Summary of Contents for suprema NOVUS
- Page 1 NOVUS INSTALLATION GUIDE Version 1.00 English EN 101.00.NVS07_D1/NVS07_D1K V1.00A...
-
Page 2: Table Of Contents
Contents Safety instructions ................. 4 Introduction .................... 5 Components ..............................5 Basic Components ................................5 Optional Components ................................. 6 Disassembling the device housing ........................ 7 Disassembling the rear cover ............................. 7 Disassembling the housing ..............................8 Name and function of each part ....................... 9 Front ...................................... - Page 3 Copyright notice ............................31 Open Source License ............................ 31 GNU GENERAL PUBLIC LICENSE ............................31 BoringSSL License ................................35 OpenSSL License ................................35 Original SSLeay License ..............................36 Chromium License ................................38 Apache License ..................................39...
-
Page 4: Safety Instructions
• These may cause product failure. NOVUS uses capacitive buttons and screen. If the environment is moist from wet weather or the product surface is smeared with a lot of water, wipe off the product with a dry towel before using it. -
Page 5: Introduction
You can choose NOVUS either NVS07-D1 or NVS07-D1K. • If installed, the swipe reader option is mounted on the right side of the NOVUS housing. The installer should allow for • access to the swipe reader by end-users in choosing the site installation location. -
Page 6: Optional Components
Optional Components You can assemble the various options you need into NOVUS. For more information on how to install each option, refer to Installing the Optional Part in this guide. Includes Includes Fingerprint Sensor · RFID Module Cable · ·... -
Page 7: Disassembling The Device Housing
Disassembling the device housing Disassembling the rear cover To assemble or disassemble some optional parts and connect cables, you need to separate the rear cover. Unlock the device with the key and open the rear cover of the device. Unplug one side of the cable and strap that are connected to both the rear cover and the housing side. Pull out the latch of the left side and disassemble the rear cover from the housing. -
Page 8: Disassembling The Housing
Disassembling the housing To assemble some optional parts, you need to separate the housing. Unplug one side of the cable that is connected to both the front and back of the housing. If a magnetic swipe reader is mounted on the device, you need to unplug the MSR module cable. Loosen the four screws on the back of the housing. -
Page 9: Name And Function Of Each Part
• OK: Used for selecting and setting an item. • : Used for moving to the desired item. • Fingerprint Authentication Unit Fingerprint placement location for authentication. Speaker Delivers sound. External USB slot External Host USB port for NOVUS-capable functions. -
Page 10: Name Of Each Part
Name of each part Housing Name GPS Module Adhesion Area Internal USB Slot for Wi-Fi Dongle and Modem data connection MSR Module Cable Connector Heat Sink Reset Button FW Download Button IO(Relay/Wiegand/RS-232) Board Cable Connector Battery Interface Connector PoE Switch Power Connector Ethernet/PoE Cable Port External USB Cable Connector... -
Page 11: Rear Cover
Keyboard Cable Connector Speaker Cable Connector Fingerprint Sensor Mounting Area Fingerprint FFC Connector Fingerprint Cable Connector RFID Module Mounting Area RFID Module Cable Connector Modem Power Cable Connector GPS Module Connector Rear Cover Name Relay Connector Wiegand Connector Modem Antenna Adhesion Area Modem Mounting Area Battery System IO(Relay/Wiegand/RS-232) Board Cable Connector... -
Page 12: Installation
Installation Fixing the device Disassemble the housing and the rear cover of the NOVUS by referring to Disassembling the device housing. Determine the correct position to install the NOVUS using the provided drilling template. Screw the two fixing screws first at the upper screw position of the drilling template. - Page 13 NOTE If installing NOVUS on a concrete wall, drill holes, insert PVC anchors, and attach them with fixing screws. • If you use the RFID option, to avoid RF interference, a minimum separation distance must be maintained. The • minimum separation distance of NOVUS is 10 cm from the horizontal plane and 10 cm vertically.
-
Page 14: Installing The Basic Part
You can connect the product to a hub using a general type CAT-5 cable. • NOVUS has an automatic MDI/MDIX function so that it can be connected to a PC directly using a normal straight • type CAT-5 cable or a cross cable. -
Page 15: Battery
Connect the battery cable to the battery connector on the battery board and the main board. NOTE When installing batteries with DC or POE power supplied, NOVUS may take up to a few minutes to detect batteries • for accurately and safely charge. We recommend to powering off the device when mounting the batteries. -
Page 16: Relay
Relay You can control the door by connecting the relay to the NOVUS. Use the SVP Android SDK, you can apply the feature to control the relay to your application. NOTE Relay cable is sold separately. • You can view the SVP Android SDK at http://kb.supremainc.com/svpsdk. -
Page 17: Installing The Optional Part
Installing the Optional Part You can assemble the various options you need into NOVUS. This section describes how to mount each option to NOVUS. NOTE Before installing the optional parts, turn off the power and PoE on the device, and remove the batteries. - Page 18 Hold the FCC with the blue side up connect it so that the outer dotted outline contacts the holder of the FCC connector. Close the holder of the FCC connector to lock the cable in place. Connect the fingerprint cable to the fingerprint cable connector. NOTE For more information on how to enroll the fingerprints, please refer to How to enroll a fingerprint...
-
Page 19: Rfid Module
RFID Module Disassemble the front and back of the housing by referring to Disassembling the housing. Place the RFID module on the RFID module mounting area. Fix the RFID module firmly at the housing using the two screws. Connect the RFID cable to the RFID module cable connector. -
Page 20: Msr (Magnetic Swipe Reader)
MSR (Magnetic Swipe Reader) Disassemble the front and back of the housing by referring to Disassembling the housing. Loosen the two screws on the inside of the housing side and disassemble the cover. Insert the MSR module cable into the hole in the housing side and mount the reader on the housing. Fix the magnetic swipe reader firmly at the housing using the two screws. -
Page 21: Gps
Disassemble the front and back of the housing by referring to Disassembling the housing. Attach the GPS module to the GPS module adhesion area using double-sided tape. Connect the GPS module cable to the GPS module cable connector. Wireless Ethernet Unlock the device with the key and open the rear cover of the device. -
Page 22: Cellular Modem
Cellular Modem Unlock the device with the key and open the rear cover of the device. Insert the cellular modem into the modem bracket from the top first and attach it using a double sided tape. Mount the lower part of the bracket into the modem mounting area of the rear cover and mount the upper part. Fix the modem bracket firmly at the rear cover using a screw. - Page 23 Connect the modem antenna to the cellular modem. NOTE Connect the modem antenna to the side of the antenna connector on the cellular modem. • Attach the modem antenna to the modem antenna adhesion area. The internal antenna may be omitted if the site requires use of a remote antenna to capture signal.
-
Page 24: Installing The Application
The Time and Attendance or Workforce Management applications can be installed on NOVUS via USB memory device. NOTE You can use the SVP (Suprema Versatile Platform) Android SDK to integrate the features of NOVUS to your • applications. You can view the SVP Android SDK at http://kb.supremainc.com/svpsdk. -
Page 25: Product Specifications
Product specifications Basic Device Category Feature Specification 1.0 GHz Quad-core Memory 16 GB eMMC LCD type 7.0” Touchscreen LCD resolution 1024 x 600 pixels Multiple colors Sound Max 1W Loudspeaker Operating temperature 0°C ~ 50°C Storage temperature -20°C ~ 70°C Operating humidity 0% ~ 80%, non-condensing General... -
Page 26: Optional Parts
Specification • Sensor: Optical sensor (OP6) Fingerprint • Template: SUPREMA / ISO 19794-2 / ANSI 378 R1: 125kHz EM, & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, HID iCLASS SE/SR/Seos • (UID Only), Legic Advant (UID Only) RFID R2: 125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, HID iCLASS •... -
Page 27: Dimensions
Dimensions (Unit: mm) 201.1 182.5 200.5... -
Page 28: Fcc Compliance Information
FCC compliance information FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 29: Eu Declaration Of Conformity (Ce)
This product is CE marked according to the provisions of the Radio Equipment Directive (RED) 2014/53/EU. Hereby, Suprema Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive (RED) 2014/53/EU. -
Page 30: Appendices
When the fingerprint recognition fails NOVUS can recognize a fingerprint regardless of a change of season or finger condition. However, the authentication rate may vary according to the external environment or fingerprint input method. If the fingerprint authentication cannot be done smoothly, it is recommended to take the following measures. -
Page 31: Disclaimers
Suprema's products. • Do not use the product of Suprema under the situations related to medical, rescue of human lives, or maintenance of life, as a person may get injured or lose his/her life due to product malfunction. If an accident... - Page 32 sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation's software and to any other program whose authors commit to using it. (Some other Free Software Foundation software is covered by the GNU Library General Public License instead.) You can apply it to your programs, too.
- Page 33 b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this License.
- Page 34 a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You are not responsible for enforcing compliance by third parties to this License. 7.
-
Page 35: Boringssl License
THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END OF TERMS AND CONDITIONS BoringSSL License BoringSSL is a fork of OpenSSL. As such, large parts of it fall under OpenSSL licensing. Files that are completely new have a Google copyright and an ISC license. -
Page 36: Original Ssleay License
Original SSLeay License Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code;... - Page 37 ISC license used for completely new code in BoringSSL: Copyright (c) 2015, Google Inc. Permission to use, copy, modify, and/or distribute this software for any purpose with or without fee is hereby granted, provided that the above copyright notice and this permission notice appear in all copies. THE SOFTWARE IS PROVIDED "AS IS"...
-
Page 38: Chromium License
* Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of Google Inc. -
Page 39: Apache License
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT OWNER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;... - Page 40 3. Grant of Patent License. Subject to the terms and conditions of this License, each Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable (except as stated in this section) patent license to make, have made, use, offer to sell, sell, import, and otherwise transfer the Work, where such license applies only to those patent claims licensable by such Contributor that are necessarily infringed by their Contribution(s) alone or by combination of their Contribution(s) with the Work to which such Contribution(s) was submitted.
- Page 41 rights consistent with this License. However, in accepting such obligations, You may act only on Your own behalf and on Your sole responsibility, not on behalf of any other Contributor, and only if You agree to indemnify, defend, and hold each Contributor harmless for any liability incurred by, or claims asserted against, such Contributor by reason of your accepting any such warranty or additional liability.
- Page 42 Tel: +82 31 783 4502 I Fax: +82 31 783 4503 I Inquiry: sales@supremainc.com ©2019 Suprema Inc. Suprema and identifying product names and numbers herein are registered trade marks of Suprema, Inc. All non-Suprema brands and product names are trademarks or registered trademarks of their respective companies. Product appearance, build status and/or specifications are subject to change without notice.
