USER MANUAL

2D-STAEXTU

Preface

Dear Users,

Thank you for choosing and using our products.

In order for the better use of the product, please read this manual in

details and operate following the steps. Please also keep this manual

well stored for future reference.

Our company is committed to improve the product functions and service

quality continuously. The contents and figures in this manual may be

different from the actual product. The function description may have

slight differences due to specific types. If there are some differences

between the manual and the actual product, please refer to the actual

product.

Some parts, appearances or functions mentioned in this manual may

contain

the

issues.

No part of this

manual

may

be reproduced or transmitted

in any form or by any

means

without

prior written consent of our company.

Our company reserves the right to modify the contents and specifications

of this manual. The contents are subject to change without prior notice.

Should you have any question, please contact us and we will be at your

service. Thank you again for your use of our products.

Table of Contents

Need help?

Do you have a question about the 2D-STAEXTU and is the answer not in the manual?

Questions and answers

Summary of Contents for One Tech 2D-STAEXTU

Page 1 USER MANUAL 2D-STAEXTU Preface Dear Users, Thank you for choosing and using our products. In order for the better use of the product, please read this manual in details and operate following the steps. Please also keep this manual well stored for future reference.
Page 2: Table Of Contents
IPPS Intercom System Catalogue Chapter I Product Introduction........ 1 1.1 Appearance..........1 1.2 Basic Function ........... 3 1.3 Status Indicator ..........3 1.4 Technical Parameters........ 3 1.5 Product Standard........3 1.6 Configuration List........4 Chapter II Basic Operations........4 Chapter III Web Settings ........5 Chapter IV IC Card Registration......13 Chapter V System Connection Diagram....
Page 3: Chapter I Product Introduction
IPPS Intercom System Chapter I Product Introduction 1.1 Appearance Type:D-C9 Camera Fill Light Speaker Photosensitive Diod Emergency Call Key Microphone Type:D-C3（with funcion of swiping card） Microphone Photosensitive Diod Camera Night Light Card Area Label Call Key Speaker...
Page 4 IPPS Intercom System Type:D-C3（with numeric keyboard） Photosensitive Diod Microphone Camera Night Light Numeric Keyboard Label Call Key Speaker Type: D-C3（with one button） Photosensitive Diod Microphone Night Light Camera Label Call Key Speaker...
Page 5: Basic Function
IPPS Intercom System 1.2 Basic Function ◇Call the host for video call ◇Receive music broadcat and announcement from the host ◇Be able to connected with external microphone, active loudsperker, record output,door light control, electric lock,door contact, and alarm button, etc. 1.3 Status Indicator ◇When enabeling the outer net mode (checking SIP account), when there is anomalous connection between the extension and the server, the...
Page 6: Configuration List
IPPS Intercom System 1.6 Configuration List Open the packing box to check the configuration list inside the box. Chapter II Basic Operations 1. Call Press “Emergency Call Key” to call the host. 2. Unlock by card (only applicable to Type D-C3 with the function of swiping card) Holding the registered IC or ID card close to the card area, the extension will have the beep and the door is unlocked.
Page 7: Chapter Iii Web Settings
IPPS Intercom System Clicking the icon “Search”, IP address will be shown in the box of IP address. Chapter III Web Settings Connect the extension to the computer by the switch, enter the extension’s IP address in the web browser of computer (IP addresses of the computer and the extension should be in the same network segment), and then enter user name &...
Page 8 IPPS Intercom System 3.1 System Settings Clicking the icon “System Settings”, the system will enter the following interface: The number means the number of this extension with setting range 1~999; the host number means the number for superior host of this extension. Call Time: time limit for the call with the host.
Page 9 IPPS Intercom System the browser. After setting, click the icon “Apply” to enable the settings. 3.2 Network Settings Clicking the icon “Network Settings”, the system will enter the following interface: IP Address: for the same network segment in the same system, IP address should be different.
Page 10 IPPS Intercom System Server: URL of SIP proxy server in format of sip:ip or sip: domain name. Realm: Scope of device, same as IP or domain name in general. Password: Password for accessing SIP proxy server, provided by the administrator of SIP proxy server. Stun Address and Port: IP and port of public server for NAT traversal of audio and video.
Page 11 IPPS Intercom System Intercom Volume: the volume of call ranging from 0 to 5. Follow Host’s Settings: If checking, the extension will follow the host’s settings. The settings on this extension will be invalid (The default settings will follow the host’s settings). Extension Volume: the volume of extension ranging from 0 to 5.
Page 12 IPPS Intercom System 3.6 Unlock Settings Clicking the icon “Unlock Settings”, the system will enter the following interface: Unlock Time: time of extension for unlocking the door Unlock Password: it is used for unlocking the door (only applicable to the extension type with keyboard) Enable Changes of Unlock Password: After checking, the unlock password can be changed.
Page 13 IPPS Intercom System Noise Alarm Setting: After the box “Follow Host’s Settings” is checked, the own settings of the extension are invalid. Sensitivity Setting: Set the sensitivity of noise alarm for the extension, suggestion: set high sensitivity for a quiet environmen and low sensitivity for a noisy environment.
Page 14 IPPS Intercom System Check the box “On”, and input the path of FTP server in the box “FTP Path”, such as ftp://192.168.12.60/upgrade After setting, click the icon “Apply” to enable the settings. The extension will check regularly if new update package of software is available.
Page 15: Chapter Iv Ic Card Registration
IPPS Intercom System Chapter IV IC Card Registration (applicable to the device with the function of swiping card) Connect the extension to the computer by the switch, enter the extension’s IP address in the web browser of computer (IP addresses of the computer and the extension should be in the same network segment), and then enter user name &...
Page 16 IPPS Intercom System Swipe the IC card to be registered on the device, click the icon “for Card Number” after the beep, input the relevant information such as user name, and click the icon “Register” to complete the registration. In turn, when registering the next IC card, the should be swiped on the device.
Page 17 IPPS Intercom System 4.2 Visit Time Management Clicking the icon “Visit Time Management”, the system will enter the following interface: The page shows the current system time. In order to ensure that the visit time is effective, please make sure to check whether the display time is correct.
Page 18 IPPS Intercom System 4.2 IC Card Management Clicking the icon “IC Cad Management”, the system will enter the following interface: The registered IC card including valid time period, user name and ID card No. can be modified in this page. Click “Apply” to save the changes. To delete the card, please check the option “Delete”...
Page 19: Chapter V System Connection Diagram
IPPS Intercom System Chapter V System Connection Diagram -17-...
Page 20: Chapter Vi Extension Connection Diagram
IPPS Intercom System Chapter VI Extension Connection Diagram 1. Centralized Power Supply: input of DC12V. When the device needs to adopt the centralized power supply, this connector can be used as power inut of the device. In this case, DC power socket is not used. 2.
Page 21 IPPS Intercom System subordinate extension will show door magnet 1 in the main interface of the host. 7. Door Magnet 1: Connect with the door magment and indicate switch status of door lock 2 through the host. When door lock 2 opens, the grid of subordinate extension will show door magnet 2 in the main interface of the host.
Page 22 IPPS Intercom System Eletric Lock Connection: -20-...
Page 23 IPPS Intercom System Magnetic Lock Connection: -21-...
Page 24: Chater Vii Installation Instructions
IPPS Intercom System Chater VII Installation Instructions Type: D-C9（flush mounted installation） Installation: 1. Have a square groove in proper position of wall or gate based on the mounting dimensions of extension； 2. Place the embedded box into the slot; 3. Fix the tamper module on the embedded box; 4.
Page 25 IPPS Intercom System Installation Instructions: [Suggestion]: When the installation, the camera should be 1450～1550mm from the ground. -23-...
Page 26 IPPS Intercom System Type: D-C9（surface mounted installation） Installation: 1. Fix the exposed aluminum cover on 86-type connecting block and tighten the screws; 2. Fit the extension into the cover and lock it with one bottom screw. -24-...
Page 27 IPPS Intercom System Installation Instructions: [Suggestion]: When the installation, the camera should be 1450～ 1550mm from the ground. -25-...
Page 28 IPPS Intercom System Type: D-C3 Installation: 1. According to the mounting dimensions of extension, have a square slot in proper position of wall or gate and open a drain hole at the bottom of the wall; 2. Open up the threading hole at the bottom of embedded box for drainage;...
Page 29 IPPS Intercom System Installation Instructions: [Suggestion]: When the installation, the camera should be 1450～ 1550mm from the ground. -27-...
Page 30: Chapter Viii Safety Instructions
IPPS Intercom System Chapter VIII Safety Instructions In order to protect you and others from harm or your device from damage, please use the device after reading the following information. Do not install the device in the followin places:  Do not install the device in high-temperature and moist environment or the area close to magnetic field, such as the electric generator, transformer or magnet.
Page 31 IPPS Intercom System expose the device to chemical products, such as the diluent, gasoline, alcohol, insect-resist agents, opacifying agent and insecticide.  Do not knock on the device with hard objects.  Do not press the screen surface. Overexertion might cause flopover or damage to the device.
