Powerohm Instruction Manual
For BM "BG" Series
Braking Modules
IMPORTANT: These instructions should be read thoroughly before installation. All warnings and
precautions should be observed for both personal safety and for proper equipment performance
and longevity. Failure to follow these instructions could result in equipment failure and/or serious
injury to personnel. Braking modules contain lethal voltages when connected to the inverter. It is
very important to remove power to the inverter before installing or servicing this unit. Always
allow adequate time (approximately 5 minutes) after removing power before touching any
components. The LED's must be completely out before servicing the unit.
