Summary of Contents for Alecto AK-70
- Page 1 User Manual AK-70...
- Page 2 Introduction: The Alecto AK-70 is a radio-controlled clock with an alarm (wake-up) function and temperature / humidity display. The clock is powered by the included 5V power adaptor. Size AAA batteries may be placed as a backup power supply (type Alkaline, size AAA, voltage 1,5V).
-
Page 3: Table Of Contents
Service WWW.ALECTO.NL SERVICE@ALECTO.NL Help Hesdo, Australiëlaan 1, 5232 BB, The Netherlands ‘s-Hertogenbosch, TABLE OF CONTENT OVERVIEW Front ................4 Back ................5 INSTALLATION Power supply ............... 6 Clock ................6 Backup batteries ............6 Table stand / wall-mounting ......... 7 SETUP ................. -
Page 4: Overview
OVERVIEW Front: Time display Illuminates when the alarm is set. MO-VR is the wake-up alarm for weekdays (Monday through Friday), and SA-SO is the wake-up alarm for weekends (Saturday and Sun- day). Indicator for the display lighting (see also section 6) Antenna symbol for the radio-controlled clock (see also paragraph 3.2) Illuminates when the backup batteries are empty or not... -
Page 5: Back
Back: AL-1 AL-2 °C/°F AK-70 Digital Clock PD: xxxxA v1.0 Power: DC 5V/300mA Hesdo bv., Aziëlaan 12, 5232 BA, ‘s-Hertogenbosch, The Netherlands Power adaptor input Operating panel (the functions for the various buttons are described in the corresponding sections of this manual) -
Page 6: Installation
Power supply: The AK-70 is powered by the included 5V power adaptor. Connect the adaptor to the right-hand side of the AK-70. The model number of this adaptor is: ICY500-1200W.Only use this adaptor. Clock: As soon as you connect the adaptor, (and there are no batteries installed yet), the clock starts searching for the DCF radio signal to synchronise the time and date. -
Page 7: Setup
Table stand / wall-mounting: You may choose to place the AK-70 on a cabinet or desk (to do so, fold out the stand at the rear) or to suspend it from a wall (see keyhole openings at the rear). - Page 8 9. Use to set the minutes and then briefly press the SET button. 10. Use to set the seconds to 0 (this allows you to have the clock run exactly the same as another clock) and then briefly press the SET button. The clock is now set manually.
-
Page 9: Wake-Up) Alarm
DST (Daylight Saving Time) is indicated underneath the antenna symbol when the clock automatically switches to daylight saving time. (WAKE-UP) ALARM The AK-70 provides 2 alarm or wake-up times. Alarm-1 sounds on weekdays while alarm-2 only sounds on Saturday and Sunday: To set the alarm time: 1. -
Page 10: Display Lighting
5 minutes. DISPLAY LIGHTING Use the button on top of the AK-70 to set the display lighting. The light icon indicates the selected setting as follows: 100% lighting Dimmed lighting Automatic lighting (when the ambient light is bright, the lighting is set to maximum;... -
Page 11: Reset
Maximum / minimum memory Briefly press the MEM button to show the maximum val- ues, press the MEM button again for the minimum values and press for a third time to show the actual values. To reset the maximum / minimum memory Press and hold the MEM button for 2 seconds to reset the MAX/ MIN memory. -
Page 12: Warranty
WARRANTY For the Alecto AK-70 you have a warranty of 24 months from the date of purchase. During this period, we guar- antee the free repair of defects caused by material and workmanship errors. All this subjected to the final assessment of the importer.
