Summary of Contents for Stair Climbers Apollo
- Page 1 Apollo Instruction Manual Dolly Stair Lift ...
-
Page 2: Table Of Contents
Contents Essential Safety Information Technical Parameters Operation Loading the Dolly Moving the Unit on Level Ground Climbing Stairs Descending Stairs Folding the Unit Maintenance Charging the Battery Pack Adjusting the Track Tension Cleaning Recycling Troubleshooting 2 ... -
Page 3: Essential Safety Information
2 Essential Safety Information The following symbols are used throughout this manual Caution: Failure to comply with this notice may result in injuries. Note: Failure to comply with this notice may result in damage to the unit or premises. Before Initial Operation ... - Page 4 Do not use aggressive cleaning agents. ● Do not use high-pressure cleaning methods. ● Repairs may only be done by certified and experienced personnel ● Keep away from naked flames. ● The battery may interfere with other electronic device’s sensitive ●...
-
Page 5: Technical Parameters
3 Technical Parameters Product size (L*W*H) 61-85*52*110-160 cm Folded size (L*W*H) 110*52*34 cm Packing size(L*W*H) 116*55*35 cm Load limit 180 kg Net Weight. 25 kg Gross Weight 35 kg 4 Operation Caution: The unit should only be operated by trained personnel. ... - Page 6 Raise the main handle to a suitable height by pulling the red bar upwards and sliding the main handle upwards. There are three possible positions for the main handle. When the desired position is reached, release the red bar. Ensure the main handle is locked in ...
-
Page 7: Moving The Unit On Level Ground
Lock the wheels of the unit and safely lift the load onto the platform. Once the load is balanced, secure the load to the unit using the supplied straps. 4.2 Moving the Unit on Level Ground Push and guide the chair from ... - Page 8 Deploy the climbing tracks by releasing the red side locks and pulling the tracks away from the body of the unit using the black bar. Ensure the climbing tracks are as close to the stairs as possible and firmly locked in position. Turn on the control unit by ...
-
Page 9: Descending Stairs
Press and hold the UP button on the control unit to begin moving. The climbing speed can be adjusted during movement by pressing the + and – buttons. When you have reached the top of the stairs, release the UP button and manoeuvre the unit completely ... - Page 10 Position the unit at the top of the stairs. Lock the wheels on the unit. Visually inspect the stairs to ensure that there are no safety hazards, including debris, ice, or water. Deploy the climbing tracks (as described above) and ensure they are locked in place. ...
-
Page 11: Folding The Unit
The climbing speed can be adjusted during movement by pressing the + and – buttons. When you have reached the bottom of the stairs return the unit to an upright position, release the DOWN button, and unlock the wheels on the unit. Press the POWER button to turn off ... -
Page 12: Maintenance
Retract the main handle by pulling up on the red bar as shown and lowering the main handle carefully. To fold the main unit, pull the red cross-bar under the unit along the slot as you fold the unit. 5 Maintenance ... -
Page 13: Adjusting The Track Tension
Notice: Follow the operating instructions to charge the battery. Notice: The new battery will reach its optimum state after several charging and discharging cycles. The battery can be taken off the unit for charging by unlocking the battery compartment with the ... -
Page 14: Recycling
5.4 Recycling Stair Climbers products are designed to have a long service life. However, if your unit is near the end of its life, you can return the unit to the manufacturer for recycling. 14 ... -
Page 15: Troubleshooting
6 Troubleshooting Fault Detection and solution The unit won’t start or Ensure the power switch on the control panel can't go up or down is in the ON position. stairs Check the level of charge remaining on the battery. If the level of charge is low, charge the unit. If the battery has charge remaining, and the ... - Page 16 16 ...
- Page 17 ww.stairclimbers.com.au (03) 8899 6615 17 ...
