Observator NEP5000 Turbidity Sensor
The Observator ANALITE NEP5000 Turbidity Sensor is compatible with the Nexsens
X2 data logger using SDI-12 output, and is designed for environmental monitoring
and process applications.
Calibrating the NEP5000
For configuration and calibration, the Observator ANALITE NEP5000 Configuration
Kit accessory must be used. This kit comes with a dedicated Subconn connection
cable.
The Subconn cable to calibration module connection is detailed in the table below.
Subconn Wire Color
Black
White
Red
Green
Orange
Blue
Quick Start Guide
Wire Outputs
Power GND
SDI-12 Data
10 to 30V DC power
4-20mA loop to power
GND
Voltage Out
Calibration
Communication Data
1
Calibration
Module Connection
Slot 2
N/A
Slot 1
N/A
N/A
Slot 6
2091 Exchange Court
Fairborn, Ohio 45324
937-426-2703
www.NexSens.com
Advertisement
Table of Contents
Related Manuals for Observator ANALITE NEP5000
Summary of Contents for Observator ANALITE NEP5000
- Page 1 Observator NEP5000 Turbidity Sensor Quick Start Guide The Observator ANALITE NEP5000 Turbidity Sensor is compatible with the Nexsens X2 data logger using SDI-12 output, and is designed for environmental monitoring and process applications. Calibrating the NEP5000 For configuration and calibration, the Observator ANALITE NEP5000 Configuration Kit accessory must be used.
- Page 2 Black 10 to 30 VDC power *If the MCIL wire color is not listed, it is unused in the connection. For additional information, please read the Observator sensor manual located on the Fondriest Environmental website. https://www.fondriest.com/pdf/observator_nep5000_manual.pdf 2091 Exchange Court Fairborn, Ohio 45324 937-426-2703 www.NexSens.com...
