LGT-297
LGT-298
Caution: Please read through the instructions carefully. Before starting
this project, remove the system's positive and negative connections
from the battery or battery pack. This kit is designed for a 12-30V
Operation only. Operating this kit at a higher voltage will void any and
all warranties. Look behind each drill location BEFORE YOU DRILL.
Installer is responsible for damage (i.e. drilling into a wiring harness,
battery, fuel tank etc.). Do no attempt to activate or control this device
in a hazardous driving situation.
LGT-297 and LGT-298
Strobe Light Bar, 10-30V DC
Installation Instructions
Advertisement
Table of Contents
Summary of Contents for RHOX LGT-297
-
Page 1: Installation Instructions
LGT-297 and LGT-298 Strobe Light Bar, 10-30V DC Installation Instructions LGT-297 LGT-298 Caution: Please read through the instructions carefully. Before starting this project, remove the system’s positive and negative connections from the battery or battery pack. This kit is designed for a 12-30V operation only. - Page 2 - Socket & Ratcheting Wrench (10mm) - Drill & Drill Bit (1/4”) - Wire Cutters, Strippers and Crimpers - Marking Device Specifications LED Color: Amber (LGT-297); Red / Blue (LGT-298) Voltage: 10-30V DC Max Power: Flash Pattern: Size: 356mm x 210mm x 44.9mm (excluding mounting brackets) Cleaning Instructions Use only soap and water to clean the outer lens.
- Page 3 Strobe Light Bar Installation Locate a desirable area on the top to mount the strobe light bar. Using the light bar’s mounting brackets as a guide, mark the (4) mounting hole locations onto the top using a marking device. Drill through the top at the marked locations using a 10mm drill bit. Fasten the strobe light bar to the top using the included hardware as shown.
- Page 4 Operation Power the strobe light Amber Strobe Light Bar (LGT-297) bar ON using the Sequence Flash Pattern ON/OFF switch. ECE Single Change the sequence of Quad the flash pattern by pressing the momentary Rotate 1 switch. Single - Double - Quint...
