  • Page 1 Infrared receiver Infrared Transmission For Touch Probes For Tool Setting Probes Installation instructions English Type IC56...
  • Page 2 Copyright Passing on as well as duplication of this documentation, evaluation and communication of its content are prohibited without specific authorization. Contraventions are subject to damages. All rights reserved. The language version of the manufacturer (DE/EN) is decisive for the technical content. Subject to technical change without notice. Original operating instructions © 2007 ‐ 2018 by Blum‐Novotest GmbH All brands stated in this document are the property of the respective brand owners. Article number of this documentation: 180191_EN...
  • Page 3: Table Of Contents

    3.1  Mounting position  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . .10 3.2  Mounting variants  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . .12 4.  Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  15 5.  Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  15 6.  Order numbers  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  16 7.  Shipping instructions / storage  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17 8.  EC Declaration of Incorporation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18 9.  Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19   © by Blum‐Novotest V2A | 04/2018...
  • Page 4: Introduction

    Introduction 1. Introduction Please read and observe the notes included in these instructions.  Subject to technical change without any notice. Keys CAUTION! signifies a danger, which may cause injuries, if it is not avoided. NOTICE signifies measures to avoid material damages. Advice for secondary literature  Additional advice Don’t use compressed air for this step. The CE‐label confirms, that the product as described complies with the product‐spe‐ cific European regulations. Green Blue Orange LED shines LED flashes tightening torque   V2A | 04/2018  © by Blum‐Novotest...
  • Page 5: System Overview

    System overview 2. System overview Description The infrared receiver is suitable for the BLUM measuring devices with infrared transmission. The receiver enables wireless communication between the measuring devices and the NC con‐ trol (type A2 / A3).  Data transfer to the NC control via IF59‐A2 interface. NOTICE Risk of collision Measuring systems TC series / Z‐Nano IR type ‐A1 cannot be operated with the infrared receiver. 1 2 3 4 IF59 Fig. 2‐1  (1) Transmission diodes (4e) LED transmit IR / flash On/Off (2) Receiver diode (6) Cable (4a) LED Mode (7) for mounting screws (4b) LED Battery (8) Universal holder (4c) LED Status (9) Seal insert + O‐Ring (at horizontal facing cable) (4d) LED Receive IR  ...
  • Page 6: Display Elements

    System overview Display elements LED colour Function MODE (4a) Standby Mode TC Mode DUO Reserved Battery (4b) Battery o.k. Battery low Status (4c) Initial position Probe deflected / collision Receive IR (4d) No reception Interference  / incorrect reception Reception o.k. Wrong system Send command Transmit IR / Flash On  / Off (4e) Send flash Tab. 2‐1  The LED´s are explained on enclosed label. Please fix label clearly visible on the machine.   V2A | 04/2018  © by Blum‐Novotest...
  • Page 7: Dimensions

    Technical data Protection class IP68 Power supply 12 V DC / 100 mA via IF59 Air nozzle Integrated, max. 6 bar (0.6 MPa) Signal transmission Infrared Min. bending radius cable 60 mm (application: flexible) Max. cable length 50 m Mass 700 g Storage temperature ‐20 °C ... +70 °C Operating temperature +5 °C ... +50 °C Tab. 2‐2    © by Blum‐Novotest V2A | 04/2018...
  • Page 8: Area Of Work

    Area of work 70° 70° 60° 60° 50° 50° TC50 / 40° 40° TC51 / 30° 30° TC53-30 20° 20° IC56 10° 10° 1m 2m 3m 4m 3m 2m 1m 10° 10° 20° 20° 30° 30° 40° 40° 50° 50° 60° 60°...
  • Page 9: Complete System

    For customer‐specific codes the white label can be marked. NOTICE Risk of collision due to lack of labelling possible.  In order to avoid mistakes the measuring system and the machine must be coded.  Please always use the transparent label to protect! IC56/IC57 IC56 - IF59 standby mode TC IC56 - TC mode DUO no reception IC56 - DUO Mode interference reception o.k. incorrect system send flash initial position probe deflected Probe 1: battery o.k.
  • Page 10: Mounting And Commissioning

    Mounting and commissioning 3. Mounting and commissioning CAUTION! Physical injuries and material damages of the components caused by voltage  Make sure that the components are volt‐free during installation work. NOTICE Damages of the measuring system by chips are possible.  Never install cables and wires without protection in the working area.  Protect cables and wires in the working area against flying chips, e.g. by protection hose, protection spring, cover, etc. NOTICE Damage to the measuring system by sharp edges possible.  Please deburr the sharp edges on the cable bushing and mount edge protection. NOTICE Damage by improper installation of cables and hoses  When mounting cables and hoses, please provide sufficient strain relief.  Please note the minimum binding radius of cables and hoses. NOTICE Damages caused by improper installation/dismounting  Please only use original replacement parts as well as the provided special tools.  Consider the maximum tightening torque. Mounting position Choose a mounting position, in which other machines are not affected. Test the  mounting position before the final mounting. The receiver should be placed protected from coolant and chips. Distance between probe and receiver: Pay attention to chap. 2.5. Align the optics of the receiver to the probe in measuring position.   V2A | 04/2018  © by Blum‐Novotest...
  • Page 11 Mounting and commissioning 142678 Fig. 3‐1    © by Blum‐Novotest V2A | 04/2018...
  • Page 12: Mounting Variants

    Mounting and commissioning Mounting variants Horizontal facing cable: NOTICE Pollution of the system Mount seal insert and O‐Ring at horizontal facing cable. Fig. 3‐2  (9) Seal insert (10) O‐ring Vertical facing cable: Fig. 3‐3    V2A | 04/2018  © by Blum‐Novotest...
  • Page 13 Mounting and commissioning 149358 142680 Fig. 3‐4  (8) Universal holder (9) Seal insert (10) O‐ring Tightening torque: DIN EN ISO 4762 (DIN912)  M3x10:  =   1.3 Nm (max.) M4x10:  =   3.0 Nm (max.) M6x12:  =   10.5 Nm (max.) Drilling template (data sheet, scope of delivery)   © by Blum‐Novotest V2A | 04/2018...
  • Page 14 Mounting and commissioning Ø5,2 60° Fig. 3‐5 Universal holder (11) Clamping screw  = 1.5 Nm 142676 142684 (15°) 142677 (30°) Fig. 3‐6 Front‐Kit / Adapter 15° / 30° Please find detailed designs and dimensions in the data sheets. 142678 360° Fig. 3‐7 Light protection shield Please find detailed designs and dimensions in the data sheets.   V2A | 04/2018  © by Blum‐Novotest...
  • Page 15: Electrical Connection

    Electrical connection 4. Electrical connection Installation instructions IF59 5. Maintenance • The receiver needs minimum maintenance only. • Keep the viewing glass clean.   © by Blum‐Novotest V2A | 04/2018...
  • Page 16: Order Numbers

    Order numbers 6. Order numbers Use original parts and accessories by Blum‐Novotest only. Infrared receiver IC56 Cable length L = 10 m PUR 142636 Cable length L = 20 m PUR 142639 (8 wires) Front‐Kit 142676 Adapter 15° 142684 Adapter 30° 142677 Light protection shield 142678 Heavy Duty Kit 142680 Protection spring 1 m incl. screwing   V2A | 04/2018  © by Blum‐Novotest...
  • Page 17: Shipping Instructions / Storage

    Shipping instructions / storage 7. Shipping instructions / storage NOTICE  If you return the measuring system for repair, please enclose a detailed error description.  The measuring system has to be returned in the original packing only.  The packing is not allowed to deflect the measuring system.  The measuring system should be packed shock and pollution protected. Service order Please complete this repair order answering all questions in detail and attach it to the system. It will be more cost effective for both parties if we have all the information and will ensure a prompt repair service. Blum‐Novotest GmbH Kaufstr. 14, 88287 Gruenkraut ‐ Germany Tel. +49 751 6008‐0, Fax. +49 751 6008‐156 Company: Department: Contact: Address: Phone: Fax: Email: Measuring system type, serial No.: Machine type, manufacturer: Description of defect:   © by Blum‐Novotest V2A | 04/2018...
  • Page 18: Ec Declaration Of Incorporation

    EC Declaration of Incorporation 8. EC Declaration of Incorporation acc. to the EC Machine Regulations 2006/42/EC in the edition from 17 May.2006 We hereby confirm that the subsequently following components are defined for the installation into other machines and that they are in accordance with the following safety requirements of the EC regulations. Commissioning is not allowed until it is ascertained that the machines, in which the compo‐ nents are installed, are in accordance with the EC regulations 2006/42/EC. The relevant technical information is compiled acc. to annex VII part B and, where appropriate, we will send the information concerning the components to the different countries. The indus‐ trial property rights of Blum‐Novotest GmbH will remain unaffected. Component name IC56 Infrared receiver Safety requirements 1.5.1 2006/42/EC, Annex I Applied standards: EC‐Regulations: 2014/30/EU 2014/35/EU Applied harmonized standards: EN 61000‐6 EN 60204‐1 EN ISO 12100 Applied national standards: DIN VDE 0100 DIN VDE 0113 Authorised representative for technical information: Blum‐Novotest GmbH Kaufstr. 14 88287 Gruenkraut, Germany   V2A | 04/2018  © by Blum‐Novotest...
  • Page 19: Service

    Service 9. Service Headquarters: Worldwide: Blum‐Novotest GmbH Kaufstr. 14 88287 Grünkraut, Germany Tel.:+49 751 6008‐0 Fax:+49 751 6008‐156 www.blum‐novotest.com Vertrieb/Sales: sales@blum‐novotest.com Service: service@blum‐novotest.com Hotline: Vertrieb/Sales: Tel.:+49 751 6008‐200 Tel.:+49 751 6008‐202 Service:   © by Blum‐Novotest V2A | 04/2018...
