Summary of Contents for ATS AT87 Series
- Page 1 INSTALLATION INSTRUCTIONS & USER MANUAL AT87 SERIES AT87001-AT87005 AT87012 AT87024 AT87120 1-in-1, 2-in-1, and 3-in-1 Power, A/V Coax and PTZ MODULES CCTV PROTECTION SYSTEM...
- Page 2 2.3.1 Insert a small screwdriver into the upper GROUNDING Adhering to these instructions hole of the terminal block (see figure 2). guarantees maximum performance of The mounting plate must be connected to this Protection Device. 2.3.2 Push screwdriver in and lever away from the ground reference used by the system the lower hole with moderate force.
- Page 3 Connect field cables to the female socket end. Connect the male plug end to the equipment meant to be protected (see figure 6). ATS, Accurate Technology Services, Inc. 829 Gretel Ave, Concord, NC 28027 Call Toll Free: 1-877-774-7782 Fax: 1-877-774-7782...
