Feasycom FSC-BP403 Product Manual

Version：V1.1
Bluetooth Headsets Application Mode
Power On
‐Long press the multifunction key for 2 seconds, power on after blue light flash for once.
‐When There's No Connection Record: The device will enter paring state for 2 minutes, both blue/red lights will be
flashing, it means the receiver is waiting to be connected.
‐When There's Connection Record: After blue light flash for twice, the receiver will start auto‐scanning and connect to
the last BT device paired. If the receiver can't find or connect to the BT devices with connection record for 2 minutes,
it will enter none‐broadcasting‐under‐connection state, blue light will flash every 3 seconds, and it will auto
shutdown after 10 minutes in this state.
‐When connection successfully built, the blue light will be under breathing light state (It'll flash every 7 seconds)
‐When connection failed to be built, receiver will enter none‐broadcasting‐under‐connection state.
Power Off
Long press the multifunction key for 5 seconds, the receiver will be turn off, meanwhile.
Charging
When charging, the indicator red light will be flashing slowly; When battery fully charged, the indicator red light will be
steadily on.
Low Power State
When battery power is running low, the red light will be flashing 3 times per 30 seconds; When battery power ran out,
the device will be auto‐powered off.
(Low Power State: Battery power between 3.0V ~ 3.2V; Power Off: Battery power less than 3V)
Connecting
When paring with new BT devices:
1, Use the phone to search and connect to the device: Feasycom‐XXXX (XXXX indicates the last 4 characters of the BT
device address).
‐In default, no pairing password, if the phone end requests a password, input "0000".
2, When connection successfully built, the blue light will be under breathing light state.
‐If the receiver can't find or connect to the BT devices with connection record for 2 minutes, it will enter none‐
broadcasting‐under‐connection state, blue light will flash for once in every 3 seconds, and it will auto shutdown
after 10 minutes in this state.
3, Long press the multifunction key for 8 seconds, both red/blue lights on for 1 second, alternately flash afterward, now
the FSC‐BP403 can be found and connected.
Connection Interruption
‐When connection interruption happens, the receiver will enter Standby Mode(Blue light flashing every 3 seconds),
and it will try to reconnect every 30 seconds, 6 tries in total.
‐When there's no connection built in 10 minutes, it will be turned off automatically.
