Sound System
We hope you have lots of fun with your new Teufel sound unit!
Now all you have to do is connect your TV and peripheral units and off you go!
Further information – for example how to upgrade to 5.1 surround sound –
can be found at www.Teufel.de/huelsta
1568309
SERVICE
Stand: 09/2015
hülsta-werke · Karl-Hüls-Straße 1 · D- 48703 Stadtlohn
TEL +49 2563 86-1500 · FAX +49 2563 86-1417
www.huelsta.com
Advertisement
Table of Contents
Summary of Contents for Hulsta Teufel
- Page 1 Sound System We hope you have lots of fun with your new Teufel sound unit! Now all you have to do is connect your TV and peripheral units and off you go! Further information – for example how to upgrade to 5.1 surround sound –...
-
Page 2: Table Of Contents
Inside General notes and information ........ 3 “Speaker levels” menu ........18 Trademarks ............3 “Source levels” menu .........18 Proper use .............3 “Audio mapping” menu ........18 “Speaker Setup” menu ........19 For your safety ............4 Speaker size ..........19 Sign symbols ............4 Crossover .............19 Safety notes ............4 Phase Sub ............19 Symbol explanations ..........5... -
Page 3: General Notes And Information
General notes and information Trademarks Proper use ® All trademarks are the property of the The units are only to be used as an audio system. corresponding owner. Only use the components as described in these Operating Instructions. Any other use is deemed to Manufactured under licence of be improper and can cause damage to property or Dolby Laboratories. -
Page 4: For Your Safety
For your safety Sign symbols • Only use the unit indoors. • Do not use the unit in moist rooms, and protect The following sign symbols are to be found in these it against drops of water or spraying. Ensure that instructions: no vases or other containers with liquid stand on the unit or in its vicinity so that no liquids... -
Page 5: Symbol Explanations
Explanation of symbols Listening to high volumes for long periods can cause damage to the hearing. Protection class II Double insulation • Prevent injury by avoiding listening to high volume levels for long periods. Danger of electric shock – do not open housing. -
Page 6: Control Unit - Operating Elements And Connections
Control unit – Operating elements and connections Control unit rear view Pos. Name Description — Connection jack for mains cable HDMI IN 1–4 Input jacks for external HDMI source devices HDMI TV HDMI output jack to TV set LINK Connection jack for future extensions POWER Operation mode LED display —... -
Page 7: Control Unit Front View
Control unit front view Pos. Name Description — Function LED Remote control RC 1 Pos. Name Description Mute (switch sound on and off) VOLUME +/– Lower (-) / increase (+) volume ◄►▲ ▼ Setting buttons • Enter button MENU Access main menu SOUND Access tone setting TOOLS... -
Page 8: Connecting Control Unit
Connecting control unit WARNING Danger of injury / damage!! Lay out cables so that they cannot be tripped over. FM (VHF) antenna WARNING Danger of electrical shock! If you use an outside or roof antenna, be sure that the antenna is correctly protected against lightning. Connect the antenna for receiving FM/VHF stations to the FM ANTENNA jack (18). -
Page 9: Coaxial
COAXIAL You can connect the coaxial digital sound output jack of a source device to the COAXIAL jack (14). To do so you require a coaxial cable with cinch plugs. AUX 1, 2 and 3 You can connect source devices with analogue sound to the jacks (15) and (16). -
Page 10: Subwoofer
(surround). You can connect your end amplifiers or active loudspeakers or even a remote control transmission system (for example the Teufel RearStation 4) to these jacks. To do so you require a stereo cable with 3.5 mm stereo jacks. TV set Connect your TV set or your projector to the HDMI TV jack (3) . -
Page 11: Headphones
Headphones You can connect stereo headphones with a 3.5 mm stereo jack to the HEADPHONES jack (7). When connecting the headphones, the loudspeakers and the output jacks to the end stages (11) and (12) are automatically switched off. WARNING Danger of injury / damage! Lower the volume before you remove the headphones plug, otherwise the loudspeakers might emit an unexpected loud noise. -
Page 12: Remote Control
Remote control Insert/change battery If the remote control no longer functions correctly, or after 2 years at the latest, the battery should be replaced. Battery type: button cell CR2025H. WARNING If the battery supplied with the article is swallowed, this can cause serious internal injury and even death. -
Page 13: Functioning
Functioning The remote control transmits the control signals and has a range of about 6 metres. Objects, walls and other sources of wireless transmission (e.g. telephones, Wi-Fi) can limit the range. You do not need to hold a remote control in the direction of the control unit to transmit signals and the control unit can even be hidden behind the TV set or be placed in a cupboard. -
Page 14: Control Unit - Basic Functions
Control unit – Basic functions Switch on and off • Switch the control unit on by briefly pressing the button (6) on the rear side of the unit or (32). When the unit is switched on, the function LED (19) lights up briefly in white. -
Page 15: Adjust Volume
Adjust volume Adjust the required level with the VOLUME +/- buttons (21). Mute You can switch the sound off and on again by pressing the button (20). When muting, the mode LED (19) blinks slowly in white and “Mute: On” appears on the TV set connected. -
Page 16: Control Unit - Menu Functions
Control unit – Menu functions Set the functions for the control unit via the menu. This is how to operate the menu: 1. Switch on the control unit and your TV set. 2. Select the control unit as the source on your TV set. 3. -
Page 17: Frequency
Frequency To set the reception frequency, begin the station search by pressing the ▲/▼ buttons (22) in the required direction and it automatically stops as soon as a station is found with a sufficiently strong signal. Mode If the stereo signals are weak there can be interference, which you can prevent by switching over to mono reception. -
Page 18: Tone Control Menu
Tone Control menu Tone Here you can set the tone (trebles and bases). Possible values: from -10 dB (lower) to +10 dB (raise). Mode Dynamic Compr. Dynamic compensation controls volume deviations between individual tracks on the CD or other digital sound sources so that playback is neither too loud nor too low. -
Page 19: Speaker Setup Menu
Speaker Setup menu Speaker size Here you can set the size of the loudspeakers being used so that these can be operated optimally. There are five configurations to choose from. The letters represent the loudspeakers: Front left/right, Center, Surround left/right. S (small) stands for small and capital L (large) stands for large loudspeakers. -
Page 20: System Setup Menu
System Setup menu Special Keys The AV, 1, 2, 3, 4 buttons (28) are for selecting the source devices, and you can allocate the buttons to meet your own requirements. Each button can activate two source devices: • “Primary” – press button once. •... -
Page 21: Wireless
In this way sound can be transmitted to another room or the surround loudspeakers in 5.1 mode can be connected by means of a radio-controlled transmission system (such as the Teufel RearStation This is the normal configuration for your furniture because 3 front loudspeakers are available here. -
Page 22: Control Unit - Bluetooth Playback
Control unit – Bluetooth playback Compatible Bluetooth devices such as most smart phones can be connected via Bluetooth to your control unit. The sound output of the smart phone is then operated by the control unit. The Bluetooth transmission system has a range of about 10 metres which can be affected by walls and furniture. -
Page 23: Control Unit - Radio Playback
Control unit – radio playback Your control unit has a radio receiver for receiving mono and stereo stations in FM/VHF frequencies from 87.5 to 108 MHz. Select radio stations Select the radio as the source with the FM button (27). The frequency set is displayed on the TV set connected. -
Page 24: Control Unit - Software Update
Control unit – Software update The software for the control unit is being further developed. Future versions can be downloaded from our website www.teufel.de/support. Install new software To do so you require an empty USB flash drive formatted in FAT-32. -
Page 25: Subwoofer - Operating Elements And Connections
POWER CLIP STATUS AUTO WIRELESS 180° HIGH PAIRING SUB IN 0° T 4000 POWER LAUTSPRECHER TEUFEL GMBH WIRELESS SUB IN AUTO LEVEL INPUT PHASE T 3.15 AL/250 V BERLIN 230V AC ~ 50 Hz 250 WATTS Pos. Label Description Pos. Label... -
Page 26: Connect Subwoofer
• Connect the mains connection jack (38) with the HIGH PAIRING SUB IN 0° T 4000 POWER INPUT PHASE LAUTSPRECHER TEUFEL GMBH WIRELESS SUB IN AUTO LEVEL mains socket using the mains cable . T 3.15 AL/250 V BERLIN 230V AC ~ 50 Hz 250 WATTS... -
Page 27: Subwoofer - Operating And Adjusting
WIRELESS 180° HIGH HIGH PAIRING PAIRING Automatic switch on/off SUB IN 0° SUB IN 0° T 4000 T 4000 LAUTSPRECHER TEUFEL GMBH LAUTSPRECHER TEUFEL GMBH SUB IN AUTO LEVEL POWER INPUT PHASE SUB IN AUTO LEVEL POWER INPUT PHASE WIRELESS WIRELESS T 3.15 AL/250 V... -
Page 28: Subwoofer Settings
Subwoofer settings – POWER switch (42) to “AUTO” – INPUT switch (41) to “SUB IN” – SUB LEVEL loudspeaker controller (34) to Centre (“0 dB”) SUB-LEVEL HIGH - PASS – HIGH PASS controller (35) to “20 Hz”. Then you can POWER CLIP STATUS... -
Page 29: Troubleshooting
Troubleshooting The following notes are meant to help you to rectify errors. If you do not succeed, our comprehensive FAQs on our website are sure to provide further assistance. Otherwise, please get in touch with our hotline. Please also note the guarantee conditions. Control unit Error Possible cause... -
Page 30: Subwoofer
Subwoofer Storing Possible cause Remedy The subwoofer doesn’t The subwoofer is switched off or Switch on the subwoofer with the mains switch work. has no mains supply. (37). Check the mains cable and the socket. The input signal is too weak. The following solutions are possible: •... -
Page 31: Technical Data
225 x 100 x 95 mm Weight 1.25 kg Impedance 4-8 ohms More technical details can be found on the website www.teufel.de. Subject to technical alterations! This product complies with the Guidelines of the Council of the European Community 2004/108/EC, 2006/95/EC and 1999/5/EG...
