- Page 1 DOC273.52.00144.Jul07 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Instruction Sheet Edition 1 July 2007 wc/kt...
- Page 2 © HACH LANGE GmbH, 2007. All rights reserved. Printed in Germany.
-
Page 3: Instruction Sheet
Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Introduction This instruction sheet describes how to install tank wall mount kit LZX414.00.71000 (with 1 m long pipe) and LZX414.00.72000 (with 0.35 m long pipe). Items supplied with LZX414.00.71000 and LZX414.00.72000 Items supplied with the tank wall mount kit are shown in... - Page 4 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 1 Items supplied with tank wall mount kits LZX414.00.71000 and LZX414.00.72000 continued 16 Tank wall mount for SONATAX sc (Cat. No. LZY370) 28 Quick-fit anchor (4x) 17 Base (Cat. No. ATS012) 29 Set of cap screws (Cat. No. LZY429) 18 Pipe bracket (Cat.
- Page 5 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 2 Dimensions Jointed pipe (0.35 m) (Cat. No. BRO078) Jointed pipe (1 m) (Cat. No. BRO077) from LZX414.00.72000 from LZX414.00.71000...
- Page 6 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 3 Installation dimensions for LZX414.00.71000...
- Page 7 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 4 Installation dimensions for LZX414.00.72000 Select the install location Important Note: When installing the SONATAX sc, observe all hazard and safety instructions, particularly the information on selecting the measuring location and instrument setup in the SONATAX sc user manual.
- Page 8 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Install the tank wall mount 1. Find a suitable installation location and install the quick-fit anchors. Note: Drill accurate holes so that the fastening lug is exactly vertical. a. Drill the holes (see Figure 5 on page 7) and insert the quick-fit anchors.
- Page 9 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 9. To attach the sensor, remove the jointed mount pipe from the fastening lug (see section Attach the SONATAX sc on page Figure 5 Install the quick-fit anchors Figure 6 Attach the base...
- Page 10 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 7 Attach the fastening lug Cap screw M8 x 30 mm Quick-fit anchor Washer Base Fastening lug Figure 8 Assemble the joint Parts of joint, jointed mount pipe Nut M8 Parts of joint, jointed pipe...
- Page 11 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 9 Attach the brackets to the mount pipe Threaded bracket Unthreaded bracket Mount pipe Attach the SONATAX sc 1. Slide the O-ring over the sensor cable. 1. Slide the sensor cable through the short (bottom) jointed pipe and bolt the pipe flange...
- Page 12 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Figure 10 Attach the SONATAX sc Sensor cable Washer Bottom jointed pipe O-ring Cap screw M5 x 20 mm SONATAX sc Figure 11 Insert the plugs Sealing plug Sensor cable Plug Jointed pipe...
- Page 13 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Attach the protective plate 1. Attach the protective plate on the bottom jointed pipe as shown in Figure 12 on page a. Insert the flat head cap screws (M8 x 120 mm) through the protective plate and the spacers.
- Page 14 Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Attach mount pipe to base 1. Slide the two brackets (attached to mount pipe, sensor and protective plate) over the fastening lug and align all the parts, taking into account the installation dimensions...
-
Page 15: Replacement Parts And Accessories
Tank wall mount kit, LZX414.00.71000 and LZX414.00.72000 Replacement parts and accessories Quantity Cat. No. Description Base ATS012 Bracket for pipes LZY449 Impact protection LZY364 Mount pipe (2 m), jointed BRO072 Pipe (1 m), jointed, for LZX414.00.71000 BRO077 Pipe (0.35 m), jointed, for LZX414.00.72000... -
