Summary of Contents for Linak Desk Sensor1
- Page 1 Desk Sensor User manual LINAK.COM/DESKLINE Page 1 of 20...
-
Page 2: Table Of Contents
Installation ........................... 12 System with Control Box CBD6S ....................12 System with IC columns ......................12 Method of operation ........................14 Disposal of LINAK products ....................... 15 Drawing appendix ........................16 Label ............................17 LINAK application policy ......................18 Addresses ............................. 20... -
Page 3: Preface
LINAK subsidiaries and some distributors situated all over the world have authorised service centres, which are always ready to help you. LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance with the specifications, maintenance being done correctly and any repairs being carried out at a service centre, which is authorised to repair LINAK products. -
Page 4: Important Information
Important information Important information on LINAK products can be found under the following headings: ® Warning! Failure to comply with these instructions may result in accidents involving serious personal injury. Failing to follow these instructions can result in the product being damaged or being destroyed. -
Page 5: Only For Eu Markets
Only for EU markets This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. -
Page 6: Informations Importantes
Informations importantes Les informations importantes sur les produits LINAK peuvent être trouvées dans les ® rubriques suivantes: Attention! Le non respect de ces instructions peut entraîner des accidents impliquant des blessures graves. Ne pas suivre ces instructions peut entraîner l´endommagement ou destruction du produit. -
Page 7: Seulement Pour Les Marchés Au Sein De L´ue
Seulement pour les marchés au sein de l´UE: Cet appareil peut-être utilisé par des enfants âgés de 8 ans et plus, ainsi que les personnes dont les capacités physiques, sensorielles ou mentales sont réduites ou ayant un manque d´expérience et de connaissance si elles ont bénéficié d´une surveillance ou d´instructions concernant l´utilisation de l´appareil en toute sécurité... -
Page 8: Repairs
Repairs In order to avoid the risk of malfunction, all DESKLINE repairs must only be carried out by authorised LINAK ® ® workshops or repairers, as special tools must be used and special gaskets must be fitted. Lifting units under warranty must also be returned to authorised LINAK workshops. -
Page 9: Declaration Of Conformity
DECLARATION OF CONFORMITY LINAK A/S Smedevænget 8 DK - 6430 Nordborg hereby declares that LINAK Actuator System composed of: Control Box(s) CBD6SP00020A-009 CBD6S*000*0A-709 (The ‘*’ in the product description can either be a character or a number, thereby defining the variation of the product) -
Page 10: Misc. On The Deskline ® System
60 months’ warranty on the DESKLINE products when used in DESKLINE applications against manufacturing faults from the production date of the individual products. The LINAK warranty is only valid in so far as the equipment has been used and maintained correctly and has not been tampered with. Furthermore, the system must not be exposed to violent treatment. -
Page 11: Valid For
Valid for: This User manual is valid for the following product: Desk Sensor Page 11 of 20... -
Page 12: Installation
Installation Ensure that the CBD6S and/or T-splitter are fixed securely to the tabletop for optimal DS1 performance. The DS1 reacts to angle changes from its original position. Thus, the DS1 mounting direction is not important. If the DS1 is removed from the system or is no longer mounted correctly, the desk panel will show error 94 at the first activation. - Page 13 3. Plug serial cable into RJ45 socket on IC column. 4. Plug serial cable into a port on double-port side of T-splitter. 5. Plug cable for desk panel into the other port on double-port side of T-splitter. Page 13 of 20...
-
Page 14: Method Of Operation
Method of operation The DS1 operates on the gyroscope principle detecting tilting of the desk. If the desk starts tilting while driving up or down, the DS1 reacts an angle change. If the angle change is larger than 0.7° per second, the DS1 immediately stops the desk and drives it in the opposite direction. -
Page 15: Disposal Of Linak Products
Some of these main groups can be further divided into subgroups; e.g. metal can be divided into steel/ aluminium/copper and plastic can be divided into ABS/PA/PE/PP. As an example, the table below breaks down the different components in LINAK products to various recycling groups:... -
Page 16: Drawing Appendix
DRAWING APPENDIX Desk Sensor 60.1 T-splitter Page 16 of 20... -
Page 17: Label
Label Desk Sensor 1 T-splitter Page 17 of 20... -
Page 18: Linak Application Policy
LINAK shall be responsible solely that the LINAK products comply with the specifications set out by LINAK and it shall be the responsibility of the LINAK customer to ensure that the specific LINAK product can be used for the application in question. - Page 19 Page 19 of 20...
-
Page 20: Addresses
Therefore, LINAK cannot guarantee the correct and actual status of said information on its products. While LINAK uses its best efforts to fulfil orders, LINAK cannot, for the same reasons as mentioned above, guarantee the availability of any particular product.
