Summary of Contents for Watson Pro AM-93-HLE
Page 1
AM-93-HLE VM-93-HLE High Load Li-ion Battery with LED and 3-Stud or V Mount Thank you for choosing Watson Pro Please read this user manual carefully and keep it for reference before using the battery.
SAFETY INSTRUCTIONS Make sure the battery is fully charged before use. When not in use, remove the battery from its device. Some electronic equipment will draw current even when the switch is off. Do not short-circuit the terminals. This battery is protected with an internal self-resetting fuse, but short circuits may still cause severe damage to the battery.
OVERVIEW Battery-level LED meter Shows the remaining capacity of the battery. When the capacity reaches less than 9%, the bottom LED will flash. Battery-level check button P-tap port 12 V, 10 A max. USB output Press the battery-level check CHECK button to start charging or to power your USB device.
