- Page 1 Sepa CF Cell Assembly & Operation Manual www.sterlitech.com info@sterlitech.com 1-877-544-4420...
-
Page 2: Table Of Contents
Table of Contents Page 1. Introduction 2. Sepa CF Cell Components 3. Sepa CF Cell Assembly 4. Operation of the Sepa CF Cell 5. Supplementary Operating Information 6. Accessory and Spare Part Ordering Information 7. Return Material Authorization 8. Warranty 9. -
Page 3: Introduction
Sepa CF Cell Manual 1. Introduction The Sepa CF Cell is a laboratory-scale crossflow filtration unit designed to evaluate the performance of flat sheet membranes in a variety of applications. It simulates the flow dynamics of larger, commercially available membrane elements such as industrial spiral wound membrane elements. By using a combination of stainless steel (SS) shims, feed spacers, and membranes, users can vary the operating conditions and fluid dynamics over broad ranges. -
Page 4: Sepa Cf Cell Components
Sepa CF Cell Manual 2. Sepa CF Cell Components Verify that the Sepa CF Cell was shipped complete, intact, and undamaged. The complete Sepa CF Cell includes: 1. Stainless steel cell body: top and bottom Cell Top Cell Bottom 2. Anodized aluminum cell holder with piston and high-pressure gauge Cell Holder www.sterlitech.com... - Page 5 ¼-inch diameter permeate tubing (91.4 cm [3 ft]) 4. Concentrate control valve with high pressure gauge 5. O-rings (2) 2.1 Additional Equipment The Sepa CF Cell also requires additional equipment to be operated, which are sold separately: • Hydraulic hand pump to pressurize the cell holder •...
-
Page 6: Sepa Cf Cell Assembly
3. Sepa CF Cell Assembly After verifying that all the necessary components were shipped and present, you can begin the assembly of the Sepa CF Cell. 3.1 Cell Body Assembly The cell body consists of the cell top, membrane filter, feed spacer/ permeate carriers (optional), shims (optional), O-rings, and cell bottom. - Page 7 Sepa CF Cell Manual To assemble the Sepa CF Cell Body: 1. Connect the concentrate flow control valve to the cell bottom by wrapping PTFE tape around the valve’s male NPT end and screwing it into the concentrate outletport. Note: The cell bottom is the half of the cell body that has the four alignment pins. The cell top has the holes to accept the alignment pins.
- Page 8 Sepa CF Cell Manual 4. Install the feed spacer into the central cavity, on top of the shim. The feed spacer must lie flat and be fully contained within thecavity. Note: The feed spacer and the permeate carrier look similar and are cut in the same size. The permeate carrier is thinner and has a tight weave while the feed spacer has large gridding.
- Page 9 Sepa CF Cell Manual 6. Wet the permeate carrier with water or the fluid to be processed and place it into the cavity in the cell top. The surface tension caused by wetting the carrier will keep it in place.
- Page 10 3.2 Cell Holder Assembly The cell holder is filled with Mobil DTE 20 Series Hydraulic Oil to operate the hydraulic piston. Before using the Sepa CF Cell for the first time, the brass quick release connector must be installed into the cell holder.
- Page 11 Sepa CF Cell Manual 3.3 Sepa CF Cell Connections and Parts Figure 2: Example Sepa CF Flow Diagram Sepa CF Flow Diagram Item No. Part Description Conical Feed Tank Pressure Relief Valve Motor & Pump Assembly Drain Valve Flow Meter...
- Page 12 Figure 2 shows the typical plumbing connections that need to be made for the operation of the Sepa CF Cell. The configuration can change slightly depending on the objectives of the user. In general, the connections to be made are:...
-
Page 13: Operation Of The Sepa Cf Cell
To operate the Sepa CF Cell: 1. Set the feed pressure less than or equal to the piston pressure on the cell holder/cell body and turn the feed flow pumpon. -
Page 14: Supplementary Operating Information
Sepa CF Cell Manual 5. Supplementary Operating Information 5.1. Membrane Performance Results Spiral wound membranes containing mesh spacers are usually operated with a fluid velocity across the membrane surface of 0.1–0.5 m/sec (0.3–1.6 ft/sec). Higher velocities in membranes may lead to an excessive pressure differential across the membrane and possible damage. -
Page 15: Accessory And Spare Part Ordering Information
Sepa CF Cell Manual 6. Accessory and Spare Part Ordering Information Accessories and spare parts for the 1812 housing can be ordered by calling Sterlitech Corporation at 1-877-544-4420 or by visiting www.sterlitech.com. Table 3: Accessory and Spare Part Ordering Information... -
Page 16: Return Material Authorization
Sepa CF Cell Manual 7. Return Material Authorization If materials are to be returned to Sterlitech for repair, evaluation, or warranty consideration, a Return Material Authorization (RMA) number and form must be obtained from Sterlitech prior to the return. Contact Sterlitech’s Customer Service Department for these forms. -
Page 17: Appendix 1: Sepa Cf Cell Applications
Sepa CF Cell Manual Appendix 1: Sepa CF Cell Applications The following studies utilized the SepaCF Cell in their method and are listed here to illustrate the potential applications for the SepaCF. These studies are good references for understanding the operation of the SepaCF Cell. -
Page 18: Appendix 2: Bench Scale Filtration Products
Sepa CF Cell Manual Appendix 2: Sterlitech Bench Scale Filtration Products Discoverer Innovator Explorer Developer Investigator Filter Holder HP4750(X) CF016 CF042 Sepa 1812 Membrane 14.6 cm (2.26in 20.6 cm (3.2in 42 cm (6.5in 0.27-0.46 m 140 cm (22in Active Area... - Page 19 Sepa CF Cell Manual Notes: www.sterlitech.com info@sterlitech.com 1-877-544-4420...
- Page 20 Sepa CF Cell Manual Notes: www.sterlitech.com info@sterlitech.com 1-877-544-4420...
- Page 21 Sterlitech’s bench scale test equipment provides the versatility required to innovate. Sterlitech’s comprehensive line of products is supported by the expertise of its technical specialists who can assist with application-specific product selection, and provide customized solutions where necessary. Unique problem-solving approaches, flexibility, and consistent quality have made Sterlitech Corporation a renowned global provider of filtration products and equipment.
- Page 22 22027 70th Ave. S Kent, WA 98032-1911 USA Phone: (253) 437-0844 Fax: (253) 437-0845 Email: sales@sterlitech.com © 2019 Sterlitech Corporation...
