00.00 measuring. Press button to change the wavelength. The 000.00 meter's six calibration wavelengths are: 850nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm.
  • Page 21 TriBrer This device has VFL function, the output power is about 1nW. 2012-01-01 21:25 40.00 Press button to control red laser on-flashing-off. When 36.00 A:0.000Km 32.00 B:0.000Km Laser is on, the prompt icon will occur at upper right corner. 28.00 24.00 20.00 16.00...

  • Page 22: Tf Card And Usb Communication

    TriBrer TF card and USB communication All measured waveforms are stored in TF card. Using mini USB cable can store data to PC. PC will show a new disk icon, data inside. According to filename, user can store or recall files. 2012-01-01 21:25 40.00...

  • Page 23: User Upgrading

    TriBrer User upgrading When device needs upgrading, user does not need to send it Measure Settings System Settings About File Firmware Version: TEN1A20V35_MAIN_V1.2 back to factory. Prepare materials before upgrading as followed: TEN1A20V35_ANALOG_V0.3 TEN1A20V35_TFT_V1.1 1. CPU ID Firmware Version: SEN1A20V35_MAIN_V1.2.0 Optical Time Domain Reflectometer Optical Time Domain Reflectometer 2.
  • Page 24 TriBrer Charging This device has lithium batteries inside, and can only use the 2012-01-01 21:25 40.00 power adapter from factory to charge it. Insert the adapter to 36.00 A:0.000Km 32.00 B:0.000Km device, and finish charging in 8-10 hours. Red charge indicator 28.00 24.00 means charging, while green...

  • Page 25: Detail Parameters

    TriBrer Detail parameters Dynamic range PB-3SN25: 35/34/34dB PC-3CN25: 38/37/37dB Optic fiber type SM optical fiber Wavelength 1550nm 20nm/1310nm 20nm/1625nm 20nm Optic fiber connector FC/PC(1310/1550nm),FC/APC(1625nm)interchange able adapter(Optional SC/ST/LC) 3.5 inch color LCD Test range PB-3SN25: 120Km PC-3CN25: 140Km Pulse width 10ns~10us Measurement time 5s~180s Attenuation blind area...
