TROUBLE SHOOTING
EAR SPEAKER NOT RECEIVING
•
Verify that radios communicate with each other with
no accessories attached.
•
Verify that all connectors are fully engaged.
•
Adjust receiving radio volume.
•
Position ear speaker near ear by bending flexible
boom.
RADIO NOT TRANSMITTING
•
Verify that radios communicate with each other with
no accessories attached.
•
Verify that all connectors are fully engaged.
•
Adjust receiving radio volume.
•
Adjust position of the Helmet Mic. along the nape
strap of the helmet.
•
Tighten ratchet suspension
GARBLED OR UNCLEAR COMMUNICATIONS
•
Verify that radios communicate with each other when
no accessories attached.
•
Verify that all connectors are fully engaged.
•
Adjust receiving radio volume. Some radios will pro-
duce distorted sound at full volume.
•
Adjust position of the Helmet Mic. along the nape
strap of the helmet.
•
Check for wrinkles or folds of excess material
between Helmet Mic. and head.
•
Tighten ratchet suspension.
MAINTENANCE/TROUBLESHOOTING
INSTRUCTION MANUAL
HELMET MIC. ASSEMBLY
Note: The radio must be specified when ordering the
Lapel Microphone (See Radio Interface Kits).
REPLACEMENT PARTS
Item Part
DUST COVER
TALL GUARD
SHORT GUARD
BELT CLIP ASSY STANDARD
BELT CLIP ASSY CLOTHESPIN TYPE
O-RING, SINGLE-PIN CONNECTOR
Pkg. of 10
FLANNEL HEADBAND LINER
7
10046197
10042902
Number
10046087
10046123
10046122
10046089
10046120
10046121
10045778
TAL 5010 (L) REV. 4 - 10046197
