Coast APS 3000 Safety, Set Up, Operation And Maintenance Instructions

Center post tire changer. for servicing single piece automotive and most tubeless light truck tire/wheel assemblies.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APS 3000
Center Post Tire Changer
For servicing single piece automotive
and most tubeless light truck
tire/wheel assemblies.
Any other type, including tube type agricultrual, require
special handling. Tires identifi ed as truck tires need to
adhere to OSHA standard 1910.177.
See
RIM Safety
Operating
Instructions
on page 6.
1601 J. P . Hennessy Drive, LaVergne, TN USA 37086
HENNESSY INDUSTRIES INC. Manufacturer of AMMCO
page 4
Operation Instructions
Maintenance Instructions
READ these instructions before placing unit in
service. KEEP these and other materials delivered
with the unit in a binder near the machine for ease
of reference by supervisors and operators.
615/641-7533
800/688/6359
, COATS
and BADA
®
®
Safety Instructions
Set Up Instructions
www.coatsgarage.com
Automotive Service Equipment and Tools.
®
Manual Part No.:
85610910 00
Revision:
3/17

Advertisement

Table of Contents
loading

Summary of Contents for Coast APS 3000

  • Page 1 APS 3000 Center Post Tire Changer For servicing single piece automotive and most tubeless light truck tire/wheel assemblies. Any other type, including tube type agricultrual, require special handling. Tires identifi ed as truck tires need to adhere to OSHA standard 1910.177.

  • Page 2: Table Of Contents

    Table of Contents Upper Bead Loosening ........15 General Information ..........iii Lower Bead Loosening ........16 General Safety Instructions ........iii Match Mounting ..........16 Tire Specifications Diagram ........iv Tire Demounting ............. 17 Safety Instructions ........... v Upper Bead Demounting ........17 Owner’s Responsibility .........v Lower Bead Demounting ........

  • Page 3: General Information

    General Information The tire changer is designed to demount and mount tires of passengers cars and light commercial vehicles with rims from 10” to 34” (254 - 863 mm) and maximum tire diameter of 47” (1200 mm). The tire changer is designed to demount and mount conventional tires, as well as new generation types, such as “self-supporting”...

  • Page 4: Tire Specifications Diagram

    Tire Specifi cations Diagram Radial Rim diameter code Ratio of height to Load index & width (aspect ratio) speed symbol Nominal width of tire in millimeters U.S. DOT tire identification number Passenger car tire Severe snow conditions Max. Tire ply permissible composition inflation...

  • Page 5: Safety Instructions

    Safety Instructions Definitions of Hazard Levels Identify the hazard levels used in this manual with the Owner’s Responsibility following definitions and signal words: To maintain machine and user safety, the responsibility DANGER of the owner is to read and follow these instructions: Watch for this symbol: •...

  • Page 6: Specifications

    Specifi cations Connections: Power supply: 230V - 50/60 Hz - 1Ph Operating pressure: 116 - 145 psi Air supply pressure regulator set at 145 psi Inflating air-pressure regulator set at 50 psi Working Capacity: Rim clamping range: 12” to 34” Maximum rim width: 16”...

  • Page 7: Safety Devices

    Safety Devices The tire changer is equipped with safety devices that are designed to guarantee the safety of the machine operator: Pneumatic safety valve, arranged inside the machine that prevents the pressure from exceeding 58 PSI during inflation. Pressure regulator and gauge that limits the maximum pressure of the circuit to 145 PSI. Maximum tank pressure valve, fitted on the tank, to prevent the maximum pneumatic pressure from exceeding 160 PSI (optional auxiliary bead seater) Safety Notices and Decals...

  • Page 8: Warning Decal Placement

    Warning Decal Placement Replace any warning label immediately in case of damage or loss. Do not operate the Tire Changer in case of missing warning labels. Do not hide any warning label by any means. Do not place objects that can obstruct or reduce the visual ability of the operator.
  • Page 9 Warning Decal Palcement (cont.) Main Coats Pinch Point 85608119 85610705 Front of the machine Manual Tire Bleed 8183597 Inlet Pressure 8182059 Danger Explosion (2x) 8109888 / 8109888Fr Tower Pinch Point 8182373 and FR 85609356 Important: Always read and follow operating instructions. •...

  • Page 10: Remember R.i.m

    Remember R.I.M. Three Simple Steps To Help Keep Shops Safe READ INSPECT MOUNT R.I.M. is a training program developed by Hennessy Industries to help keep tire technicians safe. By following the basic principles of R.I.M., technicians can avoid situations that can cause catastrophic accidents like tire explo- sions.
  • Page 11 Intentionally left blank Important: Always read and follow operating instructions. • 5...

  • Page 12: Principal Operating Parts

    Principal Operating Parts Know Your Unit Compare this illustration with the unit before placing it Do It Now! into service. Maximum performance and safety will be Now is a good time to contact product service (800- obtained only when all persons using the unit are fully 688-6359) to start warranty, otherwise warranty starts trained in its parts and operation.
  • Page 13 CAUTION Replace any damaged or missing safety decals. They are available from COATS, (800) 688-6359. Tilting tower control pedal Clockwise and counterclockwise clamping chuck (15) rotation control pedal Wheel lifter (optional) control pedal Inflation pedal Button used to activate the “over-run” function of bead loosener disks (16 and 18) Selector used to block the bead breaking carriage and to activate the “over-run”...

  • Page 14: Pneumatic Systems

    Pneumatic Systems 8 • Important: Always read and follow operating instructions.

  • Page 15: Description Of The Machine Controls

    Description of the Machine Controls Installation Space required for positioning When choosing the place of installation be sure that it complies with current safety-at-work regulations. The Tire-Changer must be connected to the main electric power supply and the compressed air system. It is therefore advisable to install the machine near these power sources.

  • Page 16: Transport

    Transport The Tire Changer must be transported in its original packaging and kept in the position indicated on the box. The packaged machine must be moved with a fork lift of suitable capacity. Please insert the forks as shown in fig. 1. Unpacking Remove the protective cardboard, remove all fixing screw and free the Tire-Changer from its original pallet.

  • Page 17: Set Up

    Set Up Connect the machine to the electrical power supply, which must have line fuses and an efficient grounding system, meeting current standards. It must also be connected to an automatic differential 20A circuit breaker. NOTE: If the machine is not supplied with an electrical plug, the user shall install a 20A plug that is suitable for the voltage of the machine and complies with current standards.

  • Page 18: Wheel Clamping Operation With Smart Lock

    Wheel Clamping Operation with Smart Lock 1. Check the correct wheel positioning on the clamping chuck. Insert SMART LOCK making the centering cone fi t the rim hole correctly, leaving no space among SMART LOCK nut, the rim and the Tire-Changer clamping chuck.

  • Page 19: Positioning The Valve

    Positioning the Valve Fig. 6 shows a rim in the form of a clock. In the following Mounting and Demounting process steps, you will position the rim with clock directions, so that the valve and pressure sensor do not get damaged. CAUTION To avoid damaging the valve and pressure sensor, (if installed) you must always arrange the valve in...

  • Page 20: Tire Pressure Monitoring System (Tpms)

    Tire Pressure Monitoring System (TPMS) TPMS, Tire Pressure Monitoring System is an electronic system designed to monitor the air pressure inside the tires through special sensors mounted inside the wheels, which provide real-time tire-pressure information and inside temperature data to the vehicle’s electronic control unit. Tire pressure system alerts the driver when the tire pressure falls 20% below the recommended pressure, thus increasing your safety on the road.

  • Page 21: Bead Loosening

    Bead Loosening Ensure the tire is completely deflated before starting any operation on the wheel. Before lifting and positioning the wheel onto the clamping chuck, use the proper tool to remove any weights from the rim, paying attention to not damage the rim. Before starting any operation, check for the presence of a pressure sensor.

  • Page 22: Lower Bead Loosening

    Lower Bead Loosening Keep the bead loosener system set up as for upper bead loosener disk procedure: the lower bead loosener disk is always aligned with the upper one, and it is already positioned at 3-4 mm from lower rim edge. Lift the lower bead loosener disk until it touches the lower tire bead using controls 13 for lifting and 12 for lowering.

  • Page 23: Tire Demounting

    Tire Demounting Once the bead loosening process is completed, and the wheel is already positioned on the clamping chuck, check and ensure its locked and centered. Upper Bead Demounting Bring the tilting tower close to the wheel by pressing pedal 1, while simultaneously placing the mounting tool over the rim edge using the handle (fig.

  • Page 24: Lower Bead Demounting

    Lower Bead Demounting Press pedal 1 to move the mounting arm away from the working position. Before pulling out the lower bead, spin the clamping chuck to let the valve reach “1” or “2” o’clock position in order to avoid possible damages to the valve and the pressor sensor - if equipped.

  • Page 25: Upper Bead Mounting

    Upper Bead Mounting Keep the mounting arm and the mounting tool in working position and proceed with mounting of the upper bead, then put the tire bead on the rim slightly tilted down to “3 o’clock” position, so that the upper bead rests on the left side and under the right side of the mounting tool (fig.

  • Page 26: Inflation

    Infl ation NEVER exceed tire manufacturer's recom- mended air pressure. Tires can explode, especially if inflated beyond these limits. Use clip-on air chuck, keep hands, arms and entire body back from inflating tire. Avoid distraction during inflation. Check tire pressure frequently to avoid over infla- tion.

  • Page 27: Stages Of Inflation

    Stages of Infl ation on a Conventional Tire and Rim Review these descriptions and diagrams carefully. Refer to them as necessary during bead sealing, bead seating, and inflation to verify that you are proceeding properly and safely. Bead Sealing Bead sealing is the process of capturing air pressure between the tire and the rim.

  • Page 28: Mismatched Tires And Wheels

    Mismatched Tires and Wheels Never mount and inflate mis-matched tires and wheels. Mismatched tire and wheel combinations will explode, if you attempt to force a bead seat, causing personal injury or death to operator and/or bystanders. 22 • Important: Always read and follow operating instructions.

  • Page 29: Tubeless Tire Inflation

    NOTE: Sometimes, regular inflation may not be enough to seat the bead of tubeless tires. This problem may be solved by using the optional accessory TUBELESS INFLATING DEVICE. Tubeless Tire Infl ation In order to properly use the optional Tubeless Inflating Device: Press the safety valve against the rim border, push the activating button on the handle to blast air and press the inflating pedal 4 to provide air to the wheel valve.

  • Page 30: Standard Accessories

    Standard Accessories Lube Paste Bucket (PN 8183710) Brush (PN 85000850) Plastic protections for mounting/demounting tool (PN 85000850) Plastic protections for Smart Lock centering cone (PN 89231516) Rubber protections for clamping chuck (PN 89231517) Plastic protections for clamping chuck driving pin (PN 89231518) Plastic cone Ø...
  • Page 31 Standard Accessories (cont.) Adjustment knob for Smart Lock (PN 82041474) Cleaning brush for Smart Lock and clamping chuck in- ner surface (PN 84292291) O rings for Smart Lock • (PN 84293252) • (PN 84298601) Air lubricator, air filter/water trap (PN 82041007) Wheel lifter for wheel positioning and centering onto clamping chuck.

  • Page 32: Optional Accessories

    Optional Accessories Wheel clamping adaptor, allows clamping reverse mounted wheels, wheels with no center hole and special wheels (BMW rims). Suitable to lock any rim with any holes-number onto the clamping chuck. (PN 89242832) Reverse mounted wheels Wheels with no center hole Special rims Truck cone kit, allows clamping VAN and LCV wheels with center hole diameter from 110 to 190 mm.

  • Page 33: Maintenance

    Maintenance Standard Maintenance Routine maintenance according to the following instructions is of crucial importance to ensure the correct operation and lasting life of the Tire Changer. Unplug the unit from electrical power source and compressed air supply before servicing it. Release the compressed air from the circuit by pressing the deflation button 14 for a few seconds.

  • Page 34: Machine Overhaul

    Maintenance (cont.) The regular cleaning and lubrication of the SMART LOCK components help ensure long-lasting functioning of the machine. The replacement of the O-Rings is recommended every 12 - 18 months of SMART LOCK use. Machine Overhaul Overhaul maintenance must be carried out by factory authorized personnel ONLY. Defective parts should be replaced with authorized or approved replacement parts by factory authorized service personnel.

  • Page 35: Troubleshooting Chart

    Troubleshooting Chart PROBLEM CAUSE SOLUTION The clamping chuck does not rotate 1) The power supply is missing; 1) Check the wall socket; 2) Machine has not plugged 2) Check the machine plug is correctly; connect properly or if the plug 3) The fuses have blown;...
  • Page 36 Troubleshooting Chart (cont.) PROBLEM CAUSE SOLUTION The bead loosener disk positions 1) The air supply is missing; 1) Check net pressure; itself correctly but does not 2) The control valve is damaged or 2) Replace the control valve; perform the “over run” defective;...
  • Page 37 NOTES Important: Always read and follow operating instructions. • 31...

  • Page 38: Rim Chart

    AFETY R.I.M. READ INSPECT MOUNT READ… INSPECT… MOUNT… Mounting and inflating the Before you put any tire Once you’ve made sure the tire is OK wrong size tire can get on a rim, inspect the rim and the right size and the rim is OK, you hurt.
