  • Page 1 Long-throw diffuser DF-47-TR Mounting instructions www.koolair.com...
  • Page 2 Long-throw diffuser DF-47-TR Installation instructions...

  • Page 3: Installation Instructions

    Adjusting offset angle of the temperature-adjustable DF-47-TR. The DF-47-TR diffuser has the capability of being directed up at an angle of 20º (with respect to the horizontal axis) to supply cold air (Air Temp. < 20ºC) or down 20º to supply hot air ( Air Temp. > 30ºC).
  • Page 4 DF-47-TR Installation instructions Adjusting optimum angle for cold air. Using the offset angle label (Fig. 1) to measure the offset, loosen screw 2 (figure 2); rotate the diffuser to the desired angle; move screw 2 along slot 1 (figure 2) until it touches the moving part of the diffuser and re-tighten screw 2.
  • Page 5 THIS CATALOGUE IS INTELLECTUAL PROPERTY. Its reproduction either of a part or its full contents is prohibited without the expressed and authentic consent of KOOLAIR, S.A. CEN-IMDF47TR-0117-00...
