Herschel iQ WH1 Installation And Operating Manual

Central control unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WH1 Central Control Unit
ELECTRICAL EQUIPMENT:
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist.
The product complies with EEC Directives 2014/35/EU Low Voltage Directive, 2014/30/EU EMC
Directive, 2011/65/EU Restriction of Hazardous Substances Directive, 2014/53/EU RED Directive,
2009/125/EC Ecodesign Directive & 93/68/EC CE Marking Directive.
Original instructions covering WH1 units produced 122017 onwards.
Installation and Operating Guide
IP20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iQ WH1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Herschel iQ WH1

  • Page 1 WH1 Central Control Unit Installation and Operating Guide IP20 ELECTRICAL EQUIPMENT: Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. The product complies with EEC Directives 2014/35/EU Low Voltage Directive, 2014/30/EU EMC Directive, 2011/65/EU Restriction of Hazardous Substances Directive, 2014/53/EU RED Directive, 2009/125/EC Ecodesign Directive &...

  • Page 2: Important Safety Precautions

    WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY: 1. The Herschel iQ system must be fitted by a competent person and installation must comply with the guidance provided in the current editions of BS7671 (IEE Wiring Regulations).

  • Page 3: How Does It Work

    Explore your iQ to find out what you can achieve, using this simple guide to get the most from your new system. SIMPLE CONTROL FOR BETTER COMFORT Herschel iQ gives you intelligent controls that are easy to use. A clear, simple touch screen controller leads you every step of the way through setting up and managing your building heating system.
  • Page 4 2. Pair your WH1 and R1(s). Enjoy the convenience of Herschel’s pre-set default programme until you can determine the changes you want in each location see in the User Guide “Section 8. Setting up a new Heating Schedule”, when you are ready).
  • Page 5 Fix to the wall, reconnect ribbon cable and close Install the base plate over the pattress and onto the wall, using the screws provided. Then reconnect the ribbon cable. Replace the faceplate (bottom edge first). Start WH1 for the first time Turn the mains power on, the WH1 will default to the “Quick Actions”...
  • Page 6 3. SETTING UP ZONES AND PROGRAMMES For added convenience the Herschel iQ WH1 is pre configured with default settings below. The system will run with these until you are ready to personalise them. All days: 0500 20°C 0900 16°C 1600 20°C...
  • Page 7 5. SET UP AND MANAGE ZONES WH1 has up to 6 zones and 6 R1’s within each zone. Use zones to group heaters by the way you wish to control them. For example, you may wish to put several or all bedrooms onto one zone, hallways / bathrooms into another and living areas in another zone.
  • Page 8 From this screen you can take actions to control the whole zone, or just individual R1 receivers. 5.2 NAMING THE ZONE Long-click on the zone icon in the top right of the Manage Zone screen. (Initially this will be the number 1 – 6). This enables the keyboard with UPPER and lower case letters, numbers 0- 9, a back-space and a control to pick your letters and numbers.

  • Page 9: Receiver Status

    To do so, long click on the R1 name (e.g. ‘3’) in the top right hand corner of the screen. Use the keyboard as before to name your heater and remember to save before exiting. 6.2. RECEIVER STATUS On the “Manage Heater” screen, you will see: •...
  • Page 10 To set the mode, Click the word “Mode” (if it is not Orange) and click the Icon of the mode you want to set. That Icon will also turn Orange to show it is activated. Comfort Mode. This raises your set temperature to a new (higher) temperature. This setting will remain until you choose a different mode.

  • Page 11: Warranty

    Refer to Herschel Infrared Ltd’s warranty policy for full details. See https://www.herschel-infrared.com. USER GUIDE ONLINE The online version of this user guide is available on the WH1 product page on Herschel’s website. You can download it by using this QR code, or going to: https://www.herschel-infrared.com/product/iq-wh1-central-control-unit Page | 11...

  • Page 12: Frequently Asked Questions

    It must not be possible for anyone in the bath or shower to be able to reach out and touch the R1. Herschel Infrared Ltd cannot accept responsibility for damage, loss or injury caused by ingress of water or moisture into the R1 unit.
  • Page 13 The range of the R1 and WH1 will depend on factors such as wall thickness, interference etc. For locations out of range of your WH1, (outbuildings etc), the R1 will pair and be controlled by Herschel IQ T1 room thermostats which can be purchased separately, but would not form part of the WH1 control solution.
