VS2 Machine Vision System
INSTALLATION AND DEPLOYMENT GUIDE
What's included:
1x Controller Breakout Cable
1x Controller Mounting Plate
1x Camera Mount
¼
4x Self-Tapping Screws
1x
-20 Flat-End Screw
1x Camera
1x Camera Cable
1x Camera Controller
4x Flat-End Screws
4x M4 Flat-End Screws
1
Questions? samsara.com/support
Advertisement
Table of Contents
Summary of Contents for Samsara VS2
- Page 1 VS2 Machine Vision System INSTALLATION AND DEPLOYMENT GUIDE What’s included: 1x Controller Breakout Cable 1x Controller Mounting Plate 1x Camera Mount ¼ 4x Self-Tapping Screws -20 Flat-End Screw 1x Camera 1x Camera Cable 1x Camera Controller 4x Flat-End Screws 4x M4 Flat-End Screws...
- Page 2 The Samsara VS-series machine vision system is a complete solution for streamlining quality control across the factory floor. Once the system is installed, it can be programmed and updated remotely via the Samsara dashboard. This guide will walk you through the steps for deploying the system.
- Page 3 VS2 INSTALLATION GUIDE This section provides the information required for mounting the VS system including dimensions and important considerations for capturing clear images. For additional guidance on mount brackets, external lighting, and special configurations, consult your Samsara representative. VS2 Dimensions Enclosure...
-
Page 4: Mounting Considerations
Use shock mounts to minimize are inspecting depending on the feature’s camera at a 10° to 20° angle. Samsara movement and maintain camera size. Use the diagram in Appendix 1 to may also recommend external lighting to alignment where necessary. -
Page 5: Mounting Steps
MOUNTING VS2 INSTALLATION GUIDE Mounting Steps Once you have identified a mount location and installed your mount, mount the camera at the correct angle and working distance using the ¼ x 20 mounting screw or the included swivel mount and M4 screws. -
Page 6: Connectors And Indicators
Wi-Fi for internet connectivity and supports trigger inputs and outputs from NPN and PNP devices and lines. For additional guidance on integrating with both rejection and local control systems consult your Samsara representative. Connectors and Indicators Controller connectors... -
Page 7: Wiring Steps
Connect the controller to the camera using the Connect the controller to an active internet connection camera cable. via ethernet. Note: Contact Samsara if you would like to receive units pre-configured with Wi-Fi credentials. Questions? samsara.com/support... -
Page 8: Connecting An Output
WIRING VS2 INSTALLATION GUIDE CONNECTING A TRIGGER INPUT Triggering from an NPN device Triggering from a PNP device Connect the Input common wire (white) to +10-30VDC and Connect the Input common wire (white) to +0-3VDC and the Trigger wire (green) to the output of the trigger. - Page 9 Activate Devices Activation ABC9-DE9-FG9 Activate Samsara Hardware Go to cloud.samsara.com, create an account, and follow the on-screen steps to activate your hardware. You can find your serial number on the back of the controller or its box. cloud.samsara.com cloud.samsara.com...
- Page 10 VS2 INSTALLATION GUIDE VS2 Ring Light and Mount Samsara offers an externally mounted ring light for applications where additional lighting is required to reduce glare and provide a clear image. Consult your Samsara representative for additional details. 160.18 mm 166 mm...
