- Page 1 EtherHaul-5500FD™ Gigabit Ethernet Wireless Solution Installation Manual EH-5500FD-INST-01, Issue 3 July 2017 © ALL RIGHTS RESERVED TO SIKLU COMMUNICATION LTD.
- Page 2 EH-5500FD Installation Manual Trademarks Siklu, the Siklu logo, and EtherHaul are all trademarks of Siklu Communication Ltd. All other product names and trademarks mentioned in this document are trademarks or registered trademarks of their respective companies. Copyrights Copyright © 2017 Siklu Communication Ltd. All rights reserved.
- Page 3 EH-5500FD Installation Manual Safety and Regulatory Notices The following are mandatory notices for installation and operation of EtherHaul Wireless Backhaul Link. Indications appearing here are required by the designated government and regulatory agencies for purposes of safety and compliance. General Do not install or operate this System in the presence of flammable gases or fumes.
- Page 4 Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by Siklu LTD or Note: the party responsible for compliance could void the user's authority to operate the equipment.
- Page 5 EH-5500FD Installation Manual About this Document This document is the Installation Manual for the EtherHaul-5500FD wireless Link. It provides product overview and details the installation and initial setup. For instructions how to use the product’s features, refer to the “EtherHaul Operation, Administration and Maintenance Manual”.
- Page 6 EH-5500FD Installation Manual Caution: Describes an activity or situation that requires special attention. Text Conventions Italicized text is used to reference sections or chapters Document References in this document. In many cases, references use clickable hypertext links that enable immediate access to referenced objects.
-
Page 7: Table Of Contents
EH-5500FD Installation Manual TABLE OF CONTENTS Introduction to the EtherHaul System ............10 Main Features ........................ 10 Functional Description ....................11 Technical Specifications ....................12 Management ........................12 Installing the EtherHaul System ..............13 Preparing the Site ......................13 2.1.1 Physical and Environmental Requirements ............13 2.1.2 Cabling Requirements .................. - Page 8 EH-5500FD Installation Manual 3.3.4 Reboot ....................... 37 3.3.5 Copy To Remote ....................37 Quick Configuration Wizard ..................37 Quick Configuration: Step 1 – System ............. 37 3.4.1 Quick Configuration: Step 2 – Radio ............... 38 3.4.2 Quick Configuration: Step 3 – Eth Ports ............39 3.4.3 Quick Configuration: Step 4 –...
- Page 9 EH-5500FD Installation Manual TABLE OF FIGURES Figure 1-1 Hitless Adaptive Bandwidth, Coding and Modulation .......... 11 Figure 1-2 EH-5500FD Functional Block Diagram ..............12 Figure 2-1 Attaching the ODU to the Antenna ................ 17 Figure 2-2 Setting ODU Polarization ..................17 Figure 2-3 EtherHaul Mounting Assembly Components ............
-
Page 10: Introduction To The Etherhaul System
Main Features Siklu’s EtherHaul wireless backhaul radio link operates in the E-band spectrum, which provides clear technological and economic advantages over the existing lower frequency bands. Taking advantage of the new spectrum, the EtherHaul enables easy migration to support Gigabits throughput, enabling operators to enhance bandwidth capacity on a “pay as you grow”... -
Page 11: Functional Description
(PoE in and management) and 1 integrated SFP+ for 10G Host processor (CPU) the host processor controls the system responsible for the control plane, and the antenna alignment. Antenna: Siklu’s self-designed 1ft innovative antenna, as well as 2ft antenna option for longer range higher availability. Page 11... -
Page 12: Technical Specifications
EH-5500FD Installation Manual Figure 1-2 EH-5500FD Functional Block Diagram Technical Specifications For detailed technical specifications please refer to the datasheet. For detailed supported features list please refer to the product’s release notes. Management You can manage an EtherHaul system using a Web-Based Element Management System (Web EMS) or a Command Line Interface (CLI). -
Page 13: Installing The Etherhaul System
EH-5500FD Installation Manual Installing the EtherHaul System This chapter describes how to install and perform the basic setup for EtherHaul outdoor unit (ODU) in an EtherHaul wireless network, including: Preparing the Site EtherHaul Package Content Unpacking the EtherHaul ... -
Page 14: Cabling Requirements
EH-5500FD Installation Manual There must be a clear, unobstructed line-of-sight between ODU. The EtherHaul ODU should be mounted on a fixed, stable, permanent structure. A reinforced steel mounting pole is required, with a diameter measuring from 2-4 inches (1ft antenna) or 2-4.5 inches (2ft antenna). Caution: Do not mount the EtherHaul device on a structure that is temporary or easily moved. -
Page 15: Etherhaul Package Content
ODU using a minimum amount of 16AWG grounding cable or according to local electrical code. Siklu will not be held responsible for any malfunction or damage in the event that the ODU is not properly grounded. EtherHaul Package Content An EtherHaul link consists of two ODUs, two antennas and two mounting assemblies. -
Page 16: Required Tools
EH-5500FD Installation Manual Required Tools Ensure that you have the following tools with you when performing an EtherHaul installation: Standard handheld digital voltage meter (DVM) with probes Standard open-end wrench, 13 millimeter 8mm Allen key for ODU installation with 2ft antenna ... -
Page 17: Installing The Odu With A 1Ft (31Cm) Antenna
EH-5500FD Installation Manual Installing the ODU with a 1ft (31cm) Antenna 2.6.1 Attaching the ODU to the Antenna 1. Unpack the ODU, place it on a clean unobstructed work surface area, and remove the plastic cap protecting the waveguide interface. 2. -
Page 18: Mounting The Odu Using The 1Ft Mounting Bracket
EH-5500FD Installation Manual 2.6.2 Mounting the ODU using the 1ft Mounting Bracket 1. Unit mounting screws and bolts 6. Azimuth adjustment lock bolts 2. Back mounting bracket 7. Elevation adjustment lock bolts 3. Front mounting bracket 8. Azimuth fine adjustment screw (± 8) 4. -
Page 19: Figure 2-4 Quick Release Hooks
EH-5500FD Installation Manual 3. Place the assembly on the mounting pole and rotate the front and back mounting brackets to close the assembly on the pole. Replace the unit mounting bolt that was removed. 4. Ensure that both front and back mounting brackets are attached evenly to the pole, and are completely level. -
Page 20: Installing The Odu With A 2Ft (65Cm) Antenna
EH-5500FD Installation Manual Installing the ODU with a 2ft (65cm) Antenna 2.7.1 Attaching the 2ft Adapter to the ODU 1. Unpack the ODU, place it on a clean unobstructed work surface area, and remove the plastic cap protecting the waveguide interface. 2. -
Page 21: Figure 2-6 Etherhaul Odu Installed On 2Ft Antenna
EH-5500FD Installation Manual Figure 2-6 EtherHaul ODU installed on 2ft Antenna 10. Pluck the plastic plug at the very bottom of the antenna (drain hole). Figure 2-7 Antenna Option #1: Mounting Instructions for 2ft Antenna (EH-ANT-2ft) Page 21... -
Page 22: Figure 2-8 Antenna Option #2: Mounting Instructions For 2Ft Antenna (Eh-Ant-2Ft-A)
EH-5500FD Installation Manual Figure 2-8 Antenna Option #2: Mounting Instructions for 2ft Antenna (EH-ANT-2ft-A) Page 22... -
Page 23: Connecting The Cables
The DC input is floating, so either (+) or (-) can be connected to the GND on the power supply side. For the sake of consistency with other systems, Siklu recommends that you connect the (+) to the GND. - Page 24 EH-5500FD Installation Manual Use a two-wire cable (14-18 AWG) to connect the power supply to the ODU. On the ODU DC terminal, connect only the (+) and (-) wires. Do not connect to the ODU's GND input. Caution: This system may have more than one power supply cable. To reduce the risk of electrical shock, a trained service technician may need to disconnect all power supply cables before servicing the system.
-
Page 25: Grounding The Etherhaul
EH-5500FD Installation Manual 2.8.2 Grounding the EtherHaul 1. Connect one end of the grounding cable to the ground outlet on the left side of the ODU using the grounding cable lug. 2. Tighten the lug securely in place. 3. Connect the opposite end of the grounding cable to the earth connection, typically located on the mounting pole. -
Page 26: Preparing The Cables
To make a protective earth connection, use the grounding point located on the ODU using a minimum amount of 16AWG grounding cable or according to local electrical code. Siklu will not be held responsible for any malfunction or damage in the event that the ODU is not properly grounded. 2.8.3... -
Page 27: System Leds
EH-5500FD Installation Manual System LEDs Color Description PWR (Power) Green – Power OK Blink Green – Device boot (~90 sec) Red – Power Failure Off – ODU off Green – Link Up Orange – Alignment Mode Off – Link Down ETH1-2: Green –... -
Page 28: Aligning The Antenna
EH-5500FD Installation Manual 2.10 Aligning the Antenna The ODU antenna must be aligned on both local and remote ODUs. You must first perform coarse alignment on each ODU, followed by fine alignment. Accurate alignment of the ODU is critical for achieving the strongest possible receive signal. To perform antenna alignment, the ODU must be in Alignment mode. -
Page 29: Performing The Alignment
EH-5500FD Installation Manual 2.10.2 Performing the Alignment Note: These instructions are for aligning a one-foot antenna. For instructions on aligning a two-foot antenna, refer to the relevant section To perform an alignment 1. Verify that the ODU is in Alignment Mode. Coarse Alignment (Azimuth Only) 2. - Page 30 EH-5500FD Installation Manual 8. Perform steps 6 and 7 for the remote ODU. 9. Repeat steps 6 and 7 for the local ODU. 10. Use the DVM to verify maximum received signal strength on both local and remote ODUs. For best performance, measured RSSI should be within ±4 dB of the calculated value.
-
Page 31: Link Up Verification
EH-5500FD Installation Manual 2.11 Link Up Verification 1. Disconnect the DVM probes. 2. Reboot both ODUs by shortly pressing the ODU Reset Button or alternatively disconnect/reconnect the power. 3. This action will switch back the ODU to Adaptive Mode (ODU’s default operational mode). -
Page 32: Performing Basic Setup Using The Web-Based Management
EH-5500FD Installation Manual Performing Basic Setup Using the Web-Based Management This chapter describes how to perform basic setup using the web-based management. The scope of this installation manual is basic setup and monitoring of the radio link. For full configuration and maintenance procedures, refer to the “EtherHaul Operation, Administration and Maintenance Manual”. -
Page 33: Connecting To The Odu Using The Web-Based Management
EH-5500FD Installation Manual Connecting to the ODU Using the Web-Based Management 1. Launch an Internet Browser and enter https:// followed by the ODU’s IP address. The ODU’s default IP address is 192.168.0.1. Figure 3-1 Launching the Web-Based Management 2. When prompted, enter the username and password. Default: admin and admin. Figure 3-2 Entering Username and Password 3. -
Page 34: Main Page
EH-5500FD Installation Manual Main Page The Web-Based Management provides link view, presenting both local and remote configuration and monitoring. Although the local and remote systems IP address is identical (default IP address 192.168.0.1), the remote will be available as well as the EtherHaul uses dedicated communication channel for local-remote communication that is not IP-based. - Page 35 EH-5500FD Installation Manual Note: Actual Layer 1 throughput depends on product's specs. Refer to the EtherHaul Release Notes for exact specifications. Current Alarms – list of currently active alarms and date&time raised. History Log – System alarms and events history log. ...
-
Page 36: General Configuration Commands
EH-5500FD Installation Manual General Configuration Commands 3.3.1 Apply Any configuration change is executed upon clicking Apply. The Local-Remote concept of the Web-Based Management allows configuring both local and remote systems of the link. The Apply button is available at the bottom of each configuration page (one button for both local and remote systems). -
Page 37: Reboot
EH-5500FD Installation Manual 3.3.4 Reboot Separate buttons for local and remote reboot. The system will reboot and come up after initialization (~120 seconds). Note that any unsaved changes will be lost. 3.3.5 Copy To Remote You can find the Copy To Remote button next to some configuration parameters or sections. -
Page 38: Quick Configuration: Step 2 - Radio
EH-5500FD Installation Manual The first section allows configuring the following parameters: Name – you can give a name for each system Date – [YYYY.MM.DD] Time – [HH:MM:SS] Click Next to continue. Quick Configuration: Step 2 – Radio 3.4.2 Figure 3-6 Quick Config Page: Step 2 - Radio This section allows configuring the following parameters:... -
Page 39: Quick Configuration: Step 3 - Eth Ports
EH-5500FD Installation Manual Note: When exiting Alignment mode, perform system reboot to allow proper operation of the radio link. o Static – Fixed modulation profile. If you select Static, you must select from a list of pre–configured modulation profiles in the Modulation field. o Adaptive –... -
Page 40: Quick Configuration: Step 4 - Network
EH-5500FD Installation Manual o R/O field indicating the current speed/duplex (note that for SFP+ port, only 10G speed is available). Click Next to continue or Back to return to previous section. Quick Configuration: Step 4 – Network 3.4.4 Figure 3-8 Quick Config Page: Step 4 – Network This section allows configuring the following parameters: ... -
Page 41: Radio Page
EH-5500FD Installation Manual Up to five managers that will receive SNMP traps can be configured (SNMPv2c or SNMPv3). o # - Index (1-5) o IP Address – Destination IP Address o UDP Port – port number for sending traps o Security Name (community) o SNMP Ver –... - Page 42 EH-5500FD Installation Manual Tx Power [dBm] – ODU’s transmit power. Default is the max power, based on product’s specs. Minimum configurable Tx power is -35dBm (note that actual minimum Tx power is based on product’s specs). Adjust Tx Power so the RSSI at the remote end will not exceed -35dBm (overload Note: threshold).
-
Page 43: Advanced Settings
EH-5500FD Installation Manual 3.5.2 Advanced Settings Figure 3-10 Radio Page: Advanced Settings This section allows configuring the following parameters: Range Mode – allows selecting short range mode (default: Normal). Use short range mode for cases where the received level (RSSI) exceeds -35dBm. Short range allows the radio to work with higher RSSI levels (up to about - 26dBm), compared to the typical overload threshold of -35dBm. -
Page 44: Modulation Table
Note that different modulation tables may apply according to product used, the frequency channel used and ARQ status. The modulation profiles and thresholds are optimized and should not be modified (can be configured via CLI only after consulting Siklu support). 3.5.5 Statistics Radio link’s performance can be monitored using the advanced statistics counters. -
Page 45: Commissioning And Acceptance Procedure
EH-5500FD Installation Manual Commissioning and Acceptance Procedure This chapter presents the recommended commissioning and acceptance procedure to be performed following the installation of each EtherHaul radio link. The commissioning and acceptance procedure verifies the correct installation and the proper, safe, and robust operation of the EtherHaul RF link. This chapter includes the following topics: Installation Verification and Testin ... -
Page 46: Ethernet Services Test [Optional]
EH-5500FD Installation Manual 1. No ARQ losses on the RF Statistics counters. 4.1.4 Ethernet Services Test [Optional] This inspection verifies correct Ethernet services flow and error-free operation. 1. Connect a packet analyzer to the GbE port and verify that no packets are lost. 4.1.5 Management Verification This inspection verifies proper management of the link. - Page 47 EH-5500FD Installation Manual ODU safely mounted using Siklu’s bracket correctly installed Pole diameter according to mount specs Bracket’s mounting bolts securely tightened ODU grounding Cables/Fibers connections Eth1 Cat5 Eth1 Fiber Eth1 Cat5 Eth1 Fiber Eth2 Cat5 Eth2 Fiber Eth2 Cat5...
- Page 48 EH-5500FD Installation Manual Channel-width 250MHz 500MHz 250MHz 500MHz Role Auto Auto Master Slave Master Slave Tx/Rx Link ID 0 (not used) 0 (not used) Modulation/Mode Adaptive ____________ Adaptive ____________ Static ____________ Static ____________ Mode: modulation/sub-channel/repetitions/FEC UL/DL Configuration Symmetric Asymmetric (ratio)_____________% ODU polarization Link distance meters...
- Page 49 EH-5500FD Installation Manual Default IP Gateway Management of local and remote NMS used _______________ _______________ NMS management access Traps received in NMS Final Configuration Verification Copy running config to startup Done Done Clear all statistics and logs Done Done Configuration file saved and stored Done Done Additional Info / Remarks...
