Explanation of Symbols

The symbols below can be found within this document or on the Nexalin ADI Device.
CAUTION!
Indicates a potential for bodily harm or a reminder that specific instructions must be followed
to avoid a potential problem.
ATTENTION!
Indicates an area of the operating instructions that requires special attention.
1A 250
FUSE AMPERAGE INDICATOR
EQUIPOTENTIAL GROUND
Used by equipment requiring a common ground. This symbol appears on the tip of the ground
stud on the back of a Nexalin ADI Device.
ATTENTION, CONSULT ACCOMPANYING DOCUMENTS
ELECTRICALLY ISOLATED/FLOATING PATIENT CONNECTION
(TYPE BF PER UL 60601-1)
3
