(619) 665-2077
Installation and Operating Instructions
WaterQuick Tankless
- Hot Water Circulation Pump
WaterQuick Tankless
with built-in Pump Manager
Step 1. Choose the appropriate place to install the pump and Flow Monitor:
WaterQuick Tankless
can be installed in several different configurations. The circulation
pump and Flow Monitor can be mounted in either the cold water supply line to the water heater
or in the hot water line going out of the water heater into the house.
Note: It is important that you take into consideration how the pump will be supported and where
there is access to an electrical outlet.
Cold Water Line:
If you install the circulation pump and Flow Monitor in the cold-water line it must be located on
the pipe that is the sole supply of water for the tankless heater. If it supplies water to any other
fixture it will lead to false activation of the pumping system.
Hot Water Line:
The pump and Flow Monitor can be installed in the hot water line that comes out of the water
heater and goes into the house. It does not need to be located next to the water heater, but it
needs to be located before the first hot water lateral.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WaterQuick Tankless and is the answer not in the manual?

Questions and answers

Summary of Contents for Faster Hot Water WaterQuick Tankless

  • Page 1: Installation And Operating Instructions

    (619) 665-2077 Installation and Operating Instructions WaterQuick Tankless - Hot Water Circulation Pump WaterQuick Tankless with built-in Pump Manager Step 1. Choose the appropriate place to install the pump and Flow Monitor: WaterQuick Tankless can be installed in several different configurations. The circulation pump and Flow Monitor can be mounted in either the cold water supply line to the water heater or in the hot water line going out of the water heater into the house.
  • Page 2 (619) 665-2077 The volute of the pump (silver part) can be installed in either a vertical or horizontal orientation. However, the can (green part) must be installed in a horizontal orientation. The orientation of the pump can be changed by unscrewing the 4 hex head bolts (circled in picture below) that hold the can and volute together and rotating the can as necessary.
  • Page 3 (619) 665-2077 Step 6. Turn on water: Once all of your connections are complete, replace caps on water drain valves and turn water back on. Check for leaks. Repair as necessary. Step 7. Connect the pump and the Flow Monitor: There are 2 switches that control the speed of the pump and how it works.
  • Page 4 (619) 665-2077 Step 7. Plug the pump in: Set pump toggle switch to the 3 setting for the highest speed. Step 8. Plug the pump in: Plug the pump into a properly grounded 110 vAC outlet. Step 9. Test pump operation: Turn on any hot water faucet in the house to start the pump.
  • Page 5 (619) 665-2077 Do not over tighten. 6. Attach existing faucet supply lines to the appropriate "Cold Water Out" and "Hot Water Out" ports of the Advanced Bridge Valve (if the existing supply lines are 3/8”, use the 1/2" x 3/8” adapters). Tighten finger tight plus a quarter turn with a wrench. Do not over tighten.

  • Page 6: Operating Instructions

    I be grounded in accordance with the national Electrical Code and local government regulations. Operating Instructions WaterQuick Tankless – Red To activate the Pump, simply turn on any hot water faucet in the house and quickly turn it off.

  • Page 7: Limited Warranty

    For warranty service, call (619) 665-2077 for a return authorization number. Then, ship your unit to our factory, freight and insurance prepaid, with proof of date of original purchase. Please include a note stating the problem. Faster Hot Water will repair it, or replace it, and ship it back to you prepaid.
  • Page 8 This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. (California law requires this warning to be given to customers in the State of California.) WaterQuick Tankless - Hot Water Where You Want It, When You Want it!
