Centellis 2000 User Card 10GE with Telco Alarm
Installation and Use
P/N: 6806800M46C
May 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Centellis 2000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Artesyn Embedded Technology Centellis 2000 Series

  • Page 1 Centellis 2000 User Card 10GE with Telco Alarm Installation and Use P/N: 6806800M46C May 2016...
  • Page 2 © Copyright 2016 Artesyn Embedded Technologies, Inc. All rights reserved. Trademarks Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other names and logos referred to are trade names, trademarks, or registered trademarks of their respective owners.

  • Page 3: Table Of Contents

    Contents Contents About this Manual ............... . 9 Safety Notes .
  • Page 4 Contents Contents Contents 3.1.3.2 Telco Alarm Connector Pin Out ........43 Sensors .
  • Page 5 List of Tables Table 1-1 Standard Compliances ............27 Table 1-2 Ordering Information .
  • Page 6 List of Tables Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)
  • Page 7 List of Figures Figure 1-1 Functional Block Diagram of the Centellis 2000 Chassis ..... . 24 Figure 1-2 Main Parts Overview ........... . . 25 Figure 1-3 Block Diagram .
  • Page 8 List of Figures Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 9: About This Manual

    About this Manual Overview of Contents This manual is intended for users qualified in electronics or electrical engineering. Users must have a working understanding of AdvancedTCA and telecommunications. This manual provides the information you need to install, access and operate the Centellis 2000 User Card 10GE with Telco Alarm.
  • Page 10 About this Manual About this Manual Abbreviation Definition Central Office CPCI Compact Peripheral Component Interconnect Embedded Communications Computing Electromagnetic Compatibility Electromagnetic Immunity Elektromagnetische Vertraeglichkeit European Norm Electrostatic Sensitive Device Federal Communications Commission FPGA Field-Programmable Gate Array Field Replacable Unit Fabric Interface Gigabit Ethernet GmbH Gesellschaft mit beschraenkter Haftung...
  • Page 11 About this Manual Abbreviation Definition Out-of-Band Out-Of-Service Printed Circuit Board Power Entry Module Physical Device PICMG PCI Industrial Computer Manufacturers Group RoHS Restriction of the use of Certain Hazardous Substances Rear Transition Module Software Availability Forum SELV Safety Extra Low Voltages Shelf Manager Small Form-factor Pluggable Underwriters Laboratory Inc.
  • Page 12 About this Manual About this Manual Notation Description Used to characterize user input and to separate it Courier + Bold from system output Reference Used for references and for table and figure descriptions File > Exit Notation for selecting a submenu <text>...
  • Page 13 About this Manual Summary of Changes Order No. Date Description 6806800M46C May 2016 Removed Declaration of Conformity. 6806800M46B May 2014 Rebranded to Artesyn 6806800M46A August 2011 First edition Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)
  • Page 14 About this Manual About this Manual Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 15: Safety Notes

    Safety Notes This section provides warnings that precede potentially dangerous procedures throughout this manual. Instructions contained in the warnings must be followed during all phases of operation, service, and repair of this equipment. You should also employ all other safety precautions necessary for the operation of the equipment in your operating environment.
  • Page 16 Safety Notes Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly approved by Artesyn could void the user's authority to operate the equipment.
  • Page 17 Safety Notes Damage of the Product and Additional Devices and Modules Incorrect installation or removal of additional devices or modules may damage the product or the additional devices or modules. Before installing or removing additional devices or modules, read the respective documentation.
  • Page 18 Safety Notes Replacement/Expansion Only replace or expand components or system parts with those recommended by Artesyn. Otherwise, you are fully responsible for the impact on EMC or any possible malfunction of the product. Check the total power consumption of all components installed (see the technical specification of the respective components).

  • Page 19: Sicherheitshinweise

    Sicherheitshinweise Dieses Kapitel enthält Hinweise, die potentiell gefährlichen Prozeduren innerhalb dieses Handbuchs vorangestellt sind. Beachten Sie unbedingt in allen Phasen des Betriebs, der Wartung und der Reparatur des Systems die Anweisungen, die diesen Hinweisen enthalten sind. Sie sollten außerdem alle anderen Vorsichtsmaßnahmen treffen, die für den Betrieb des Produktes innerhalb Ihrer Betriebsumgebung notwendig sind.
  • Page 20 Sicherheitshinweise Das Produkt wurde in einem Artesyn Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten gewährleisten.
  • Page 21 Sicherheitshinweise Datenverlust Ziehen Sie das Board im laufenden Betrieb heraus, obwohl die Hot-Swap LED noch nicht leuchtet, führt das zu Datenverlust. Warten Sie deshalb bis die Hot-Swap LED blau leuchtet, bevor Sie das Board herausziehen. Beschädigung von Schaltkreisen Elektrostatische Entladung und unsachgemäßer Ein- und Ausbau des Produktes kann Schaltkreise beschädigen oder ihre Lebensdauer verkürzen.
  • Page 22 Sicherheitshinweise Überhitzung und Beschädigung des Boards Betreiben Sie das Board ohne Zwangsbelüftung, kann das Board überhitzt und schließlich beschädigt werden. Bevor Sie das Board betreiben, müssen Sie sicher stellen, dass das Shelf über eine Zwangskühlung verfügt. Verletzungen oder Kurzschlüsse Board oder Stromversorgung Falls die ORing Dioden des Boards durchbrennen, kann das Board einen Kurzschluss zwischen den Eingangsleitungen A und B verursachen.

  • Page 23: Introduction

    Chapter 1 Introduction Overview The Centellis 2000 User Card 10GE with Telco Alarm, is an independent Field Replaceable Unit (FRU) for the Centellis 2000 system. It hosts a physical device (PHY) for converting a 10 Gbps Attachment Unit Interface (XAUI) Ethernet signal to a Small Form-factor Pluggable (SFP/SFP+) connector on the face plate.

  • Page 24: Figure 1-1 Functional Block Diagram Of The Centellis 2000 Chassis

    Introduction Each 10G User Card is connected through the chassis backplane to fabric channel 2 of one front board via 4x bidirectional Low Voltage Differential Signal (LVDS) signals. The LVDS signals provide the XAUI 10G Ethernet interface which is converted by the 10G User Card to a serial 10G Ethernet interface on an SFP+ module.

  • Page 25: Hardware

    Introduction Hardware The following figure gives an overview about the main parts of the board. Figure 1-2 Main Parts Overview Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 26: Block Diagram

    Introduction Figure 1-3 Block Diagram Functional Characteristics: Transceiver  – BCM8707 10GE Serial-to-XAUI 10GBASE-LRM transceiver – Compliant to IEEE 802.3ae and IEEE 802.3aq Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 27: Standard Compliances

    Introduction Clock  – BCM8707 differential 156.25MHz reference clock SFP+  SFP+ modules – Optical MMF module for distances up to 300m – Copper cable assembly for distances up to 25m IPMI  – PICMG 3.1 compliant IPMI subsystem Power ...

  • Page 28: Ordering Information

    Introduction Table 1-1 Standard Compliances (continued) Standard Description CISPR 22 Legal EMC requirements on system level (predefined Artesyn system) CISPR 24 EN 55022 EN 55024 FCC Part 15 Industry Canada ICES-003 VCCI Japan AS/NZS CISPR 22 EN 300 386 NEBS Standard GR-1089 CORE ANSI/IPC-A610 Rev.C Class 2 Manufacturing requirements ANSI/IPC-7711...

  • Page 29: Table 1-2 Ordering Information

    Introduction For further details, contact your local Artesyn representative. Table 1-2 Ordering Information Order No. Name Description CENT-2000-UC-TA-10GE CENT-2000 USER CARD with 10G Port Centellis 2000 Uplink Card (SFPP Module not included) & Telco Alarm Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)
  • Page 30 Introduction Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 31: Centellis 2000 User Card 10Ge Hardware

    Chapter 2 Centellis 2000 User Card 10GE Hardware Overview The Centellis 2000 User Card 10GE is compliant to PICMG 3.0 R3.0 (AdvancedTCA). The shelf manager and hub board is equipped with two backplane connectors. Figure 2-1 Hardware To prevent connector damage the alignment pin offers a guide rail to the slot and a coding mechanism to ensure the installation of the board in the matching slot.

  • Page 32: Payload Hardware

    Centellis 2000 User Card 10GE Hardware The hardware consists of: Payload hardware section with  – Ethernet interfaces to the backplane and to the face plate telco alarm connector IPMI controller section with  – IPMB0-A and IPMB0-B interface to the backplane –...

  • Page 33: Intelligent Platform Management Controller

    Centellis 2000 User Card 10GE Hardware Intelligent Platform Management Controller The Intelligent Platform Management Controller (IPMC) is derived from Artesyn's IPMC building block and consists of two coupled micro controllers: IPMC Master Controller (IMC) based on an Atmega 256  IPMC Slave Controller (ISC), based on an Atmega 168 ...

  • Page 34: Onboard And External Supply

    Centellis 2000 User Card 10GE Hardware 2.4.1 Onboard and External Supply The Centellis 2000 User Card 10GE with Telco Alarm has no provisions to switch off the power input. The board is powered whenever the power is attached to the Centellis 2000 system (- 40 VDC to -72 VDC).

  • Page 35: Installing And Removing Sfp/ Sfp+ Modules

    Centellis 2000 User Card 10GE Hardware Installing and Removing SFP/ SFP+ Modules This section describes how to install and remove SFP/SFP+ modules. Eye Damage Optical SFP/SFP+ modules may emit laser radiation when no cable is connected. Avoid staring into open apertures to avoid damage to your eyes. Personal Injury and Damage of the RTM and SFP/SFP+ Modules Installing and using SFP/SFP+ modules which are not fully certified and which do not meet all relevant safety standards may damage the RTM and the SFP/SFP+ modules and may lead...
  • Page 36 Centellis 2000 User Card 10GE Hardware Table 2-1 SFP/SFP+ Modules Part Number Vendor TRX10GDP0310EP01 Merge Optics TRX10GVP2010 Merge Optics FTLX1471D3BCL Finisar TRX10GDP0310 C1 Merge Optics AFBR-57L5APZ Avago TXN100010850A00 Intel 2032237-8 Tyco FTLX8571D3BCL Finisar Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 37: Installing An Sfp/Sfp+ Module

    Centellis 2000 User Card 10GE Hardware 2.5.1 Installing an SFP/SFP+ Module Procedure In order to install an SFP/SFP+ module, proceed as follows: 1. Slide the SFP/SFP+ module into the slot until it locks into position. 2. Remove the optical port plug. Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)
  • Page 38 Centellis 2000 User Card 10GE Hardware SFP/SFP+ Module Damage The optical port plug protects the sensitive optical fibres against dirt and damage. Dirt and damage can render the SFP/SFP+ module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP/SFP+ module.

  • Page 39: Removing An Sfp/Sfp+ Module

    Centellis 2000 User Card 10GE Hardware 2.5.2 Removing an SFP/SFP+ Module Procedure In order to remove an SFP/SFP+ module, proceed as follows: 1. Remove any connected cable from the SFP module. 2. Open the SFP/SFP+ latch. Note that the latch mechanism of your SFP/SFP+ module may be slightly different compared to the latch shown in the following figure.

  • Page 40: Frame Ground And Esd

    Centellis 2000 User Card 10GE Hardware 3. Grasp the SFP/SFP+ module and carefully slide it out of the slot. 4. Cover the optical port with the optical port plug. SFP/SFP+ Module Damage The optical port plug protects the sensitive optical fibres against dirt and damage. Dirt and damage can render the SFP/SFP+ module inoperable.

  • Page 41: Controls, Indicators And Connectors

    Chapter 3 Controls, Indicators and Connectors Face Plate The following figure highlights the position of LEDs and connectors on the face plate of the board. The LEDs and connectors are described in sections LEDs on page Ethernet Connectors on page 42, and Telco Alarm Connector on page Figure 3-1...

  • Page 42: Ethernet Connectors

    Controls, Indicators and Connectors 3.1.2 Ethernet Connectors A SFP+ port located on the front panel allows for Ethernet connectivity from the payload to an external device. 3.1.3 Telco Alarm Connector 3.1.3.1 Block Diagram Figure 3-2 shows the block diagram of the Telco Alarm. Figure 3-2 Telco Alarm Block Diagram Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 43: Telco Alarm Connector Pin Out

    Controls, Indicators and Connectors 3.1.3.2 Telco Alarm Connector Pin Out The Centellis 2000 User Card has a front panel Telco Alarm connector. This connector is Artesyn PN 28NL9802U84. This is a 15 male pin D-Sub right angle connector made by Tyco 5747841- 4.

  • Page 44: Figure 3-3 Aromat Agq200A03Z Dry Contact Relay Max Switching Capacity

    Controls, Indicators and Connectors Power Alarm - NO is open when the chassis is powered off. The alarm state is when this signal is open. Figure 3-3 shows the maximum switching capacity of Aromat AGQ200A032, and Figure 3-4 shows the life curve of Aromat AGQ200A032. Figure 3-3 Aromat AGQ200A03Z Dry Contact Relay Max Switching Capacity Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 45: Figure 3-4 Aromat Agq200A03Z Dry Contact Relay Life Curve

    Controls, Indicators and Connectors Figure 3-4 Aromat AGQ200A03Z Dry Contact Relay Life Curve Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 46: Sensors

    Controls, Indicators and Connectors Sensors The IPMC functionality is based on the IPMI specification V1.5. The IPMI sensors on the Centellis 2000 User Card 10GE with Telco Alarm are shown in Table 3-3. For further information, refer Centellis 2000 User Card 10 GE with Telco Alarm: Control via IPMI Programmer’s Reference.
  • Page 47 Controls, Indicators and Connectors Table 3-3 Centellis 2000 User Card 10GE with Telco Alarm Specific Sensors (continued) Sensor Type Code Generate Event/ Reading Type Sensor Name Description Event Code VOLTAGE_1_0 Voltage (02h) +1.0V sensor Threshold (1) VOLTAGE_3_3 Voltage (02h) +3.3V sensor Threshold (1) VOLTAGE_3_3_MGMT Voltage (02h) Management...
  • Page 48 Controls, Indicators and Connectors Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 49: Board Exchange

    Chapter 4 Board Exchange Introduction This chapter describes how to install the Centellis 2000 User Card 10GE with Telco Alarm board and includes the following information: Before installation  Installing the board in a shelf  Starting up the board ...

  • Page 50: Environmental Requirements

    Board Exchange 4.2.1.1 Environmental Requirements You must make sure that the board when operated in your particular system configuration meets the environmental requirements specified below. Operating temperatures refer to the temperature of the air circulating around the board and not to the component temperature. Board Damage High humidity and condensation on the board surface causes short circuits.

  • Page 51: Power Requirements

    Board Exchange Table 4-1 Environmental Requirements (continued) Feature Operating Non-Operating (packed state) Shock Half-sine, 11 mSec, 30 m/Sec Blade level packaging Half-sine, 6 mSec at 180 m/Sec Free fall 200 mm/all edges and corners 1.0 m (packaged) per ETSI 300 019-2-2 (Blade level packaging) 100 mm (unpackaged) per GR-63-CORE 4.2.1.2...

  • Page 52: Required Equipment

    Board Exchange The board provides two independent power inputs according to the AdvancedTCA specification. Each input has to be equipped with an additional fuse of maximum 30 A located either in the shelf where the board is installed or the power entry module (PEM). 4.2.1.3 Required Equipment Gather the following equipment before starting the installation:...

  • Page 53: Installing The Board

    Board Exchange 2. Check for damage and report any damage or differences to the customer service. 3. Remove the desiccant bag delivered together with the board and dispose of it according to your country’s legislation. The board is thoroughly inspected before shipment. If any damage occurred during transportation or any items are missing, please contact our customer's service immediately.

  • Page 54: Removing The Board

    Board Exchange Installation Procedure The following procedure describes the installation of the board. It assumes that your system is powered. If your system is not powered, you can disregard the blue LED and thus skip the respective step. In this case it is a purely mechanical installation. 1.
  • Page 55 Board Exchange Removal Procedure The following procedure describes how to remove the board from a system. It assumes that the system is powered. If the system is not powered, you can disregard the blue LED and thus skip the respective step. In that case it is a purely mechanical procedure. 1.
  • Page 56 Board Exchange Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)

  • Page 57: Related Documentation

    Appendix A Related Documentation Artesyn Embedded Technologies - Embedded Computing Documentation The publications listed below are referenced in this manual. You can obtain electronic copies of Artesyn Embedded Technologies - Embedded Computing publications by contacting your local Artesyn sales office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 58 Related Documentation Table A-2 Related Specifications (continued) Organization Document Title PICMG PICMG 3.0 Revision 3.0 Advanced TCA Base Specification http://www.picmg.org Service Availability Forum Service Availability Forum Hardware Platform Interface http://www.saforum.org SAI-HPI-A01.01 Centellis 2000 User Card 10GE with Telco Alarm Installation and Use (6806800M46C)
  • Page 60 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2016 Artesyn Embedded Technologies, Inc.
