Summary of Contents for Human Eyes VUZE
- Page 1 Underwater Case...
-
Page 2: Table Of Contents
VUZE UNDERWATER CASE SPECIFICATIONS ........ -
Page 3: Package Contents
● Desiccant Packet (with double sided adhesive mounting square) ● Microfiber Storage Pouch ● Manual ● Pelican Storage Case & Foam ● Spare Parts & Tools Kit F igure 2: Parts needed for assembling the VUZE Underwater Case and mounting the VUZE and VUZE+ camera... -
Page 4: Assembly
VUZE-UWC Manual V6 ASSEMBLY STEP 1: Attach the Camera Mount Plate to the bottom of your VUZE or VUZE+ camera. Ensure that the serial number is fully visible and aligned with the Camera Mount Plate. Figure 3: Assembly of VUZE camera to Camera Mount Plate... - Page 5 VUZE-UWC Manual V6 STEP 3: Ensure that the “D-ring” on the Camera Fixing Screw lays flat. Slide the Camera Mount Plate and camera into one half of the underwater housing with the camera buttons aligned to the underwater housing buttons.
-
Page 6: Before Each Use Checklist
Lenses can be cleaned with a lint-free microfiber cloth. Verify the Camera Mount Plate is securely attached to the VUZE or VUZE+ camera mount. Verify the VUZE or VUZE+ camera serial number is fully visible and aligned within the Camera Mount Plate serial number cut-out. -
Page 7: During Operation
Look through the clear plastic Curved Button Assembly to verify status lights on the camera. Figure 7: Top view of H umanEyes VUZE Underwater Case Note that the camera microphones are extremely sensitive to noises while underwater. Bumping of the underwater housing, SCUBA regulator operation, boat noises, fish and reef noises may be loud and distorted on the recording. -
Page 8: Maintenance
Ensure the screw is sufficiently tightened to fully seal the lens to the underwater housing. Verify the underwater housing does not leak before using the underwater housing with the VUZE or VUZE+ camera. - Page 9 PREVENTATIVE MAINTENANCE AND CARE Always thoroughly rinse the VUZE Underwater Case . U pon completion of underwater activities, place the underwater housing in a bucket of fresh water for at least five minutes prior to drying and opening the...
-
Page 10: Storage And Transport
STORAGE AND TRANSPORT While the VUZE Underwater Case is designed for underwater environments, care must be taken during transport and storage to reduce the likelihood of leaks: ● Always keep the lenses covered with the plastic film that originally came with the lenses. Cellophane or similar plastic cling wrap may be substituted if the original plastic film is lost or damaged. - Page 11 VUZE-UWC Manual V6 Figure 12: Exploded view of Handle Bridge Figure 13: (Bottom View) The Handle Bridge allows rigging and accessory attachment along central installation (top and bottom) and removable handle. vertical axis of the underwater case to increase stability...
-
Page 12: Spare Parts & Tool Kit
LIMITED WARRANTY This HumanEyes VUZE Underwater Case is warranted against any manufacturer defects for a period of one (1) year from the original date of purchase. Defective products should be returned to HumanEyes postage paid. HumanEyes will, at its sole discretion, repair or replace such products, and will return to customer postage paid. -
Page 13: Vuze Underwater Case Specifications
VUZE-UWC Manual V6 VUZE UNDERWATER CASE SPECIFICATIONS Compatible Cameras VUZE and VUZE+ Maximum Rated Depth 135 ft (41 meters) Weight in Air Approximately 3.8 lbs (1.72 kg) Buoyancy (seawater) Negative 0.90 lb (-0.41 kg) Buoyancy (freshwater) Negative 0.97 lb (-0.44 kg) Dome Screw Torque 2 pound-inches (0.22 newton-meters) -
Page 14: Assembly Drawing
VUZE-UWC Manual V6 ASSEMBLY DRAWING... - Page 15 VUZE-UWC Manual V6 NOTES ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 16 Humaneyes Technologies Inc. www.humaneyes.com...
