Summary of Contents for Concourse Vogue
- Page 1 Operating Instructions...
- Page 2 Preparing the Buggy for Play Step 1: Open box and lift out buggy using handle as per image below Step 2: Locate the two axles provided as per image below.
- Page 3 Step 3: Hold the red ‘push’ button down and fit axle into the section of the frame in the direction of the yellow arrow as indicated in image below Please Note - you will need to repeat this on both sides Step 3 Continued: This is how the axles and buggy should look when locked into place.
- Page 4 Step 4: Remove Smart Wheels from carry case in preparation to fit to the buggy. Step 5: Slide Smart Wheels onto buggy axles and repeat on opposite side as per images below Please Note – Before fitting Smart Wheels you should refer to the Smart Wheels Operating Instructions for detailed fitting procedures.
- Page 5 Step 6: Unlock lower section of the buggy as indicated by the yellow arrow in image below Step 7: Pull front wheel outwards to allow extension of the lower section of frame...
- Page 6 Step 7 Continued: Once lower section of frame is extended fully, lock red lever as per image below...
- Page 7 Step 8: Unlock centre section of frame and lift centre section of frame until fully extended and lock red lever as per images below...
- Page 8 Step 9: Unlock Top Handle red lever as per images below Step 9 continued: Pull handle upwards and lock red lever into desired position as per image below...
- Page 9 Step 10: Adjust handle height to suit your preference as per images below Please Note – Ensure upper handle red lock lever is locked firmly after any height adjustments are made Step 11: Slide Fourth Wheel (A) into the buggy (B) as per image below...
- Page 10 Step 11 continued:...
- Page 11 Packing the Buggy up Step 1: Press red ‘push’ button and slide out fourth wheel as per images below Step 2: Unlock red lever as indicated with yellow circle as per images below...
- Page 12 Step 3: Fold handle downwards as per images below...
- Page 13 Step 3 continued: Lock red lever as per image below Step 4: Unlock red lever and fold centre section downwards as per image below...
- Page 14 Step 4 continued: Step 4 continued: Lock red lever as per image below...
- Page 15 Step 5: Unlock lower red lever and slowly push Front Wheel into closed position as per images below Step 5 continued: Once the front section is fully folded into place, lock the red lever as per image below...
- Page 16 Removing the Front Wheel Assembly To make the buggy more compact for transportation and storage, you may choose to remove the front wheel. Below are the detailed instructions for removing the Front Wheel assembly Unlock red lever and then ‘press’ red button to release Front wheel assembly as per images below...
- Page 17 Refitting the Front Wheel Assembly Slide Front Wheel housing into lower frame section and ‘press’ red button to lock Front Wheel into place as per images below...
