K-array KMC20V User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

KMC20
Ver. 1.0
KMC20V-KMC20H
USER GUIDE
English

Advertisement

Table of Contents
loading

Related Manuals for K-array KMC20V

Summary of Contents for K-array KMC20V

  • Page 1 KMC20 Ver. 1.0 KMC20V-KMC20H USER GUIDE English...

  • Page 2: Table Of Contents

    Ver. 1.0 TABLE OF CONTENTS 1. INTRODUCTION ..............4 2. KEY FEATURES ..............4 3. PACKAGE CONTENTS .............. 5 ................... 5 3.1 KMC20V ..................5 3.2 KMC20H 4. SAFETY INFORMATION ............6 5. UNPACKING ................. 7 6. PHYSICAL OVERVIEW .............. 7 7.
  • Page 3 KMC20 Ver. 1.0 SYMBOLS K-array declares that this device is in compliance with applicable CE standards and regulations. Before putting the device into operation, please observe the respective country-specific regulations! WEEE Please dispose of this product at the end of its operational lifetime by bringing it to your local collection point or recycling center for such equipment.

  • Page 4: Introduction

    Ver. 1.0 1. INTRODUCTION Ever since K-array launched its first slim column speaker in 2007, it has maintained its position of leader of sleek line arrays. With every subsequent product release, the company has perfected its solutions composed of closely-spaced, full-range sound sources by incorporating its Pure Array Technology.

  • Page 5: Package Contents

    Ver. 1.0 3. PACKAGE CONTENTS The Capture microphone is available in two versions: KMC20V (that includes a base for vertical mounting) and KMC20H (that includes a base for horizontal mounting). If you need to mount the microphone in both orientations, the additional base is available to purcharse as an accessory.

  • Page 6: Safety Information

    KMC20 Ver. 1.0 4. SAFETY INFORMATION Read these instructions - Keep these instructions - Heed all warnings Warning. Failure to follow these safety instructions could result in injury or damage to the device or other property. IMPORTANT SAFETY INSTRUCTIONS • Follow all instructions and keep all warnings.

  • Page 7: Unpacking

    Ver. 1.0 5. UNPACKING Each K-array microphone is built to the highest standard and thoroughly inspected before leaving the factory. Upon arrival, carefully inspect the shipping carton, then examine and test your new microphone. If you find any damage, immediately notify the shipping company. Only the consignee may institute a claim procedure regarding the system’s electronic equipment.

  • Page 8: Vertical Mounting Base

    KMC20 Ver. 1.0 7. MOUNTING THE MICROPHONE 7.1 VERTICAL MOUNTING BASE Insert the microphone into the base and screw in place using the M2 key included in the packaging. Untighten the upper rig of the base, adjust the inclination of the microphone, then tighten to lock the microphone in the desired position.

  • Page 9: Horizontal Base

    KMC20 Ver. 1.0 7.2 HORIZONTAL BASE Insert the microphone into the base and screw in place by using the M2 key included in the packaging. To adjust the orientation of the microphone, untighten the screw placed in the lower part of the base using the included M3 key.

  • Page 10: Microphone Stand

    KMC20 Ver. 1.0 7.3 MICROPHONE STAND ACCESSORY Tighten the extendable stand in the floor base. Insert the microphone in the slot on the top of the stand and screw it in place using the included screw driver. Adjust the orientation of the stand and the microphone.
  • Page 11 KMC20 Ver. 1.0 8. CONNECTING THE MICROPHONE Connect the wire coming out from the base to the included preamplifier. Use a three-pin XLR professional microphone cable (XLR) to connect the preamplifier to a microphone input which provides 48 V phantom powering.

  • Page 12: Service

    9. SERVICE To obtain service: 1) Contact the official K-array distributor in your country. Your local distributor will direct you to the appropriate service center. 2) If you are calling for service, please have the serial number(s) of the unit(s) available for reference.

  • Page 13: Technical Specifications

    250 Hz The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.

  • Page 14: Certification

    KMC20 Ver. 1.0 11. CERTIFICATION...
